Hotwirer 5620 RTU Customer Premises
Installation Instructions
Document Number 5620-A2-GN11-10
June 1999

Before You Begin

The Hotwirer 5620 RTU (Remote Termination Unit) interoperates with the Hotwire 8510
DSL Card in the DSLAM (Digital Subscriber Line Access Multiplexer) system.
An optional POTS (Plain Old Telephone Service) splitter is available for the Hotwire
5620 RTU. When a POTS splitter is installed, the telephone and 5620 RADSL (Rate
Adaptive Digital Subscriber Line) RTU can function at the same time over the same pair
of copper wires. In order to confirm the RTU installation, the POTS splitter should be
installed first.
To install a POTS splitter, refer to the appropriate POTS splitter document:
Document Number Document Title
5030-A2-GN10
5038-A2-GN10
Contact your sales or service representative to order additional product documentation.
Paradyne documents are available on the World Wide Web at www.paradyne.com.
Select Library
Technical Manuals.
Wiring and Cables Needed
The following wiring and standard connectors are used with this product:
-
New or existing unshielded twisted-pair wiring (CAT3 or better). The CAT3 wiring
must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm).
-
Standard RJ11 wall jack.
-
Standard Ethernet 8-pin, non-keyed modular plug for a PC or workstation. An
Ethernet straight-through or crossover cable is used. Refer to Installing the Hotwire
5620 RTU, page 8, for Ethernet cable details.
TM
Hotwire 5030 POTS Splitter Customer Premises
Installation Instructions
Hotwire 5038 Distributed POTS Splitter Customer
Premises Installation Instructions
1
