Crestron V24-C
V-Panel™
24" HD Touch Screen Displays
Operations Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-Panel V-24-C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Crestron V-Panel V-24-C

Summary of Contents for Crestron V-Panel V-24-C

  • Page 1 Crestron V24-C V-Panel™ 24” HD Touch Screen Displays Operations Guide...
  • Page 2 Crestron, the Crestron logo, DigitalMedia, DigitalMedia 8G, DigitalMedia 8G+, DM, DM 8G+ and V-Panel are trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and other countries. Adobe, Acrobat and Flash are trademarks or registered trademarks of Adobe Systems Incorporated in the United States and/or other countries. Blu-ray Disc is a registered trademark of the Blu-ray Disc Association.

  • Page 3: Table Of Contents

    Recommended Cleaning.................... 17 Resources..........................18 Reference Documents....................18 Further Inquiries ......................18 Future Updates ......................18 Return and Warranty Policies ....................19 Merchandise Returns / Repair Service ..............19 CRESTRON Limited Warranty................. 19 Contents • i Operations Guide – DOC. 6914A...

  • Page 5: V-Panel™ 24"Hd Touch Screen Displays: V24-C

    Touch Screen Displays: V24-C Introduction ® The V-Panel™ V24-C merges high definition Crestron touch screen control and HD video in one stylish and versatile 24” touch screen display. Its generous WUXGA screen delivers stunning video performance even at extreme viewing angles, providing an exceptional HDTV or computer display solution with integrated touch screen functionality.
  • Page 6 DM-TX-201-C transmitter (sold separately). For wiring cable up to 330 feet (100 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.
  • Page 7 Crestron V24-C V-Panel™ 24” HD Touch Screen Displays Powered by Core 3* The Crestron Core 3 UI framework enables the generation of dynamically rich user interfaces with greater power and ease than ever. Core 3 lets touch screen designers ®...
  • Page 8 Native support for H.264 and MJPEG allows the V24-C and DGE-2 to display live video from a variety of Web cameras and servers such as the Crestron CEN-NVS200 Network Video Streamer . Also, through the DGE-2’s embedded Web browser and...

  • Page 9: Applications

    Crestron V24-C V-Panel™ 24” HD Touch Screen Displays Applications The following diagram shows a V24-C in a typical application. V24-C in a Typical Application V-Panel™ 24” HD Touch Screen Displays: V24-C • 5 Operations Guide – DOC. 6914A...

  • Page 10: Specifications

    V-Panel™ 24” HD Touch Screen Displays Crestron V24-C Specifications Specifications for the V24-C are listed in the following table. V24-C Specifications SPECIFICATION DETAILS Touch Screen Display Display Type TFT Active Matrix Color LCD Size 24 inch (610 mm) diagonal Aspect Ratio...
  • Page 11 V-Cable Siamese Cable, DM-8G+, 6 feet (~1.8 meters) (included with V24-C and V24L-C models only) V24-IMCW-C V-Panel Interface Module for V-24-C, DM 8G+(included with V24-C and V24L-C models only) (Continued on following page) V-Panel™ 24” HD Touch Screen Displays: V24-C • 7...
  • Page 12 V-Panel™ 24” HD Touch Screen Displays Crestron V24-C V24-C Specifications (Continued) SPECIFICATION DETAILS Available Accessories BB-V24 Pre-Construction Wall Mount Back Box for V24-WALL-C BBI-V24 Pre-Construction Wall Mount Back Box for V24-WALL-C – International Version DGE-2 Digital Graphics Engine with HDMI and...

  • Page 13: Physical Description

    Crestron V24-C V-Panel™ 24” HD Touch Screen Displays Physical Description This section provides information on the connections, controls and indicators available on your V24-C. V24-C Physical View (Shown in Black) V-Panel™ 24” HD Touch Screen Displays: V24-C • 9 Operations Guide – DOC. 6914A...
  • Page 14 V-Panel™ 24” HD Touch Screen Displays Crestron V24-C V24L-C Physical View (Shown in White – V24-WALL-C is Physically Identical) V24-C Physical View (Rear Showing Connector Ports) 10 • V-Panel™ 24” HD Touch Screen Displays: V24-C Operations Guide – DOC. 6914A...
  • Page 15 Crestron V24-C V-Panel™ 24” HD Touch Screen Displays V24-C Overall Dimensions (Front and Side Views) 23.09 in (587 mm) 2.77 in (71 mm) 15.52 in (395 mm) 15.44 in (392 mm) 2.81 in (72 mm) V24-C Overall Dimensions (Rear View) 3.94 in...
  • Page 16 V-Panel™ 24” HD Touch Screen Displays Crestron V24-C cover by first removing the four screws holding it in place. Replace the cover when connections have been made. V24-WALL-C Overall Dimensions (Front View – Without Bezel) 24.14 in (613 mm) 16.48 in (419 mm) 12 •...
  • Page 17 Crestron V24-C V-Panel™ 24” HD Touch Screen Displays V24-WALL-C Overall Dimensions (Front, Side and Bottom Views – With Bezel) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in 0.23 in (85 mm) (87 mm) (6 mm) 23.49 in...
  • Page 18 V-Panel™ 24” HD Touch Screen Displays Crestron V24-C V24L-C Overall Dimensions (Front, Side and Bottom Views) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in (85 mm) 0.23 in (87 mm) (6 mm) 23.49 in...
  • Page 19 DM-TX-201-C transmitter (sold separately). For wiring cable up to 330 feet (100 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.
  • Page 20 V-Panel™ 24” HD Touch Screen Displays Crestron V24-C 6. Refer to the following table for the DM 8G IN connector pinouts. DM 8G IN Port PIN # WIRE COLOR PIN # WIRE COLOR Orange/White Blue/White Orange Green Green/White Brown/White Blue Brown 7.

  • Page 21: Setup

    NOTE: The V24-C features a DM 8G+™ type input. Connection to a DGE-2 or DVPHD requires a DM-TX-201-C transmitter (sold separately). For wiring cable up to 330 feet (100 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.

  • Page 22: Resources

    Crestron Web site (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron Web site (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.

  • Page 23: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures.
  • Page 24 Crestron Electronics, Inc. Operations Guide – DOC. 6914A 15 Volvo Drive Rockleigh, NJ 07647 (2030370) Tel: 888.CRESTRON 06.11 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
