Hotwire 5216 RTU Customer Premises
Installation Instructions
Document Number 5216-A2-GN10-30
August 2000
Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

What Does the Hotwire 5216 RTU Do?

The Hotwire 5216 RTU (Remote Termination Unit) is a component in the Hotwire
RADSL Access System and interoperates with the Hotwire 8540 DSL Card in the
DSLAM (Digital Subscriber Line Access Multiplexer) system. This system provides
high-speed Internet or corporate LAN access over traditional twisted-pair copper
telephone wiring.
Copper pairs run from the central office (CO) to the customer premises (CP) to create
the local loop. The local loop terminates on the customer premises at the demarcation
point in a punchdown block or network interface device (NID).
Optional POTS Splitter
An optional POTS (plain old telephone service) splitter can be installed to block out the
DSL signal and allow the POTS frequencies to pass through. At the customer
premises, the 5216 RTU and a telephone can function simultaneously over the same
pair of copper wires when either:
A Hotwire 5030 or 5038 POTS Splitter is installed near the demarcation point for all
telephones on the same POTS line as DSL, or
A Hotwire 5038 Distributed POTS Filter is installed on each telephone on the same
POTS line as DSL.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
1
5
8
10
11
12
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5216 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradyne 5216

Summary of Contents for Paradyne 5216

  • Page 1: Table Of Contents

    Important Safety Instructions What Does the Hotwire 5216 RTU Do? The Hotwire 5216 RTU (Remote Termination Unit) is a component in the Hotwire RADSL Access System and interoperates with the Hotwire 8540 DSL Card in the DSLAM (Digital Subscriber Line Access Multiplexer) system. This system provides high-speed Internet or corporate LAN access over traditional twisted-pair copper telephone wiring.
  • Page 2 — Service provider is used to represent any Internet Service Provider (ISP) or remote LAN access provider. DSL Access without a POTS Splitter When the Hotwire 5216 RTU is installed without a POTS splitter, the DSL line is used for data only and does not provide telephone services. Demarcation...
  • Page 3 Demarcation Point Central Office (CO) Local Loop Service Provider Punchdown Block or NID DSL – Digital Subscriber Line NID – Network Interface Device New Wiring Connections DSL Access with a Hotwire 5038 Distributed POTS Splitter When a Hotwire 5038 Distributed POTS Splitter is used, one 5038 Distributed POTS Splitter is installed as a phone filter for each telephone on the same POTS line as DSL.

  • Page 4: Package Checklist

    26 AWG (.4 mm). Ethernet cabling: Standard Ethernet crossover cable with an 8-pin, non-keyed modular plug for a PC or workstation. Refer to Installing the Hotwire 5216 RTU on page 8 for Ethernet cable details. Refer to Cables & Connectors on page 12 for standard pin numbers.

  • Page 5: Installing The Dsl Access Wiring

    Installing the DSL Access Wiring The local loop terminates at the punchdown block or NID. Wiring must be connected from the customer premises side of the punchdown block or the NID to an RJ11 jack. Typically, the punchdown block is installed in commercial locations and the NID is installed in residential locations.
  • Page 6 3. Locate the DSL pair of T1/R1 connectors on the customer premises side of the NID or punchdown block. Attach the wiring that will be connected to the DSL jack. In the following example, a NID is used without a POTS splitter. It includes an existing POTS line and a second pair installed for DSL access.

  • Page 7: Connecting To The Dsl Access Wiring

    Connecting to the DSL Access Wiring The Hotwire 5216 RTU connects to the local loop via wiring from the demarcation point to an RJ11 wall jack. The DSL twisted-pair wiring from the local loop terminates at a new or existing wall jack. It may be necessary to install a standard single RJ11 jack or replace a single jack with a double RJ11 jack.

  • Page 8: Installing The Hotwire 5216 Rtu

    Hotwire RTU Jack If the Hotwire 5216 RTU is installed on the same line as POTS, a Hotwire 5038 Distributed POTS Splitter can be used as a phone filter. One 5038 Distributed POTS splitter is installed as a phone filter for each telephone on the POTS/DSL line, as shown below.
  • Page 9 2. Use an 8-pin Ethernet crossover cable for the Ethernet connection. Insert one end of the cable into the jack labeled ETHERNET. Connect the other end to the Ethernet Network Interface Card (NIC) installed in the PC. Hotwire RTU PC with Ethernet Network Interface Card For RTU cable pin assignments, refer to Cables &...

  • Page 10: Status Leds

    The self-diagnostics includes a power-on self-test. During the power-on self-test, all of the LEDs turn on for one second. Power – green 5216 Refer to Troubleshooting on page 11 for LED indications requiring action. Status LEDs All of the LEDs turn on and off during the power-on self-test. After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below.

  • Page 11: Troubleshooting

    PC is connected and powered on. Verify that the correct crossover cable is installed. Refer to Installing the Hotwire 5216 RTU on page 8. PWR LED is off. Check that the power cord is securely installed on both ends.

  • Page 12: Cables & Connectors

    Cables & Connectors Use standard twisted-pair CAT3 or better cables. This section is reference information. DSL interface connector uses a 6-pin, non-keyed modular plug. RJ11 6-Pin Connector Pin # Function 1 & 2 Not used DSL Ring DSL Tip 5 & 6 Not used Ethernet interface crossover cable connector uses an 8-pin, non-keyed modular plug.

  • Page 13: Optional Rtu Wall Placement

    Optional RTU Wall Placement The Hotwire 5216 RTU is designed for tabletop placement. The RTU can also be mounted on a wall. To mount an RTU, you will need: Three slotted-head #6 self-threading screws with molly bolts Drill and 3/16 drill bit for the molly bolts Screwdriver A template with the dimensions for the three screws is provided.
  • Page 14 RTU Hardware Template 5.43" Front (LEDs) 7.55" To Bottom Hole 98-16171...
  • Page 15 Technical Specifications for Model 5216 RTU Item Height x Width x Depth Weight Power Class 2 Transformer normal service input voltage range Approvals FCC Part 15 CISPR 22 Safety Certifications Physical Environment Operating temperature Storage temperature Relative humidity Shock and vibration...

  • Page 16: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.

  • Page 17: Declaration Of Conformity

    Trade Name: Hotwire Model Number: 5216-A3-200 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 18: Government Requirements

    Ringer Equivalence Number (REN) for this equipment. The label is located on the bottom of your RTU. 2. The Hotwire 5216 RTU connects to the Public Switched Telephone Network (PSTN) using the Universal Service Order Code (USOC) RJ11C or RJ14C.

  • Page 19: Notice To Users Of The Canadian Telephone Network

    5. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. 6.

  • Page 20: Document Feedback

    Trademarks Hotwire is a registered trademark of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks or registered service marks of their respective owners. Copyright 2000 Paradyne Corporation. Printed in U.S.A. *5216–A2–GN10–30*...
