- Page 1 Install Manual PTZ Dome Camera served for D&N; D&N D&N <grade> <version> V2.2 Please read this manual carefully before using, and save this manual for future reference QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 2: Table Of Contents
Alarm I/O ………………….. IR-in (Remote Control) Applications ………………….. Controllers and RS485 ………………….. ………………….. Connect a single dome ………………….. Connect two or more domes Advanced Setting -Preset function ………………….. Specification ………………….. Mounting Accessory ………………….. QMD Install manual D06400210010G PTZ Dome Camera... - Page 3 This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. ATTENTION Cet appareil numerique de laclasse B respects toutes les exigencies du Reglement sur le materiel brouilleur du Canada QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 4: Preface
Most of the image related functions (such as DSP functions, lens functions, special effects of video…) are managed via OSD (On-Screen-Display) menu. These functions are explained in a separate manual entitled OSD Menu. QMD Install manual D06400210010G PTZ Dome Camera... -
Page 5: Product Appearance
Compatible with PC and video server for WAN / LAN surveillance 12V DC or 24V AC power input (AC24V for outdoor housing) Embedded, surface, wall and ceiling mount External housing for outdoor environment (Option) QMD Install manual D06400210010G PTZ Dome Camera... -
Page 6: Access The Dip Switches
Appearance camera module QMD Install manual D06400210010G PTZ Dome Camera... -
Page 7: Basic Setup
Use pencil, pincer, paper clip or small flat screw driver to move the lever of DIP switch To access DIP switches Access points: 3 sets of DIP switch are located on the bottom of the cameras: DIP switches QMD Install manual D06400210010G PTZ Dome Camera... -
Page 8: Device Id
Refer to the picture on below for DIP switch locations. The following paragraphs are providing the detail descriptions of the three main setups. Installer should read it with care, before starts doing the hardware mounting and cabling work. QMD Install manual D06400210010G PTZ Dome Camera... - Page 9 ID of each camera onto its corresponding location on the site map, and make out a list of cameras with their ID numbers. The DIP switch pin assignment for ID setup is in binary format. QMD Install manual D06400210010G PTZ Dome Camera...
- Page 10 QMD Install manual D06400210010G PTZ Dome Camera on on on on on on...
- Page 11 158 on on on on 190 on on on on on on on on on on on on on on 160 on on on on on 192 on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 12 QMD Install manual D06400210010G PTZ Dome Camera...
- Page 13 286 on on on on 318 on on on on on on on on on on on on on on 288 on on on on on 320 on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 14 382 on on on on on on on on on on on on on on on on 352 on on on on on 384 on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 15 416 on on on on on on on 448 on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 16 511 -- on on on on on on on on 480 on on on on on on on on 512 on on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 17 542 on on on on 574 on on on on on on on on on on on on on on 544 on on on on on 576 on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 18 638 on on on on on on on on on on on on on on on on 608 on on on on on 640 on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 19 670 on on on on 702 on on on on on on on on on on on on on on 672 on on on on on 704 on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 20 735 -- on on on on on on 767 -- on on on on on on on 736 on on on on on on on 768 on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 21 800 on on on on on on on on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 22 864 on on on on on on on 896 on on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 23 928 on on on on on on on on 960 on on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
- Page 24 992 on on on on on on on on on 1024 on on on on on on on on on on QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 25: Control Protocol And Baud Rate
The following table shows the 6 protocols provided in this camera. Check what are available in the controller before choosing the protocol. Protocol Pelco-D & P Li-lin Danycolor Hunda Samsung note: Pelco D/P use the same pin for assignment. They are auto-recognized from QMD Install manual D06400210010G PTZ Dome Camera... -
Page 26: Rs485 Network And Impedance
90 to 250 ohms). Terminators are to be located at both ends of each RS-485 net..120Ω 120Ω ..120Ω 120Ω Main controller QMD Install manual D06400210010G PTZ Dome Camera... - Page 27 Most PC and notebook sort of devices have RS232 or USB ports but no RS485. Therefore, for PC system, a RS232 or USB to RS485 converter is needed. Installer must check out if the converter has proper terminator resistor. QMD Install manual D06400210010G PTZ Dome Camera...
- Page 28 In such circumstances the usage of RS485 distributor is recommended. The distributor can change the star configuration connection to the mode of connection stipulated in the RS485 standards. The new connection achieves reliable data transmission. RS485 distributor QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 29: Mount The Dome Camera
For all these five mounting ways, a common mounting base for mechanical locking and signal interface shall be adapted (referred to the picture under). In the page 55 there is a list of all the accessories provided with the camera for various environments. QMD Install manual D06400210010G PTZ Dome Camera... -
Page 30: Surface Mount
Make holes on the wall, then insert the supplied plastic plugs into the holes and squeeze them in until they are flush with the wall surface. Mount the base on the desired place tightly with screws QMD Install manual D06400210010G PTZ Dome Camera... -
Page 31: Embedded
Put the camera through out the hole Align the screw holes of the decoration ring and the auxiliary bracket Put screws through and tighten the two brackets, with the ceiling in between QMD Install manual D06400210010G PTZ Dome Camera... -
Page 32: Ceiling-Drop And Wall-Mount
Then rotate the camera body counter-clockwise until it is completely locked Put the safety screw in locking position and (anti-loss) screw it in QMD Install manual D06400210010G PTZ Dome Camera... - Page 33 Then rotate the camera body counter-clockwise until it is completely locked Put the safety screw in locking position. (anti-loss) QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 34: Use External Housing
Load the camera to housing from the opening of housing. Be sure the connectors are well mated and then rotate the camera to lock it in position Put the safety screw in locking position and tight it Finished device QMD Install manual D06400210010G PTZ Dome Camera... -
Page 35: Outlook And Measurements
10 inches (262mm). It has diameter of 8-9/16 inches (219mm) for the outer housing and 6 inches (150mm) for the dome cover. Total weight of this device is 4 kg without camera, and 5.4kg with camera. Φ 152 Φ 219 Fig. 4 QMD Install manual D06400210010G PTZ Dome Camera... -
Page 36: Mounting-Holders
Two different holders and their accessories are supplied with the camera 7.3.1 For Wall-mount --- crane type bracket Fig. 5 Fig. 6 7.3.2 For Ceiling-mount (optional) --- cane type bracket Φ 7 Fig-7 Fig-8 QMD Install manual D06400210010G PTZ Dome Camera... -
Page 37: Mount The Bracket And Housing
Be sure the wall is strong enough to hold the entire device (i.e. housing + camera) Fig-9 Fig-10 Fig-11 Fasten the housing to the bracket with supplied screws （Fig-12） Fig-12 。 Put the cover back to holder （Fig-13） Fig-13 QMD Install manual D06400210010G PTZ Dome Camera... -
Page 38: Put Camera Back To Housing
Take hands back off camera very slowly to ensure it is fully integrated to the housing. If the camera moves, shakes or drops down after your hands are off, hold it quickly, rotate it counter-clockwise to release it from the housing and re-do the integration. Fig-15 QMD Install manual D06400210010G PTZ Dome Camera... - Page 39 （Fig-16） (only for 10x zoom version) Fig-16 Put The housing dome cover in place, rotate it clockwise until it is fully tied to the housing （Fig-17） Close Fig-17 QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 40: Connecting Wires
IR in (Infra Red Remote Control) They are easily distinguished from one to another, as being featured with different connectors. Refer to the picture on below to learn about cable and connector information. QMD Install manual D06400210010G PTZ Dome Camera... -
Page 41: Power
As soon as power is supplied, the speed dome will enter “initial check” mode, and automatically run through the following procedures: Move the lens around automatically for system check and calibration Then the camera will show normal image and get ready for control QMD Install manual D06400210010G PTZ Dome Camera... -
Page 42: Video
The RS485 communication may run for 4,000 feet if the system network is properly built. Two important factors should be handled with care during the system build-up--- baud rate and termination impedance. More information about RS485 are in sections “Protocol and Baud rate” and “Applications”. QMD Install manual D06400210010G PTZ Dome Camera... -
Page 43: Alarm I/O
At the trigger of alarm-in number 6, lens will move to preset 22. At the trigger of alarm-in number 7, lens will move to preset 23. At the trigger of alarm-in number 8, lens will move to preset 24. QMD Install manual D06400210010G PTZ Dome Camera... - Page 44 5 seconds and keeps the same movement in sequence until the 60 second time segment is over. Camera will be back to its original position after the 60 seconds. QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 45: Ir-In (Remote Control)
Point to the receiver with handset and press the function button to make control to the camera. <be sure batteries are installed to the handset before using> QMD Install manual D06400210010G PTZ Dome Camera... -
Page 46: Applications
Check the PC first to see if RS232 port or USB port is available to the specific unit. Some may have both while others only have one of the two. If you need the RS232 or USB to RS485 converter, check with your camera supplier for the information. QMD Install manual D06400210010G PTZ Dome Camera... -
Page 47: Connect A Single Dome
Select proper control protocol and baud rate at the controller and the speed dome. Be sure both sides have the same protocol and baud (camera / controller) rate. Connect to keyboard + monitor Connect to keyboard + MUX QMD Install manual D06400210010G PTZ Dome Camera... - Page 48 (PTZ camera and DVR) have the same protocol and baud rate. In case the DVR does not have PTZ control function, use a separate keyboard for the PTZ controlling. Protocol shall be properly selected, too. QMD Install manual D06400210010G PTZ Dome Camera...
- Page 49 Stop bit is “ ” (one) You should be able to control to the camera after these are correctly set up. For advanced functions, follow the instructions given by the video server manual. QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 50: Connect Two Or More Domes
To connect more cameras, copy the same procedure on above. You may continue extending the quantity of camera to its maximum number of 128 per network, if the control device has the capability of addressing that many ID.. Extension box QMD Install manual D06400210010G PTZ Dome Camera... - Page 51 RS485 network ( watch the difference of impedance setup for terminal device against single or multiple domes in a network ) Power: camera’s power is to be connected locally with the supplied DC or AC adapter. QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 52: Advanced Setting -Preset Function
Start Group 4 (Preset 13~16) Scan Auto Pan-Only Auto Pan-c Tour Scan Patrol Power on reset Preset No. + Preset button = Call Preset Function Preset No. + Preset button (hold for 3 sec.) = Set Preset Function QMD Install manual D06400210010G PTZ Dome Camera... -
Page 53: Specification
-10 ~ 50℃ / 20 ~ 85% RHD Operation Temperature / Humidity (-35 ~ 55℃ for outdoor housing) Storage -20℃ ~ 60℃/ 20 ~ 85% RHD Temperature / Humidity Water proof IP-66 for outdoor housing Certification FCC, CE QMD Install manual D06400210010G PTZ Dome Camera... - Page 54 -10 ~ 50℃ / 20 ~ 85% RHD Operation Temperature / Humidity (-35 ~ 55℃ for outdoor housing) Storage -20℃ ~ 60℃/ 20 ~ 85% RHD Temperature / Humidity Water proof IP-66 for outdoor housing Certification FCC, CE QMD Install manual D06400210010G PTZ Dome Camera...
-
Page 55: Mounting Accessory
Plastic Housing To hold the camera on for surface ceiling surface mount (only for 10x zoom version) Metal Bowl To work with item 3 for creating ceiling or wall holder mount QMD Install manual D06400210010G PTZ Dome Camera... - Page 56 Accessory Picture Function Crane type bracket For wall mount Cane type bracket For ceiling mount Screw pack To mount the bracket and camera QMD Install manual D06400210010G PTZ Dome Camera...
