- Page 1 Wireless PC to TV ID# 762 Operation Manual...
- Page 2 Introduction The WiFi Smart Player to TV can send video/audio signals from a smart phone, PC or Notebook through Wi-Fi to a TV and use it as the primary display. The SmartPlayer is designed as a DLNA DMR (Digital Media Renderer) which means users can easily send audio, video and pictures from a computer wirelessly to TV.
-
Page 3: Operation Controls And Functions
Operation Controls and Functions Front Panel adaptor to AC ① DC 5V: Plug the 5V DC power supply into the unit and connect the wall outlet. ② HDMI out: Connect the output port to the HDMI TV/display. ③ Ethernet IN: This slot is to connect with CAT5e/6 cable from your network system or PC/Laptop for a wire connection of input signal sending. - Page 4 Top Panel ① Power LED: This blue LED will illuminate when the device is connected with power supply. USB Dongle ① USB Dongle: Plug this Wi-Fi dongle into the Smart Player's USB port for signal transmission...
- Page 5 Software installation and un-installation The following sections describe the procedures for installing the PC2TV device’s drivers. Insert the provid CD driver into the input source’s CD-ROM driver then begin the installation. Software Installation Insert the CD driver included in the package and double click on the PC2TV.exe executable file to start the setup process.
- Page 6 Press “Analysis” to evaluate your computer system. The Benchmark Information will show whether or not your computer system is matching with the product requirement. After the setup is complete click on Finish and restart your source device.
- Page 7 Uninstall the Computer Software Follow the steps below to uninstall the PC2TV Software Step 1: Open the Control Panel: Start a Control Panel a Uninstall a program. Step 2: Select PC2TV execute file and click to remove. Step 3: Click on Finish to complete the un-install process.
- Page 8 Configuring your application to use the Receiver Configure your PC or Smart Phone with Ethernet connection, or becoming the Internet access point. Keep in mind, however, that the number, thickness and location of walls, ceilings or other objects that the wireless signals must pass through, may limit the range.
- Page 9 • Select the PC2TV(DMR) for display system For non-DLNA Smart Phone, users may download and execute softwares like “Twonky” and “Skifta”. For Samsung DLNA Smart Phone, please execute “AllShare” software. For HTC DLNA Smart Phone, Please execute “Connected Media”. Note: The Smart Phone's DLNA installation may be vary with different brand and therefore, the instruction above are for reference only.
- Page 10 Specifications Host Interface 1 x 802.11n Wi-Fi and 100/1000Mbps Ethernet Output port 1 x HDMI Extender Port 3 x USB (Keyboard and Mouse only) Video Supports (DLNA DMR) WMV, AVI, MPEG-1/2/4, 3GP & MOV with 2CH with bit-rate under 15Mbps Audio Supports ( DLNA DMR) LPCM, MPEG-1, WMA, WAV, MPEG-4, AAC, OGG, 3GP &...
