- Page 1 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays Operations Guide...
-
Page 2: Regulatory Compliance
Inc. in the United States and/or other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. -
Page 3: Table Of Contents
Resources ..........................18 Reference Documents ....................18 Further Inquiries ......................18 Future Updates ......................18 Return and Warranty Policies ....................19 Merchandise Returns / Repair Service ..............19 Crestron Limited Warranty ..................19 Operations Guide – DOC. 7327C Contents • i... -
Page 5: V-Panel™ 24"Hd Touch Screen Displays: V24R-C
Touch Screen Displays: V24R-C Introduction ® The V-Panel™ V24R-C merges high definition Crestron touch screen control and HD video in one stylish and versatile 24” touch screen display. Its generous WUXGA screen delivers stunning video performance even at extreme viewing angles, providing an exceptional HDTV or computer display solution with integrated touch screen functionality. - Page 6 8G+ transmitter or DM switcher (all sold separately). For wiring cable up to 330 feet (~101 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or third-party CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.
- Page 7 V-Panel™ 24” HD Touch Screen Displays Smart Graphics Crestron touch screens use Smart Graphics to deliver the ultimate user experience and the ultimate value, by enabling the creation of dynamically rich user interfaces with incredible efficiency and unparalleled functionality. Using Smart Graphics,...
- Page 8 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C HDMI and Analog Video In addition to handling streaming video, the V24R-C can simultaneously display up to two fully scalable full motion video windows, each supporting HD or SD video and high resolution computer signals from external sources. All connections are ®...
-
Page 9: Applications
V24RL-C models each include (1) V-CBL-SC6 six foot (~1.8 meter) V-Cable and (1) V24-IMCW-C interface module. The V24R-WALL-C model includes no cable or interface module. For complete information, please refer to the spec sheet for each individual product or contact your Crestron representative. -
Page 10: Specifications
V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C Specifications Specifications for the V24R-C are listed in the following table. V24R-C Specifications SPECIFICATION DETAILS Touch Screen Display Display Type TFT Active Matrix Color LCD Size 24 inch (610 mm) diagonal Aspect Ratio... - Page 11 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-C Specifications (Continued) SPECIFICATION DETAILS Dimensions V24R-C Height 15.52 in (395 mm) Width 23.09 in (587 mm) Depth 2.81 in (72 mm) V24R-WALL-C Height 16.79 in (427 mm) Width 24.44 in (621 mm) Depth 3.43 in (87 mm)
- Page 12 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24R-C Specifications (Continued) SPECIFICATION DETAILS Available Accessories BB-V24 Pre-Construction Wall Mount Back Box for V24R-WALL-C BBI-V24 Wall Mount Back Box for V24R-WALL-C – International Version DGE-2 Digital Graphics Engine with HDMI and...
-
Page 13: Physical Description
Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays Physical Description This section provides information on the connections, controls and indicators available on the V24R-C. V24R-C Physical View (Shown in Black) Operations Guide – DOC. 7327C V-Panel™ 24” HD Touch Screen Displays: V24R-C • 9... - Page 14 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24RL-C Physical View (Shown in White – V24R-WALL-C is Physically Identical) V24R-C Physical View (Rear Showing Connector Ports) 10 • V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327C...
- Page 15 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-C Overall Dimensions (Front and Side Views) 23.09 in (587 mm) 2.77 in (71 mm) 15.52 in (395 mm) 15.44 in (392 mm) 2.81 in (72 mm) V24R-C Overall Dimensions (Rear View) 7.61 in...
- Page 16 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24R-WALL-C Overall Dimensions (Front View – Without Bezel) 24.14 in (613 mm) 16.48 in (419 mm) 12 • V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327C...
- Page 17 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-WALL-C Overall Dimensions (Front, Side and Bottom Views – With Bezel) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in 0.23 in (85 mm) (87 mm) (6 mm) 23.49 in...
- Page 18 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24RL-C Overall Dimensions (Front, Side and Bottom Views) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in 0.23 in (85 mm) (87 mm) (6 mm) 23.49 in...
- Page 19 V24RL-C models each include (1) V-CBL-SC6 six foot (~1.8 meter) V-Cable and (1) V24-IMCW-C interface module. The V24R-WALL-C model includes no cable or interface module. For complete information, please refer to the spec sheet for each individual product or contact your Crestron representative.
- Page 20 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C 5. Refer to the following table for the DM 8G IN connector pinouts. DM 8G IN Port PIN # WIRE COLOR PIN # WIRE COLOR Orange/White Blue/White Orange Green Green/White Brown/White Blue Brown 16 •...
-
Page 21: Setup
Setup Configuring the V-Panel To configure the V24R-C, use Crestron Toolbox™ to set up the V24R-C’s IP table entry. Then assign the address of the device with which the V24R-C is communicating (e.g., DGE-2) using device extenders that are programmed into SIMPL Windows. -
Page 22: Resources
Crestron worldwide offices on the Crestron Web site (www.crestron.com/offices) for assistance within a particular geographic region. To post a question about Crestron products, log onto the Online Help section of the Crestron Web site (www.crestron.com/onlinehelp). First-time users must establish a user account to fully benefit from all available features. -
Page 23: Return And Warranty Policies
(property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party. - Page 24 Crestron Electronics, Inc. Operations Guide – DOC. 7327C (2032855) 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 05.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
