- Page 1 PC VGA to TV Video Converter - Ultimate XP Pro # 520 Operation Manual...
- Page 2 Introduction PC VGA to TV Video Converter - Ultimate XP Pro is a VGA to Video converter allowing your PC images to be viewed on a standard TV screen, HDTV and Progressive Scan TV. Record movies from your PC using VCR's or DVD's. The PC VGA to TV Video Converter - Ultimate XP Pro will support resolutions up to UXGA (1600x1200) and can be output via Composite or S-Video, RGB (Scart) and YUV/Cb/Cr connections.
-
Page 3: Resolution Table
Save the setting when you press the SAVE button. Modes and Resolution Table: This converter supports the following VGA display modes: 1024 1152 1280 1280 1600 Resolution 1024 1200 Vertical 60, 70, 72, 56, 60, 70, 60, 70, 60, 70, Frequency 75, 85, 72, 75, 85,... - Page 4 Operating Functions and Controls FIG.1 DC IN : Plug with USB or PS/2 power cable. PC VGA to TV Video Converter - Ultimate VIDEO OUT : Connects to the VIDEO input of TV、VCR or Video projector. PC VGA to TV Video Converter - Ultimate S-VIDEO OUT : Connects to your TV、VCR or Video projector supporting the S-VIDEO input.
- Page 5 PC VGA to TV Video SCAN CNVTR : Connects Y Cable among PC, Converter - Ultimate XP and monitor. Y.Cb.Cr OUT：Connect s the Y.Cb.Cr to Y.Cb.Cr cable to your TV supporting Y.Cb.Cr Input like HDTV or PROGRESSIVE SCAN TV. Buttons 1.
-
Page 6: Remote Control
Remote Control POWER : Toggle between power on & off. VIDEO STANDARD: Press this button to select your video system. It supports NTSC, NTSC- EIAJ, PAL-M, PAL-N, PAL, PAL-COMBINATION-N. MENU : Press this button to cyclically activate functions. These functions are Fine Tune, H-SIZE, V- SIZE Brightness, Contrast, Hue, Saturation, Flicker, OSD color &... - Page 7 Installation for IBM PC Users PC VGA to TV Video Converter - Ultimate XP is a “Plug and Display” video converter. The only thing required to get the image of computer on TV is to make the proper connection. Please read the following sections carefully for the installation of the hardware.
- Page 8 Make sure your computer’s (laptop, notebook or desktop PC) power is turned OFF. Connect the Y Cable for IBM PC among computer‘s VGA output, converter’s VGA IN and VGA monitor. Please connect the Y Cable mark “PC” to your computer’s VGA output, connect the Y Cable mark with red color “SCAN PC VGA to TV Video Converter - Ultimate XP's CNVTR”...
-
Page 9: Technical Tips
Technical Tips The following are problems that might arise when using the PC to TV converter, and possible solutions of them. Q: How can I enhance the display quality? A: You can usually lower the TV contrast and sharpness control at the best position, you can get a very good picture. - Page 10 PC VGA to TV Video 1. If long cable is used to connect the Converter - Ultimate XP to a TV, use a better 75 ohm Ghost image coaxial cable. (RG-59 is recommended) 2. Adjust Sharpness of TV. PC VGA to TV Video Converter - Ultimate XP 1.Set the to underscan.
