Summary of Contents for Converters.TV 475
- Page 1 Video to SXGA Converter Box #475 Operation Manual...
- Page 2 Introduction The Video to SXGA Converter Box is a composite video signal. S-Video signal and YCbCr signal format converter for AV System (Such as DVD. VCD, VCR, Camcorder, CCD etc.) to PC monitors with a DVI Cable or VGA single cable and have high quality SXGA resolution \ outputs.
- Page 3 Connection Video to SXGA Converter Box 1 . Connect the VGA cable to the [Display card] connecting port on the PC system and the Video to SXGA Converter Box [VGA-IN I To PC] 2.Connect the VGA cable with the monitor, another end to the [VGA-OUT / To Monitor] on the Video to SXGA Converter Box.
- Page 4 If your Monitor possesses DVI-D IN, you can use DVI • cable to connect the Video to SXGA Converter Box [DVI-D OUT] with High quality display effect. 3. Connect the Stereo Pin Jack Cable to the [SPEAKER] output port of the PC system and another end to (AUDIO- IN) on the Video to SXGA Converter Box.
-
Page 5: Video Input
1 VGA INPUT To PC 2 VGA OUTPUT To Monitor 3 RED LED display Power indication 4 Standard Button action (UP / DOWN / LEFT / RIGHT) and OSD Operation menu Power control and video functions selection button-used to turn on the power to the VIDEO mode and turn A : TOP Button off power to the PC... - Page 6 Specifications 1. Proprietary scan rate conversion engine : 60 KHz and 75 KHz output signal specification selectable 2. Proprietary scaling engine : Programmable non-linear high order scaling engine ● can be optimized for any diminution and expansion ratio Independent expansion ratio in both horizontal ●...
