Summary of Contents for Symbol CRD 2x00 - 1000S
- Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
-
Page 3: Table Of Contents
R e f e r e n c e Introduction This guide describes how to set up and use the single slot serial/ charging cradle with Symbol PPT 2700 and PPT 2800 terminals. The cradle: • provides power for operating the terminal •... -
Page 4: Parts
Parts Spare Battery Charging Slot Slot for Terminal Spare Battery LED Spare Battery Terminal Status LED Charging Slot Serial Port Power Port LED Indicators Indicator Meaning Terminal Status Solid Red Terminal battery is charging. This occurs whether the terminal is on or off. Solid Green The terminal battery is fully charged. -
Page 5: Connecting To Power
Q u i c k R e f e r e n c e Connecting to Power The cradle provides power to a PPT 2700 or PPT 2800 terminal, and re-charges terminal batteries. To connect the cradle to a power source: 1. -
Page 6: Connecting To A Host Pc Or A Serial Device
• the Terminal Status LED lights up (red, if battery is charging). If the battery is fully charged, the Status LED turns green. Connecting to a Host PC or a Serial Device Host PC To enable synchronization, make sure Windows CE Services/ ActiveSync Software have been installed and configured on both the terminal and the Host PC. - Page 7 Q u i c k R e f e r e n c e 3. Connect the other end of the serial cable to the host PC. Serial Port on host PC Note: The cradle requires a dedicated serial port on the host PC.
-
Page 8: Synchronizing Data With A Host Pc
Synchronizing Data With a Host PC This section describes how to use the cradle to synchronize infor- mation between a terminal and a host PC. After you synchronize, any changes you have made on your terminal or in your desktop software appear in both places. - Page 9 Q u i c k R e f e r e n c e partnership dialog box. The terminal should similarly indicate a “connected” status. 4. On the desktop computer, enter a unique device name for your terminal and click the Next button. Follow the instructions on the screen to set up a partnership that allows synchronization of information between the two computers.
-
Page 10: Terminal Battery Charging
Terminal Battery Charging To recharge the terminal’s lithium-ion battery using the cradle: 1. Ensure the cradle is powered. 2. Insert the terminal in the cradle. Spare Battery LED Terminal Status LED 3. The Terminal Status LED turns red to indicate charging, then green when the battery is fully charged. -
Page 11: Spare Battery Charging
Q u i c k R e f e r e n c e Spare Battery Charging To charge a spare terminal battery: 1. Insert the battery into the spare battery charging slot in the back of the cradle. Spare Position it with the charging Battery contacts facing down and... -
Page 12: Troubleshooting
Troubleshooting Symptom Possible Cause Action Terminal Status Terminal is not inserted Remove the terminal and re-insert LED does not correctly into the cradle. it, making sure it fits snugly onto the light up. connector at the bottom of the cra- dle. -
Page 13: Regulatory Information
Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. - Page 14 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby declares that this device is in compliance with all the applicable Directives, 89/336/EEC, 73/23/EEC. A Declaration of Conformity may be obtained from http://...
- Page 15 Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which...
-
Page 16: Service Information On
Distributor Operations +44 118 945 7360 Customer support is available 24 hours a day, 7 days a week. For the latest version of this guide go to: http://www.symbol.com/manuals. 70-37807-02 Revision D — December 2002 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
