- Page 1 HDMI 4K UHD+ EDID Emulator - ID# 15478 Operation Manual...
- Page 2 Introduction This 4K UHD HDMI EDID Emulator is designed to manage and manipulate the EDID information provided to a connected HDMI source device. EDID contains critical information about the capabilities of the connected display, including audio and video format support, HDMI feature support, etc.
- Page 3 Operating Functions and Controls Front Panel 1. LEDs 1~8: These LEDs illuminate to indicate which EDID from the currently selected EDID mode is active. User: This LED will illuminate when the unit is in User EDID mode. Internal: This LED will illuminate when the unit is in Internal EDID mode. Note: When both the User and Internal LEDs are lit, the unit’s EDID is in External bypass mode.
- Page 4 ENTER/INFO: Press to confirm a selection within the OSD or to go deeper into a menu item. While not in a menu, press this button to display basic information about the currently connected source on the OSD. When nothing is connected to the HDMI output, pressing this button switches the HDCP management mode between "Follow In", "Follow Out"...
- Page 5 OSD Menu Level 1 Level 2 Level 3 EDID EDID MODE INTERNAL MANAGER USER EXTERNAL EDID SELECT 1: 1080p@60/8/RGB/LPCM (Internal EDIDs) 2: 4K2K@30/8/RGB/LPCM 3: 4K2K@30/8/YUV/Bitstream 4: 4K2K@30/12/RGB/HDR/LPCM 4K2K@30/12/YUV/HDR/Bitstream 6: 4K2K@60_Y420/8/LPCM 7: 4K2K@60_Y420/8/Bitstream 8: 4K2K@60/8/RGB/LPCM COPY TV EDID 1: DVI/1920×1080p@60/ (User EDIDs) STD/Emulator 2: 1920×1080p@60/STD/Emulator 3: 1920×1080p@60/STD/Emulator...
- Page 6 TIMEOUT 5~40 SEC (10 SEC) INFORMATION RESOLUTION HDCP MODE HDCP OUTPUT HDMI IN +5V EDID MODE FIRMWARE SINK INFO. FACTORY SETTING Note: Values in Bold are factory default settings EDID Manager This unit uses an EDID Management application which allows the user to copy the EDID from an attached display, edit an existing EDID file stored on the PC or create a basic EDID from scratch.
- Page 7 detected units will be displayed in the list. Clicking on a detected unit will open the EDID Commander window. EDID Controller Tab Mode Select: Under the “EDID Controller” tab the user may select the EDID to be sent to the connected HDMI source from 8 Internal, 1 External (bypass) or 8 User EDID options.
- Page 8 from the dropdown and then clicking the “Upload” icon. Before accepting the upload, the software will check and verify that the EDID’s header and checksum values are acceptable. • To analyze any EDID stored within the unit, select the EDID to view from the dropdown and click on the “Analysis”...
-
Page 9: Connection Diagram
This tab contains options for supporting 3D and defining the CEC Address. Once the user is finished editing or creating an EDID it can be saved to a *.bin file locally or uploaded directly to the unit using the “Save” and “Upload”... - Page 10 Specifications Video Bandwidth 600MHz/18Gbps Input Ports 1×HDMI Output Ports 1×HDMI Control Interface 1×USB Mini-B Supported Resolutions 408i@60Hz - 4K@60Hz (4:4:4, 8-bit) VGA@60Hz - WUXGA@60Hz (RB) HDMI Cable Length 10m (1080p@60Hz, 12-bit) 3m (4K@60Hz, 4:4:4, 8-bit) Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified) ESD Protection Human Body Model:...
- Page 11 Video Specifications Supported Resolutions (Hz) Input Output 640×480@60/72/75/85 720×480@60 720×576@50 800×600@56/60/72/75/85 1024×768@60/75/85 1280×720@50/60 1280×768@60/70/75/85 1280×800@60 1280×1024@60 1360×768@60 1600×1200@60 ...
