Service Manual
Microwave Oven
Model: KOR-6Q1B3A
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. : R6Q1B3A001
Jul. 2004
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo KOR-6Q1B3A
Summary of Contents for Daewoo KOR-6Q1B3A
-
Page 1: Microwave Oven
S/M No. : R6Q1B3A001 Service Manual Microwave Oven Model: KOR-6Q1B3A Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). -
Page 2: Table Of Contents
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other micro- wave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse. -
Page 3: Safety And Precautions
SAFETY AND PRECAUTIONS CAUTION : This Device is to be Serviced Only by Properly Qualified Service Personnel. Consult the Service Manual for Proper Service Procedures to Assure Continued Safety Operation and for Precautions to be Taken to Avoid Possible Exposure to Excessive Microwave Energy. 1. -
Page 4: Specifications
SPECIFICATIONS MODEL KOR-6Q1B3A POWER SUPPLY 120V~60Hz, SINGLE PHASE WITH GROUNDING MICROWAVE 1000W POWER GRILL CONSUMPTION COMBINATION CONVECTION MICROWAVE ENERGY OUTPUT 700W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W X H X D) 465 x 279 x 327 mm (18.3 x 11.0 x 12.9 in) CAVITY DIMENSIONS (W X H X D) 301 x 230 x 283 mm (11.9 x 9.1 x 11.1 in) -
Page 5: External View
EXTERNAL VIEW 1. OUTER DIMENSION... -
Page 6: Feature Diagram
2. FEATURE DIAGRAM 1 SAFETY INTERLOCK SYSTEM 2 DOOR SCREEN Allows viewing of food. The screen is transparent to light, but prevents microwaves escaping. 3 DOOR LATCH When the door is closed, it will automatically shut off. If the door is opened while the oven operating, the magnetron tube will immediately stop operating. -
Page 7: Control Panel
3. CONTROL PANEL 1 DISPLAY - Cooking time, power level, indicators and present time are displayed. 2 ONE TOUCH - Used to cook or reheat specific quantities of food. 3 POWER - Used to set power level. 4 + - Used to add time to cooking. 5 - - Used to decrease time from cooking. -
Page 8: Installation
INSTALLATION 1. Steady, flat location. This microwave oven should be set on a steady, flat surface. 2. Leave space behind and side. All air vents should be kept a clearance. If all vents are covered during operation, the oven may be overheated and, eventually, cause oven failure. -
Page 9: Operations And Functions
OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray must always be in place during cooking. 3. -
Page 10: Disassembly And Assembly
DISASSEMBLY AND ASSEMBLY Cautions to be observed when troubleshooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safe during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully. - Page 11 1. To remove cabinet 1) Remove three screws on cabinet back. 2) Pull the cabinet backward. 2. To remove door assembly 1) Remove the screw which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.
- Page 12 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 3. To remove door parts. REF NO.
- Page 13 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ Loosen the screw on stopper hinge top, and then push the door to contact the door seal to oven front surface. Tighten a screw.
- Page 14 Information Center (http://svc.dwe.co.kr). 5. To remove control panel parts. REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3518571600 SWITCH MEMBRANE KOR-6Q1B3A 3516732020 CONTROL-PANEL ABS VT-0826, AF-348 HG PKMPMSFM00 PCB MAIN MANUAL AS 6N(700W, A) 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN...
- Page 15 6. To remove high voltage capacitor. 1) Remove a screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
- Page 16 8. To remove wind guide assembly. 1) Remove a screw for earthing. 2) Remove a screw which secure the wind guide assembly. 3) Draw forward the wind guide assembly. 4) Pull the fan from the motor shaft. 5) Remove two screws which secure the motor shaded pole. 6) Remove the motor shaded pole.
-
Page 17: Interlock Mechanism And Adjustment
INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. CONDITION : DOOR CLOSED CONDITION : DOOR OPEN (1) Primary interlock switch... -
Page 18: Troubleshooting Guide
TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before trouble checking. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed. - Page 19 CONDITION CHECK RESULT CAUSE REMEDY Defective Outlet has Check continuity of Replace continuity magnetron. proper volt- magnetron fuse does not blow. Check continuity of noise filter Defective line Replace continuity filter board board Open power Check continuity of Replace continuity supply cord power supply cord Defective touch...
- Page 20 (TROUBLE 3) No microwave oscillation even though fan motor rotates. CONDITION CHECK RESULT CAUSE REMEDY No Continuity Check continuity of high microwave voltage fuse oscillation Continuity Replace Check continuity of high Defective high voltage capacitor terminals voltage trans- with wires removed former Continuity in Replace...
- Page 21 (TROUBLE 4) The following visual conditions indicate a probable defective touch control circuit or membrane switch assembly. 1. Incomplete segments (1) Segments missing (2) Partial segments missing (3) Digit flickering other than normal display slight flickering (4) :0 does not display when power is on. 2.
-
Page 22: Measurement And Test
MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000 5cc of potable water. -
Page 23: Microwave Radiation Test
2. MICROWAVE RADIATION TEST CAUTION : 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4. -
Page 24: Component Test Procedure
3. COMPONENT TEST PROCEDURE High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. It is neither necessary nor advisable to attempt measurement of the high voltage. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor. -
Page 25: Wiring Diagram
WIRING DIAGRAM... -
Page 26: Printed Circuit Board
PRINTED CIRCUIT BOARD 1. CIRCUIT CHECK PROCEDURE 1. Low Voltage Transformer check The low voltage transformer is located on the P.C.B. Measuring condition: input voltage : 120V/Frequency : 60Hz Terminal Voltage LOAD NO LOAD 5-6-7 AC 12.6 V AC 14.7 V NOTE : 1. - Page 27 Measure Point...
- Page 28 3. When there is no microwave oscillation 1) When touching START pad, oven lamp does not turn on. Fan motor does not rotate, but cook indicator in display comes on. (TRAY LAMP) - Check method POINT STATE RELAY 2 ON 5VDC RELAY 2 OFF 12VDC...
-
Page 29: Pcb Circuit Diagram
2. PCB CIRCUIT DIAGRAM... -
Page 30: Pcb Location No
Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 3. PCB LOCATION NO. NAME SYMBOL SPECIFICATION... -
Page 31: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY... - Page 32 So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). REF NO. PART CODE PART NAME DESCRIPTION Q'TY 3511719430 DOOR AS KOR-6C2B5S PKCPSWA900 CONTROL-PANEL AS KOR-6Q1B3A 3510808100 CABINET CR 0.5T 7112401011 SCREW TAPPING T1 TRS 4X10 MFZN 3516117400 CAVITY AS KOR-6NM51A 7122401211 SCREW TAPPING...
- Page 33 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : R6Q1B3A001 PRINTED DATE: Jul. 2004...
