  • Page 1 USER MANUAL VERSION 1.2 December 2012 EVO-TP4 Hardware System...

  • Page 2: Important Safety Instructions

    Copyright 2012 All Rights Reserved Manual Version 1.2 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Battery Caution

    CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive” . This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 5: Revision History

    Revision History Revision Description Date • Initial release November, 2010 • C68 M/B added November, 2011 • C58 M/B added December, 2012...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Accessories .............1 1-2. Optional Accessories ............2 2. System View ........3 2-1. Front & Side View ............3 2-2. Rear View with stand ............3 2-3. I/O Ports View ..............4 2-4. System Dimension ............5 3.
  • Page 7 6. Jumper Setting ......18 6-1. C68 Motherboard ............18 6-1-1. Motherboard Layout ...........18 6-1-2. Connectors & Functions ........19 6-1-3. Jumper Setting ...........20 6-2. C58 Motherboard ............25 6-2-1. Motherboard Layout ...........25 6-2-2. Connectors & Functions ........26 6-2-3. Jumper Setting ...........27 Appendix: Drivers Installation ....29...
  • Page 8 The page is intentionally left blank. viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Accessories System (with stand) Power Adapter Power cord RJ45-DB9 cable (x3) Cable cover Driver CD...

  • Page 10: Optional Accessories

    1-2. Optional Accessories MSR module Second display (with VGA cable) VFD module (with RJ-45 cable) Wall mount kit...

  • Page 11: System View

    System View 2-1. Front & Side View Item No. Description Touch screen MSR module (optional) Rugged footprint Ventilation HDD door 2-2. Rear View with stand Item No. Description VFD dummy cover MSR dummy cover...

  • Page 12: I/O Ports View

    2-3. I/O Ports View C58 Motherboard e f g Item No. Description Power button USB x 4 COM 1, 2, 3, 4 (from right to left) Mic-in Line-out Cash drawer Power switch DC-IN Parallel C68 Motherboard f g h i j k a b c Item No.

  • Page 13: System Dimension

    2-4. System Dimension 361mm 248mm...

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly 3-1. Stand Disassembly 1. Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. 2. Reverse the steps above to attach stand to the system. 3-2. Power Adapter Replacement Power adapter is secured to the system stand by a holding bracket and screws.

  • Page 15: Hd Replacement

    3-3. HD Replacement Please remove the current HDD first. To remove the HDD from the System: 1. Power the system down. 2. Remove the screw(x1) from the HDD door. 3. Open the HDD door. 4. While pinching the HDD bracket tabs pull the HDD from the system.
  • Page 16 2. To install a new HDD. Attach the HDD to the bracket until it clicks in place. Make sure to press the edges of the drive not the center to avoid damaging the drive. 3. Finally slide the HDD into the slot till it clicks.

  • Page 17: Peripheral Installation

    Peripheral Installation 4-1. MSR Installation MSR module can be installed to either side of the system. Choose one side and follow the steps below. Make sure the unit is powered down before starting. 1. Remove the screws (x2) to release the MSR dummy cover.

  • Page 18: Vfd Installation

    4-2. VFD Installation 1. Follow steps in Chapter 3-1 to disassemble the system stand. 2. Attach the VFD module to system by fastening the screws (x2). 3. Route the cable through cable mangement on the system stand. 4. Connect the RJ-45 cable to COM 4 on the systems IO panel. Make sure the system is powered off.

  • Page 19: Second Display Installation

    4-3. Second Display Installation 1. Follow steps in Chapter 3-1 to disassemble the system stand. 2. Connect one end of the VGA cable to 2nd Display. Route the cable through cable mangement on the system stand. 3. Attach the 2nd Display to system by fastening the screws (x2). 4.

  • Page 20: Wall Mounting Kit Installation

    4-4. Wall Mounting Kit Installation The wall mounting Kit includes a wall plate, a metal bracket, and one screw. (refer to Chapter 1-2 item d) Please follow the steps below. 1. Secure the wall plate to the wall by fastening screws (x4). 2.

  • Page 21: Cable Cover Installation

    4. Fasten the screw (x1) through the metal bracket to secure the wall mount kit. 4-5. Cable Cover Installation There are two different cable covers. These can be utilized separately or together. When both are needed, please take care that they are installed in the correct order. 1.

  • Page 22: Cash Drawer Installation

    4-6. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 23 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 24: Specification

    Specification Intel Sandy Bridge CPU Intel CedarView D2550 1.86GHz, L2 i3-2120 3.3G, L2 3M, 65W CPU Support 1M, 10W Pentium G850 2.9G, L2 3M, 65W Celeron G530 2.4G, L2 2M, 65W Intel Q67 PCH (Processor Controller Hub, AMT supported_highend) Intel H61 PCH (Processor Controller Hub, no AMT suport_mainstream) 2 x DDR3 SO-DIMM up to 4GB, 1 x Long DIMM slot up to 8GB...
  • Page 25 Storage Humidity 20% ~ 85% RH non condensing Dimension (WxDxH) LCD 90 degree : 361 x 248 x 337 mm Weight (N.W./G.W.) 7kgs / 8kgs Mounting 100mm x100mm VESA mounting holes for Panel PC type Windows® XP Professional, Windows Windows XP, POS Ready 2009, Embedded POSReady 2009, Windows XP XP Embedded, XP professional for OS Support...

  • Page 26: Jumper Setting

    Jumper Setting 6-1. C68 Motherboard 6-1-1. Motherboard Layout PWR1 CN18 PWR3 MINI_PCIE1 RJ45_1 CN19 RJ11_1 CN15 JP14 CN21 CN16 JP10 JP13 DDR3_A1 SATA2 RJ45_2 FAN_CPU1 CN10 CN11 SATA1 SKT1 JP11 JP12 USB1 CN14 USB2 CN12 CN13 CN17 PRN1 CN20 FAN_SYS1 JP15 Version: C68 v1.0...

  • Page 27: 6-1-2. Connectors & Functions

    6-1-2. Connectors & Functions Connector Function CN1/2 SATA power Connector LVDS Connector LVDS INVERTER Connector SATA HDD LED Connector DVI Connector BATTERY Connector FT STATUS INTERFACE CN10/11 USB Port(Internal) CN12 Card Reader Connector(COM6) CN13 RF Connector CN14 COM5 for Touch CN15 SPEAKER &...

  • Page 28: 6-1-3. Jumper Setting

    6-1-3. Jumper Setting Power Mode Setting Function ▲ATX Power AT Power COM2 RS232/485/422 Setting Function JP10 JP13 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10...
  • Page 29 Inverter Selection Function CCFL ▲LED ME Update Function ▲Lock Un-lock Hardware Reset Function ▲System Normal System Reset USB Touch Power Setting for CN11 Connector Function JP11 ▲+5VSB Jumper open Jumper short ▲ = Manufacturer Default Setting...
  • Page 30 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 31 4. To switch on the power, select "Power". Please save the change before exiting BIOS so as to go for physical jumper adjustment. COM3/COM4 Jumper setup Function JP12 ▲+5V COM3 +12V COM4 ▲+12V...
  • Page 32 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel 800 x 600 Single 800 x 600 Single 1024 x 768 Single 1024 x 768 Single LVDS Panel 1280 x 1024 Dual 1366 x 768 Single 1440 x 900 Dual 1920 x 1020 Dual Remark:...

  • Page 33: C58 Motherboard

    6-2. C58 Motherboard 6-2-1. Motherboard Layout PWR1/PWR2 CN13 CN21 MINI_PCIE1 SKT1 RJ45_1 RJ11_1 CN4 CN3 CN23 CN10 CN22 CN19 CN16 CN12 CN11 SATAT2 COM1_1 SATAT1 CN17 USB1 USB2 PRN1 DDR3_A1 DDR3_A2 CN18 CN20 CN15 Version: C58 v1.0...

  • Page 34: Connectors & Functions

    6-2-2. Connectors & Functions Connector Function CN1/CN2 SATA Power CONN Inverter Selection Card Reader COM5 Touch LVDS PS2 K/B CN9/CN10 CN11 STAT LED CN15 Touch Sensor CN17 Power LED CN19 Speaker & MIC-IN CN20 Power Button CN21 Power Adaptor CONN CN22 Line-out CN23...

  • Page 35: Jumper Setting

    6-2-3. Jumper Setting Inverter Selection Function CCFL ▲LED Cash Drawer Power Setting Function ▲+19V +12V Jumper open Jumper short ▲ = Manufacturer Default Setting...
  • Page 36 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel 800 x 600 Single 800 x 600 Single 800 x 600 Single 800 x 600 Single 1024 x 600 Single 1024 x 768 Single LVDS Panel 1024 x 768 Single 1280 x 1024 Dual 1366 x 768...

  • Page 37: Appendix: Drivers Installation

    Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
