Summary of Contents for American Standard QR042
- Page 1 Model No. QR042 Owner’s Manual Stainless Steel Under Cabinet Range Hood THANK YOU for selecting American Standard… the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly, please read these instructions carefully before you begin.
-
Page 2: Table Of Contents
Table of Contents Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Maintenance Safety Information . - Page 3 Safety Information (continued) COOKING SAFETY INFORMATION WARNING: To reduce the risk of fire, use only metal duct work . Never use plastic duct work . 1 . Never leave the range hood unattended when in use . 2 . Never cook over open flames under the range hood. WARNING: To reduce the risk of fire or electric shock, do 3 .
-
Page 4: Warranty
Warranty ONE YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . Conglom Kitchen &... -
Page 5: Pre-Installation
Pre-Installation TOOLS/MATERIALS REQUIRED (NOT SUPPLIED) Measuring tape Level Utility knife Adjustable Pencil Tape wrench Flathead Needle nose Phillips screwdriver screwdriver pliers Hammer Electric drill Safety goggles Safety gloves CONGLOMKB .COM Please contact customer.service@conglomkb.com or 1-855-629-3992 for further assistance. -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Range hood Damper (located inside the hood) Light suction cup HARDWARE INCLUDED NOTE: Parts not shown to actual size. Part Description Quantity Long tapping screw - (M5 mm x 12 mm) Short tapping screw - (M4 mm x 8 mm) Grommet... -
Page 7: Planning Installation
Pre-Installation (continued) PLANNING INSTALLATION Number of people required: 2 or more WARNING: Always wear safety goggles and gloves during Carefully check the range hood for damage and for missing parts installation . prior to installation . If there is any damage or if you are missing parts, do not proceed with the installation . - Page 8 Pre-Installation (continued) FOLLOW THESE GUIDELINES WHEN INSTALLING DUCT WORK: - Your venting system must vent to the outdoors either horizontally through the back wall (13) or vertically through the roof (14) (refer to Fig . 5/Fig . 6/Fig . 7) . - Use round metal duct work with a uniform diameter of 6 in (152 mm) .
- Page 9 Pre-Installation (continued) WIRING CONNECTION REQUIREMENTS DANGER: Risk of electrical shock . This range hood must Installation work and electrical wiring must be done by a qualified be properly grounded . person(s) in accordance with all applicable codes and standards, including fire-rated construction. DANGER: Turn off the power circuit breaker or the power switch on the junction box before installing this...
-
Page 10: Installation
Installation REMOVING THE ELECTRICAL KNOCK-OUT HOLE REMOVING THE VENTING HOLE - Choose the venting hole to remove for your installation WARNING: Always wear safety goggles and gloves during type . Use the top hole (3) for a top venting installation installation . - Page 11 Installation Installation (continued) INSTALLING THE RANGE HOOD DANGER: Turn off the power circuit breaker or the power switch on the junction box before installing this unit . Touching circuitry inside the range hood while it is energized will result in death or serious injury . DANGER: If installing this unit over a gas range, turn off the gas at the source before installing or servicing this unit .
-
Page 12: Operation
Operation NOTE: The fan and lights operate independently of each other. TURNING ON/OFF THE UNIT TURNING ON/OFF THE LIGHTS - To turn on the fan, press the appropriate speed control - Press the light switch (5) to turn on and off the lights . switch [Low Speed (2), Medium Speed (3), High Speed (4)] to select the desired level of power . -
Page 13: Replacing Filters
Maintenance REPLACING FILTERS DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance . Touching circuitry inside the range hood while it is energized When filters need replacing, exchange with similar filters with will result in death or serious injury . -
Page 14: Care And Cleaning
Care and Cleaning RANGE HOOD WARNING: Failure to maintain basic standards of care and cleaning of the range hood will increase the risk of fire. The range hood should be cleaned (regularly internally and externally) to preserve its appearance and performance . Do Not: - Always clean in the direction of the grain (original - Do not use corrosive or abrasive detergents, steel... -
Page 15: Troubleshooting
Troubleshooting DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance . Touching circuitry inside the range hood while it is energized will result in death or serious injury . Problem Solution The range hood will not operate . -
Page 16: Specifications
29.8 in (757 mm) W High 2 x Max . 25W or 310 ± 120~60Hz 35W/JDR 16, GU10 Top venting QR042 18.8 in (478 mm) D Push Button Medium 1 .6A twist and lock base Back venting 5 in (127 mm) H... -
Page 17: External Range Hood Diagram
Specifications (continued) EXTERNAL DIAGRAM OF RANGE HOOD 27.75 in. (705 mm) 9.81 in. (250 mm) 0.88 in. 1.1 in. (28 mm) (22 mm) D 1.5 in. (38 mm) 3.13 in. (80 mm) 7.62 in. (193.5 mm) 0.69 in. (18 mm) 2 in. -
Page 18: Service Parts
Service Parts If you are missing parts or if you require replacement parts, please contact our customer service team at customer .service@conglomkb .com or 1-855-629-3992 (8:30 am – 5 pm, EST, Monday–Friday). Identify the required part(s) and have the part number(s) ready. Part Description Code Quantity... - Page 19 Questions, problems, missing parts? Before returning to the store, please contact Customer Service at customer .service@conglomkb .com or 1-855-629-3992 from 8:30 am - 5 pm, EST, Monday - Friday CONGLOMKB .COM Retain this manual for future use . Made in China...
