POS-X ION User Manual

Fit pos terminal
Hide thumbs Also See for ION:
Table of Contents

Advertisement

Quick Links

Download this manual
1975 Midway Lane, Suite O
Bellingham, WA 98226
sales@pos-x.com
360.738.8433
www.pos-x.com
POS-X Warranty
Industry-leading Warranty Protection
• 3 year warranty
• *2-day Advance Exchange - standard on all products
• Warranty extensions and overnight exchanges are available
to provide means to further reduce the total cost of
ownership
Fit POS Terminal
*Available in USA and Canada
User Manual
POS-X Service and Support
24/7 Technical Support and Lifetime Customer Support
• 24/7 access to our USA-based experienced technical
support representatives
• Support techs utilize advanced techniques such as
remote access for quick and accurate system analysis
• Lifetime support on all POS-X products
Version 1.0 August 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POS-X ION

Summary of Contents for POS-X ION

  • Page 1 • Warranty extensions and overnight exchanges are available • Support techs utilize advanced techniques such as to provide means to further reduce the total cost of remote access for quick and accurate system analysis ownership • Lifetime support on all POS-X products *Available in USA and Canada...
  • Page 2 Copyright 2014 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.

  • Page 5: Revision History

    Revision History Revision Date Description V1.0 March, 2014  Release...

  • Page 6: Table Of Contents

    Table of Contents 1 Item Checklist..........1 Standard Items................1 Optional Items ................2 2 System View...........3 Front View & Side View ..............3 Rear View ..................4 Dimension..................4 I/O View................... 5 3 System Assembly & Disassembly....7 Install the Power Adapter............... 7 Replace the HDD................

  • Page 7: Item Checklist

    Item Checklist Standard Items Power adapter (65W) COM-RJ45 cable (x2) f. USB Extension cable v i r...

  • Page 8: Optional Items

    Optional Items c. Customer display d. 2 display c. 15” Customer display...

  • Page 9: System View

    System View Front View & Side View Description l i t...

  • Page 10: Rear View

    Rear View Description MSR /Fingerprint dummy cover Dimension...

  • Page 11: I/O View

    I/O View C56L Motherboard Number Description Cash drawer USB x 4 (USB2.0) COM1~4 (from left to right) DC Jack 19V Power button Printer...
  • Page 12 D36 Motherboard Number Description Cash drawer USB x 4 (USB2.0) COM1~3 (from left to right) DC Jack 19V Power button USB (USB2.0) USB (USB3.0) Printer...

  • Page 13: System Assembly & Disassembly

    System Assembly & Disassembly Install the Power Adapter The system is equipped with a 65W or 90W power adapter. Please plug it into the system as shown below. Place the system face down. Make sure not to scratch the monitor. You will find the I/O panel located at the bottom of the stand.

  • Page 14: Open The System

    Hold the plastic tab and pull the HDD outward. To remove the HDD module pull the ejector clips out of the side of the module. Open the System Use both hands to pull the top cover of the stand outwards. Remove the screw as shown in the picture.

  • Page 15: Replace The Ram

    Disconnect the LCD cables (x2). Lay the system on its back to access the bottom of the system. Pull the motherboard tray towards you by the handle Replace the RAM Follow the steps described in Chapter 3-3 to open the system. Find the RAM location on the motherboard (refer to Chapter 6-1-1 and).

  • Page 16: Peripherals Installation

    Peripherals Installation Install the MSR Module MSR module can be installed to either side of the system. Choose one side and follow the steps below. Make sure the unit is powered down before starting. Remove the dummy cover first. Connect the MSR cable to the connector on the system side. Remove the M3*6 screws (must be done before inserting the MSR module).

  • Page 17: Install The Fingerprint Module

    Install the Fingerprint Module Remove the dummy cover first. Remove the M3*6 screws (x2). Fix the hex standoffs (x2) to the screw hole as shown in the picture. Connect the fingerprint cables to the connector on the system side. Insert the fingerprint module in place and fasten the M3*4 screws (x2) on the back to secure the module.

  • Page 18: Install The Customer Display

    Install the Customer Display Use both hands to pull the top cover of the stand upwards. Release the plastic plate from the top cover. Put the top cover of the stand back to the position. Connect the customer display cable (x1) to the connector on system side and fasten the ground cable (x1) with a M3*4 screw.

  • Page 19: Install The 2Nd Display

    Install the 2nd Display Use both hands to pull the top cover of the stand upwards. Remove the M3*8 screws (x2) as shown in the picture. Connect the 2 display cables (x1) to the connector on system side. Attach the 2 display and fasten screws (x4).

  • Page 20: Install The Cash Drawer

    Install the Cash Drawer You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 21 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 22: Specification

    Integrated rear display, 8.4” ION-RD3-LCD8 (213mm) LCD, VGA Integrated 15” (381mm) Bezeled ION-RD3-LCD15A Rear LCD Integrated 15” (381mm) TruFlat ION-RD3-LCD15C Rear LCD ION Integrated U.are.U 4500 ION-BR3 BIO Reader WARRANTY EXTENSION AND UPGRADES ZWE-TPC 2-Year Warranty Extension ZOE-TPC3 *3-Year Overnight Exchange ZOE-TPC5...

  • Page 23: Jumper Setting

    Jumper Setting C56L Motherboard 6-1-1 Motherboard Layout...
  • Page 24 6-1-2 Connectors & Functions Connector Function LVDS inverter connector System FAN connector LVDS connector Power LED connector HDD LED connector Speaker & MIC connector SATA power connector COM5 (touch) connector CN10 Printer port connector CN11/12 USB port (internal) CN14 PS2 keyboard connector CN15 MSR Connector CN17...
  • Page 25 6-1-3 Jumper Setting Inverter Selection Function (1-2) (3-4) ▲LED CCFL Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V VGA Power Setting Function JP10 (1-2) ▲+0V +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 26 MSR/PS2 Keyboard Power Setting Function JP11 (1-2) (3-4) ▲MSR + PS2 Keyboard Only PS2 COM 3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) ▲COM3 +0V COM3 +5V COM3 +12V COM4+ 5V ▲COM4 +12V ▲ = Manufacturer Default Setting OPEN SHORT...
  • Page 27 LCD ID Setting Panel LVDS Output Resolution Number (1-2) (3-4) (5-6) (7-8) (9-10) Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 600 Single Panel LVDS 1024 x 768 Single...

  • Page 28: D36 Motherboard

    D36 Motherboard 6-2-1 Motherboard Layout...
  • Page 29 6-2-2 Connectors & Functions Connector Function Front I/O board Inverter connector LVDS connector System FAN connector LPT port connector Speaker & MIC connector 40pin external connector CN10 HDD LED connector CN11 Power LED connector CN12 SATA power connector CN13/14 USB port (internal) CN15 PS2 keyboard connector CN16...
  • Page 30 6-2-3 Jumper Setting Inverter Selection Function (1-2) (3-4) ▲LED CCFL Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V LCD ID Setting Panel LVDS Output Resolution Number (1-2) (3-4) (5-6) (7-8) (9-10) Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600...
  • Page 31 LVDS 1024 x 600 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. The voltage can be set to +5V or 12V in the BIOS.
  • Page 32 To enable the power, select COM1 , COM2 or COM3 Power setting and press <Enter>. Select Power and press <Enter>. Save the change by pressing F10.

  • Page 33: Appendix: Driver Installation

    Please insert the Driver CD into a computer with a CD drive and double click on the “index.htm” to pick the models. You can refer to the drivers installation guide for each driver in the “Driver/Manual List”. For more information please visit www.pos-x.com 1975 Midway Lane, Suite O Bellingham, WA 98226 sales@pos-x.com...
