American Standard QR028 Owner's Manual

American Standard QR028 Owner's Manual

Stainless steel under cabinet range hood
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SKU:
QR028
Owner's Manual
Stainless Steel Under Cabinet
Range Hood
THANK YOU
for selecting American Standard... the benchmark of fine quality for over 100 years. To ensure that
your installation proceeds smoothly, please read these instructions carefully before you begin.
1
CONGLOMKB.COM
Please contact 1-877-333-0098 for further assistance.

Advertisement

Table of Contents
loading

Related Manuals for American Standard QR028

Summary of Contents for American Standard QR028

  • Page 1 Stainless Steel Under Cabinet Range Hood THANK YOU for selecting American Standard… the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly, please read these instructions carefully before you begin. CONGLOMKB.COM Please contact 1-877-333-0098 for further assistance.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Venting .
  • Page 3 Safety Information (continued) ELECTRICAL/GROuNDING INsTALLATION 1. use this unit only in the manner intended by the manufacturer. If you have any questions regarding this range hood, contact WARNING: Improper grounding can result in a risk the manufacturer. of electric shock. Consult a qualified electrician if the 2.

  • Page 4: Warranty

    Warranty One-year ManufaCTurer defeCT WarranTy This product is warranted to the original purchaser to be free of defects in material and workmanship for one (1) year from the date of purchase. This warranty does not extend to commercial or institutional use or installation. Incidental repairs that would involve a minimum of time and effort on behalf of the purchaser will not be considered warranty work and no compensation will be deemed forthcoming.

  • Page 5: Pre-Installation

    Pre-Installation PLannInG InSTaLLaTIOn CAUTION: Always wear safety goggles and gloves during installation to prevent personal injury. NOTE: More than one person may be required to complete the installation of this product. TOOLS requIred Level PVC Electrical Tape utility Knife Drill or Flat Blade and Powered Philips screwdriver...

  • Page 6: Package Contents

    Pre-Installation (continued) PaCkaGe COnTenTS Part description quantity Range hood with 2 filters Damper small screws (ø 5/32 in x 5/16 in) Large screws (ø 3/18 in x 1-1/8 in) Wire nuts SPeCIfICaTIOnS 305 mm 228 mm (12 in) (9 in) 81 mm 458 mm (3.2 in)

  • Page 7: Installation

    Installation REMOVING EXIsTING RANGE HOOD VENTING WARNING: To reduce the risk of fire, use only metal duct WARNING: Disconnect power source. work. Never use plastic vents. If an existing range hood is installed, it must be carefully removed. CAUTION: Ducted fans must always be vented to the This should be done with an assistant.

  • Page 8: Cabinet Preparation

    Installation (continued) 6. use no more than three 90 degree elbows. Do not install two 4. Determine the venting method (top venting or back venting). Ensure that the openings in the cabinet or wall for the damper elbows together. Make sure there is a minimum of 457 mm and for power access are in appropriate locations and are of (18 in) of straight duct between the elbows if more than one appropriate sizes, as described below.

  • Page 9: Damper

    Installation (continued) DAMPER INsTALLATION TOP VENTING OPTION WARNING: Edges are sharp. Wear safety gloves. 1. Choose the appropriate electrical knock-out hole to remove for your installation type. use the top hole (10) for a top BACK VENTING OPTION venting installation and the back hole (11) for a back venting installation.

  • Page 10: Range Hood

    Installation (continued) RANGE HOOD INsTALLATION 6. Ensure that the damper (B) rotates in the correct direction. TOP VENTING DAMPER DIRECTION CAUTION: Edges are sharp. Wear safety gloves. 1. Turn the range hood (A) upside down on a protective covering, such as a piece of cardboard or a large towel. If the damper (B) was installed on the top of the hood, ensure it is well protected from damage for the next steps.

  • Page 11: Electrical Connection

    Installation (continued) 5. Drill four pilot holes in the marked positions. ELECTRICAL CONNECTION 6. screw the four large screws (D) into the pilot holes. Leave the WARNING: Electrical wiring must be done by a qualified person screw heads about 64 mm (0.25 in) from the cabinet surface. in accordance with all applicable electrical and building codes.

  • Page 12: Bottom Panel & Filter

    Installation (continued) BOTTOM PANEL AND FILTER INsTALLATION 1. Re-install the bottom panel (18) and aluminum filters (17). Ensure that the holes beside the fan guard align with the holes on the bottom panel before inserting the six screws (19). 2. Turn the power on and check all lights and fan operation. Operation Medium High...

  • Page 13: Care And Maintenance

    Care and Maintenance 1. The saturation of greasy residue in the blower and filters may WARNING: Before servicing or cleaning the unit, switch cause increased flammability. Keep this appliance clean, free power off at the junction box and lock the panel door to of grease and residue build-up at all times to prevent possible prevent power from being switched on accidentally.
  • Page 14 Care and Maintenance (continued) FILTER CLEANING CAUTION: Do not operate blowers when filters are removed. The filters fitted by the factory are intended to filter out residue and grease from cooking. They do not need to be replaced on a regular basis but are required to be kept clean. •...

  • Page 15: Troubleshooting

    Troubleshooting DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance. Touching circuitry inside the range hood while it is energized will result in death or serious injury. Problem Solution □ Check if all power has been turned back on and all electrical The range hood does not operate after installation.

  • Page 16: Wiring Diagram

    Troubleshooting (continued) WIRING DIAGRAM Yellow/Green Yellow/Green Motor Motor 35W/JDR 16 35W/JDR 16 GU10 Light Capacitor GU10 Light Capacitor 5µ F/370V 5µ F/370V Black Black White White White White Black Black Grey Grey EXTERNAL DIAGRAM BACK VIEW BACK VIEW 250 mm (9.84 in) 22 mm (0.875 in) 250 mm (9.84 in) 22 mm (0.875 in)

  • Page 17: Service Parts

    Service Parts under CaBIneT ranGe HOOd If you are missing parts or if you require replacement parts, please call our customer service team at 1-877-333-0098 (Monday–Friday, 8:30 a.m.–5 p.m., EsT). Identify the required part(s) and have the part description(s) ready. Part description Part number quantity...
  • Page 18 Questions, problems, missing parts? Before returning to the store, call Customer Service 8:30 a.m.– 5 p.m., EST, Monday–Friday 1-877-333-0098 CONGLOMKB.COM Retain this manual for future use.
