- Page 1 Video to PC VGA Converter - Video Console II # 522 Operation Manual...
- Page 2 Introduction Video to PC VGA Converter - Video Console II is a Video to VGA converter for high resolution video pictures. The de-interlace can provide a high quality picture and produces a sharp and stable VGA output. The Video to PC VGA Converter - Video Console II is fully Remote Controlled for all functions.
- Page 3 15. OSD FUNCTION : OSD POSITION, OSD COLOR. LANGUAGE : JAPANESE, ENGLISH. ( Option 1 ) Seven languages (ENGLISH, FRENCH, GERMAN, SPANISH, ITALIAN, DUTCH, RUSSIAN) (Option 2) 17. RESET : RESET to default setting. FREQUENCY: 60 Hz and 75 Hz for each resolution. Operating Functions and Controls Infrared input of remote controller.
- Page 4 Remote Control POWER : Toggle switch of on/off for power. Automatically save the setting when you turn off the power button. PC : To select the PC (VGA) input. VIDEO : To select the Video input. S-VIDEO : To select the S-Video input.
- Page 5 MUTE : Toggle switch of on/off for sound. VOL- : Volume decreased. This item value is form 0 to 63.(Default value is 40) VOL+ : Volume increment. This item value is form 0 to 63.(Default value is 40) 75 Hz : To select the mode of 75Hz. 60 Hz : To select the mode of 60Hz.
- Page 6 Press ► button to increase. Press ◄ button to decrease. This item value is form 0 to 100. (Default value is 65) ＞ HUE ► Press ENTER button and ◄/ button to modify HUE value. Press ► button to increase. Press ◄ button to decrease. This item value is form 0 to 100.
- Page 7 POP Installation for IBM PC Users Video to PC VGA Converter - Video Console II is a “Plug and Display” Video to PC converter. Please read the following steps carefully for the installation of the hardware & refer to the...
- Page 8 3. Power on your PC. 4. Turn on your video devices(TV,DVD or VCD) Video to PC VGA Converter - Video Console II 5. Power on the 6. Select the input from VGA IN, VIDEO IN or S-VIDEO IN then you will get the picture.
