  • Page 1 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays Operations Guide...

  • Page 2: Regulatory Compliance

    The specific patents that cover Crestron products are listed at www.crestronpatents.com. Crestron, the Crestron logo, Crestron Toolbox, Core 3, Core 3 UI, DigitalMedia, DigitalMedia 8G, DigitalMedia 8G+, DM, DM 8G+, SmartObjects, SmartScaling and V-Panel are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries.

  • Page 3: Table Of Contents

    Recommended Cleaning.................... 17 Resources..........................18 Reference Documents....................18 Further Inquiries ......................18 Future Updates ......................18 Return and Warranty Policies ....................19 Merchandise Returns / Repair Service ..............19 Crestron Limited Warranty..................19 Contents • i Operations Guide – DOC. 7327A...

  • Page 5: V-Panel™ 24"Hd Touch Screen Displays: V24R-C

    Touch Screen Displays: V24R-C Introduction ® The V-Panel™ V24R-C merges high definition Crestron touch screen control and HD video in one stylish and versatile 24” touch screen display. Its generous WUXGA screen delivers stunning video performance even at extreme viewing angles, providing an exceptional HDTV or computer display solution with integrated touch screen functionality powered by the groundbreaking Core 3 UI™.
  • Page 6 8G+ transmitter or DM switcher (all sold separately). For wiring cable up to 330 feet (~101 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.
  • Page 7 V-Panel™ 24” HD Touch Screen Displays Powered by Core 3 Crestron touch screens have always offered the ultimate user experience. With Core 3™, they also deliver the ultimate value, enabling the creation of dynamically rich user interfaces with incredible efficiency and unparalleled functionality. Using Core...
  • Page 8 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C HDMI and Analog Video In addition to handling streaming video, the V24R-C can simultaneously display up to two fully scalable full motion video windows, each supporting HD or SD video and high resolution computer signals from external sources. All connections are ®...

  • Page 9: Applications

    8G+ transmitter or DM switcher (all sold separately). For wiring cable up to 330 feet (~101 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.

  • Page 10: Specifications

    V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C Specifications Specifications for the V24R-C are listed in the following table. V24R-C Specifications SPECIFICATION DETAILS Touch Screen Display Display Type TFT Active Matrix Color LCD Size 24 inch (610 mm) diagonal Aspect Ratio...
  • Page 11 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-C Specifications (Continued) SPECIFICATION DETAILS Dimensions V24R-C Height 15.52 in (395 mm) Width 23.09 in (587 mm) Depth 2.81 in (72 mm) V24R-WALL-C Height 16.79 in (427 mm) Width 24.44 in (621 mm) Depth 3.43 in (87 mm)
  • Page 12 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24R-C Specifications (Continued) SPECIFICATION DETAILS Available Accessories BB-V24 Pre-Construction Wall Mount Back Box for V24R-WALL-C BBI-V24 Wall Mount Back Box for V24R-WALL-C – International Version DGE-2 Digital Graphics Engine with HDMI and...

  • Page 13: Physical Description

    Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays Physical Description This section provides information on the connections, controls and indicators available on your V24R-C. V24R-C Physical View (Shown in Black) V-Panel™ 24” HD Touch Screen Displays: V24R-C • 9 Operations Guide – DOC. 7327A...
  • Page 14 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24RL-C Physical View (Shown in White – V24R-WALL-C is Physically Identical) V24R-C Physical View (Rear Showing Connector Ports) 10 • V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A...
  • Page 15 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-C Overall Dimensions (Front and Side Views) 23.09 in (587 mm) 2.77 in (71 mm) 15.52 in (395 mm) 15.44 in (392 mm) 2.81 in (72 mm) V24R-C Overall Dimensions (Rear View) 7.61 in...
  • Page 16 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24R-WALL-C Overall Dimensions (Front View – Without Bezel) 24.14 in (613 mm) 16.48 in (419 mm) 12 • V-Panel™ 24” HD Touch Screen Displays: V24R-C Operations Guide – DOC. 7327A...
  • Page 17 Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays V24R-WALL-C Overall Dimensions (Front, Side and Bottom Views – With Bezel) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in 0.23 in (85 mm) (87 mm) (6 mm) 23.49 in...
  • Page 18 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C V24RL-C Overall Dimensions (Front, Side and Bottom Views) 24.44 in (621 mm) 16.79 in 15.78 in (427 mm) (401 mm) 3.32 in 3.43 in (85 mm) 0.23 in (87 mm) (6 mm) 23.49 in...
  • Page 19 8G+ transmitter or DM switcher (all sold separately). For wiring cable up to 330 feet (~101 meters) in length, use Crestron DM-CBL-8G DigitalMedia 8G cable or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise, which may impact performance.
  • Page 20 V-Panel™ 24” HD Touch Screen Displays Crestron V24R-C 6. Refer to the following table for the DM 8G IN connector pinouts. DM 8G IN Port PIN # WIRE COLOR PIN # WIRE COLOR Orange/White Blue/White Orange Green Green/White Brown/White Blue Brown 16 •...

  • Page 21: Setup

    Crestron V24R-C V-Panel™ 24” HD Touch Screen Displays Setup Configuring the V-Panel To configure the V24R-C, use Crestron Toolbox™ to set up the V24R-C’s IP table entry. Then configure touch using Device Extenders that are programmed into SIMPL Windows. Hardware Hookup Ventilation The V24R-C should be used in a well-ventilated area.

  • Page 22: Resources

    Crestron Web site (www.crestron.com/offices) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron Web site (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.

  • Page 23: Return And Warranty Policies

    (property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party.
  • Page 24 Crestron Electronics, Inc. Operations Guide – DOC. 7327A 15 Volvo Drive Rockleigh, NJ 07647 (2032855) Tel: 888.CRESTRON 12.11 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
