- Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
-
Page 3: Equipment Supplied
Q u i c k R e f e r e n c e Introduction The PL 370/470 RF cradle acts as a stand, host communication interface, and a charger for the Phaser RF scanner. It can sit on a desktop or be wall-mounted - whichever is more convenient. -
Page 4: Parts Of The Cradle
3 7 0 / 4 7 0 C r a d l e Parts of the Cradle Antenna Pairing Label Scanner Support Tab Charging/Communications Contacts Charging COM 1 Port Power Port Wall-mounting Socket 1 Wall- mounting Socket 2... -
Page 5: Connecting To The Host
Q u i c k R e f e r e n c e Connecting to the Host To connect the cradle to a host: COM1 1. Insert the appropriate in- terface cable from the host computer into the COM1 port. - Page 6 3 7 0 / 4 7 0 C r a d l e 2. Seat the cables from the bottom of the cradle in the grooves along the length of it so that the bottom of the cradle is smooth. 3.
- Page 7 Q u i c k R e f e r e n c e However, the scanner and cradle must be paired for this communication to work. After a new host is installed at the cradle, re-scan the Note: pairing bar code. This allows the cradle to notify the scanner of the change in the host device.
-
Page 8: Charging Led
3 7 0 / 4 7 0 C r a d l e Charging LED Once the scanner is placed in the cradle, it waits 15 minutes to start charging the battery in the scanner. The LED indicates the charging status as follows: Scanner is not in cradle Scanner is in cradle, not charging... -
Page 9: Regulatory Information
Q u i c k R e f e r e n c e Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. - Page 10 3 7 0 / 4 7 0 C r a d l e minimum 1 A. Die Stromversorgung ist bescheinigt nach EN60950 mit SELV Ausgaben Radio Frequency Interference Requirements Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
- Page 11 • Italy requires a user license for outside usage. Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from http:// www2.symbol.com/doc/...
- Page 12 3 7 0 / 4 7 0 C r a d l e Warranty (A) Seller's hardware Products are warranted against defects in workmanship and materials for a period of twelve (12) months from the date of shipment, provided the Product remains unmodified and is operated under normal and proper conditions.
-
Page 13: Wall Mounting Template
Q u i c k R e f e r e n c e Wall Mounting Template 1.27” Wall Mounting Socket 1 Use 1/8” drill bit for screw holes. Center Line of Cradle 3.85” Wall Mounting Socket 2 1.11”... - Page 14 3 7 0 / 4 7 0 C r a d l e This page left blank.
- Page 15 Q u i c k R e f e r e n c e This page left blank.
- Page 16 +44 118 945 7360 Customer support is available 24 hours a day, 7 days a week. For translations and the latest version of this guide go to: http://www.symbol.com/manuals. 72-38494-01 Revision B — June 2002 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
