Hotwire
5620 RTU Customer Premises
Installation Instructions
Document Number 5620-A2-GN11-00
August 1998

Before You Begin

An optional POTS (Plain Old Telephone Service) splitter is available for the Hotwire
5620 RTU (Remote Termination Unit). When a POTS splitter is installed, the telephone
and 5620 RADSL (Rate Adaptive Digital Subscriber Line) RTU can function at the
same time over the same pair of copper wires. In order to confirm the RTU installation,
the POTS splitter should be installed first.
To install a POTS splitter, refer to the appropriate POTS splitter document:
Document Number Document Title
5030-A2-GN10
5038-A2-GN10
Contact your sales or service representative to order additional product documentation.
Paradyne documents are also available on the World Wide Web at:
http://www.paradyne.com
Select Service & Support
Wiring and Cables Needed
The following wiring and standard connectors are used with this product:
New or existing unshielded twisted-pair wiring (CAT3 or better). The CAT3 wiring
must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm).
Standard RJ11 wall jack.
Standard Ethernet 8-pin, non-keyed modular plug for a PC or workstation. An
Ethernet straight-through or crossover cable is used. Refer to
5620
RTU, page 6, for Ethernet cable details.
TM
Hotwire 5030 POTS Splitter Customer Premises
Installation Instructions
Hotwire 5038 Distributed POTS Splitter Customer
Premises Installation Instructions
Technical Manuals
1
Installing the Hotwire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hotwire 5620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradyne Hotwire 5620

Summary of Contents for Paradyne Hotwire 5620

  • Page 1: Before You Begin

    Hotwire 5038 Distributed POTS Splitter Customer 5038-A2-GN10 Premises Installation Instructions Contact your sales or service representative to order additional product documentation. Paradyne documents are also available on the World Wide Web at: http://www.paradyne.com Select Service & Support Technical Manuals Wiring and Cables Needed The following wiring and standard connectors are used with this product: New or existing unshielded twisted-pair wiring (CAT3 or better).
  • Page 2 Connectors, page 10, for standard pin numbers. What Does the Hotwire RADSL RTU Do? The Hotwire 5620 RTU is a component in the Hotwire DSL Access System. This system provides high-speed Internet or corporate LAN access over traditional twisted-pair copper telephone wiring.
  • Page 3 — Network Service Provider (NSP) is used to represent any Internet Service Provider (ISP) or remote LAN access provider. DSL Access without a POTS Splitter When the Hotwire 5620 RTU is installed without a POTS splitter, a second telephone wiring pair is needed for DSL access. Customer Premises (CP)

  • Page 4: Installing The Dsl Access Wiring

    Installing the DSL Access Wiring The local loop terminates at the punchdown block or NID. Wiring must be connected from the customer premises side of the punchdown block or the NID to an RJ11 jack. Typically, the punchdown block is installed in commercial locations and the NID is installed in residential locations.
  • Page 5 97-15438-01 Telephone The Hotwire 5620 RTU connects to the local loop via wiring from the demarcation point to an RJ11 wall jack. The DSL twisted-pair wiring from the local loop terminates at a new or existing wall jack. It may be necessary to install a standard single RJ11 jack or replace a single jack with a double RJ11 jack.

  • Page 6: Installing The Hotwire 5620 Rtu

    , page 10. Installing the Hotwire 5620 RTU Place the Hotwire 5620 RTU on a flat surface with clearance for the rear connectors. Procedure 1. Use the RJ11 6-pin cable for the DSL connection. Insert one end of the cable into the jack labeled DSL.
  • Page 7 2. Use an 8-pin Ethernet cable for the Ethernet connection. Insert one end of the cable into the jack labeled ETHERNET. Use a straight-through cable and connect the other end to an Ethernet hub, or Hotwire RTU Ethernet Line Ethernet Ethernet Cable 97-15303-01...
  • Page 8 3. Insert the power cord’s round end into the jack labeled POWER. Plug the transformer into an AC outlet. The following illustration includes examples of two power supplies. Hotwire RTU Power Jack Transformer 98-15836 The RTU hardware installation is now complete. When the power cord is installed, the RTU goes through a power-on self-test.

  • Page 9: Status Leds

    Status LEDs All of the LEDs turn on and off during the power-on self-test. After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below. Condition Status RTU has power. No active alarms. An alarm condition exists. No active tests.

  • Page 10: Increasing The Number Of End-User Systems

    If the TST LED does not go off, contact the NSP. Increasing the Number of End-User Systems A single PC is attached to the Hotwire 5620 RTU by using an Ethernet crossover cable. To increase the number of PCs, connect all PCs to an Ethernet hub using a straight-through cable.
  • Page 11 The Ethernet interface connector uses an 8-pin, non-keyed modular plug. — To connect to an Ethernet hub, use the straight-through connection. 8-Pin Straight-Through Connection Ethernet Cable Pin # Function 10BaseT TX D+ 10BaseT TX D– 8-Pin 10BaseT RX D+ Plug 4 &...

  • Page 12: Important Safety Instructions

    Model 5620 RTU Technical Specifications Item Specification Height x Width x Depth 1.43 x 6.00 x 8.75 (3.64 cm x 15.24 cm x 22.23 cm) Weight 1 lb. 1 oz. (0.48 kg) Power Input: 100 Vac (+10%), 50 Hz; 120 Vac (+10%), 60 Hz; or Class 2 Transformer normal 230 Vac (+10%), 50/60 Hz service input voltage range...
  • Page 13 5. General purpose cables are used with this product for connection to the network. Special cables, which may be required by the regulatory inspection authority for the installation site, are the responsibility of the customer. Use a UL Listed, CSA certified, minimum No.

  • Page 14: Declaration Of Conformity

    Declaration of Conformity This Declaration of Conformity is made by Paradyne Corporation pursuant to Parts 2 and 15 of the Federal Communications Commission’s Rules. This compliance information statement pertains to the following products:...
  • Page 15 Canada EMI Warnings WARNING: To Users of Digital Apparatus in Canada: This Class B digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la classe B respecte toutes les exigences du règlement sur le matérial brouilleur du Canada. Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment.

  • Page 16: Document Feedback

    Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@eng.paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
