FS-527 (d-Color MF360/MF280/MF220)
I. Accessory parts ................................................................................................................. 1
II. Confirmation before installation .......................................................................................... 2
III. Installation procedures ....................................................................................................... 3
FS-527 (d-Color MF451)
I. Accessory parts ................................................................................................................. 9
II. Confirmation before installation ........................................................................................ 10
III. Installation procedures ..................................................................................................... 11
Y111090-1
FS-527
INSTALLATION MANUAL
E-i
Finisher
Installation Manual
Advertisement
Related Manuals for Olivetti FS-527
Summary of Contents for Olivetti FS-527
-
Page 1: Table Of Contents
FS-527 Finisher INSTALLATION MANUAL Index FS-527 (d-Color MF360/MF280/MF220) I. Accessory parts ......................... 1 II. Confirmation before installation ..................2 III. Installation procedures ....................... 3 FS-527 (d-Color MF451) I. Accessory parts ......................... 9 II. Confirmation before installation ..................10 III. Installation procedures ..................... 11... - Page 2 This page is intentionally left blank. Installation Manual E-ii Y111090-1...
-
Page 3: Accessory Parts
FS-527 Finisher INSTALLATION MANUAL Applied Machines: d-Color MF360/MF280/MF220 COLOR MFP: 36 ppm/28 ppm/22 ppm Product Code: A0ED Caution: Name Shape Q’ty Lifting the machine in an awkward position or 7. Mounting transporting it in a poorly balanced position could bracket E result in personal injury. -
Page 4: Confirmation Before Installation
II. Confirmation before installation 1. To move the finisher, be sure to push it in the directions of the arrows as shown in the illustra- tion. (Precaution against falling of the finisher). After unpacking, be sure to get rid of the packaging materials and keep them out of the reach of children. -
Page 5: Iii. Installation Procedures
III. Installation procedures 5. Remove the cover from the main body as shown in the illustration (one screw). 1. Turn off the machine and unplug the power cord from the power outlet. 2. Remove the user’s guide holder from the machine. - Page 6 8. Attach the furnished mounting plate E to the left 10. Remove the locking tapes and the locking pro- side bottom of the main body (one furnished tection materials from the finisher. screw C). Note: Push the mounting plate E upward when screwing the plate to the main body.
- Page 7 12. Connect the two horizontal transport unit con- 15. Push the lever pulled in step 13 back to its origi- nectors to the connectors located at the rear of nal position. Align the mounting hole on the lever the right side of the finisher. Secure the cord with with the screw hole on the finisher, and then a cord clamp.
- Page 8 (3) Remove the cover from the caster located on (6) Adjust the height of the four casters to align the the front side of the finisher (one screw). mark on the lever with the screw hole on the finisher. A0HRIXC033DA A0HRIXC036DA (4) Remove the rear cover from the finisher (10 screws).
- Page 9 16. Insert exit tray into the sub tray paper exit slot on the finisher. A0HRIXC037DA 17. Connect the hookup cord of the horizontal trans- port unit to the machine. A0HRIXC038DA 18. Install the user’s guide holder removed in step 2 as shown in the illustration.
- Page 10 This page is intentionally left blank. Y111090-1 Installation Manual...
-
Page 11: Accessory Parts
FS-527 Finisher INSTALLATION MANUAL Applied Machine: d-Color MF451 COLOR MFP: 45 ppm Product Code: A0P2 Caution: Name Shape Q’ty Lifting the machine in an awkward position or 7. Mounting transporting it in a poorly balanced position could bracket E* result in personal injury. When transporting the... -
Page 12: Confirmation Before Installation
II. Confirmation before installation 1. To move the finisher, be sure to push it in the directions of the arrows as shown in the illustra- tion. (Precaution against falling of the finisher). After unpacking, be sure to get rid of the packaging materials and keep them out of the reach of children. -
Page 13: Iii. Installation Procedures
III. Installation procedures 6. Remove the protective tapes of the horizontal transport unit. 1. Turn off the machine and unplug the power cord from the power outlet. 2. Remove the user’s guide holder from the machine. A0HRIXC015DA 7. Remove the guide plate from the horizontal trans- port unit (two screws). - Page 14 9. Attach the furnished guide plate B to the horizon- 12. Attach the furnished mounting plates A (left) and tal transport unit (two screws). B (right) to the upper left side of the main body (two furnished screw A’s each). Note: Use the screws removed in step 7.
- Page 15 14. Remove the locking tapes and the locking pro- 16. Connect the two horizontal transport unit con- tection materials from the finisher. nectors to the connectors located at the rear of the right side of the finisher. Secure the cord with a cord clamp.
- Page 16 19. Push the lever pulled in step 17 back to its origi- (3) Remove the cover from the caster located on nal position. Align the mounting hole on the lever the front side of the finisher (one screw). with the screw hole on the finisher, and then screw the lever to the finisher (one furnished mounting screw).
- Page 17 (6) Adjust the height of the four casters to align the 20. Insert exit tray into the sub tray paper exit slot on mark on the lever with the screw hole on the the finisher. finisher. A0HRIXC037DA A0HRIXC036DA 21. Connect the hookup cord of the horizontal trans- port unit to the machine.
