  • Page 1 COFFEE MAKER M-Series TYPE: M100, M102, MT100, MT100V Installation and Operation Manual S/N: Rev.: 2.2...
  • Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
  • Page 4 7.5.2008 Rev. 2.2...
  • Page 5: Table Of Contents

    7.5.2008 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relation of the appliance and the manual ..........1 2. Safety instructions ..................2 2.1 General .......................... 2 2.1.1 Instructions for use ....................
  • Page 6 7.5.2008 Rev. 5. Installation ....................14 5.1 General ........................14 5.1.1 Unpacking ......................14 5.2 Installation ........................14 5.2.1 Preparation for positioning the appliance ............14 5.2.2 Electrical connections ..................15 5.2.3 Water drainage ..................... 15 5.2.4 Height setting model MT100V ................15 5.2.5 Setting the descale indicator ................
  • Page 7: General

    7.5.2008 Rev. 2.2 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations.
  • Page 8: Safety Instructions

    7.5.2008 Rev. 2.2 Safety instructions 2. Safety instructions 2.1 General This appliance meets the mandatory safety regulations. Inexpert use can result in personal injury and material damage. The following warnings and safety instructions must be ob- served before using the coffee maker. 2.1.1 Instructions for use Read these instructions for use carefully, before using this appliance.
  • Page 9: Maintenance And Troubleshooting

    7.5.2008 Rev. 2.2 Safety instructions 2.1.4 Maintenance and troubleshooting • Observe the descaling intervals indicated by the descaling indicator light. • Overdue maintenance to the heating system can result in high repair costs and an- nulment of the guarantee. • Always follow the manufacturer’s instructions when using the descaling agent.
  • Page 10: Jug Detector (9)

    7.5.2008 Rev. 2.2 Safety instructions 2.2.3 Jug detector (9) This appliance is fitted with a jug detector that operates the leak stop under the filter. This jug detector also ensures that the appliance only makes coffee if there is a jug under the filter.
  • Page 11: Functional Description

    7.5.2008 Rev. 2.2 Functional description 3. Functional description 3.1 Use of the appliance The sole use of this appliance is to make coffee and/or tea, and to warm water. 3.1.1 Other use The use of the appliance for other purposes is not permitted and may be hazardous. The manufacturer cannot be held liable for losses caused by using the appliance for purposes other than those indicated here or by incorrect use.
  • Page 12: Construction

    7.5.2008 Rev. 2.2 Functional description 3.2 Construction KP ST OHJ...
  • Page 13: Control Panel

    7.5.2008 Rev. 2.2 Functional description The most important parts (see pic.): Appliance on/off switch and bottom hot plate On/off switch for top hot plate Basket filter with leak stop device Basket filter paper Control panel (see below for details) Water reservoir opening and grid Glass jug/thermos flask Top hot plate Jug detector...
  • Page 14: Brewing Process Indicator Light

    7.5.2008 Rev. 2.2 Functional description 3.3.2 Brewing process indicator light The green indicator light lights up when the coffee passes through the system. At the end of the coffee making process a signal sounds three times and the green indicator light goes out.
  • Page 15: Operation Instructions

    7.5.2008 Rev. 2.2 Operation instructions 4. Operation instructions 4.1 First time use • Slide an empty basket filter (3) into the appliance and place an empty jug (with lid) underneath it. For the MT100(V) model leave the lid of the thermos jug with pump open, and leave the riser tube in the jug.
  • Page 16: Daily Use

    7.5.2008 Rev. 2.2 Operation instructions 4.1.1 Daily use Leak stop This appliance is fitted with a leak stop that ensures that no coffee drips out of the filter when you: • take away the jug after making coffee. • take the filter out of the appliance after making coffee to empty it. The leak stop can only work if the jug detector is pressed in sufficiently by the jug.
  • Page 17: Operation Procedures

    7.5.2008 Rev. 2.2 Operation instructions 4.2 Operation procedures 4.2.1 Making coffee • Place a sheet of basket filter paper containing the desired amount of coffee (fine grind type) in the basket filter. See the table above for the amount of coffee re- quired.
  • Page 18: Cleaning Of The Appliance And Accessories

    7.5.2008 Rev. 2.2 Operation instructions 4.3 Cleaning of the appliance and accessories The appliance must not be submerged or sprayed. • Clean the outside of the appliance with a clean, damp cloth, if necessary using mild (non-abrasive) cleaning agent. • Do not use an abrasive, as this will leave scratches and dull patches.
  • Page 19: Switching-Off The Descale Indicator Light

    7.5.2008 Rev. 2.2 Operation instructions • Before descaling the appliance, carefully read the instructions for use of the scale remover. • Dissolve one (50 gram) sachet of scale remover in 1 litre of warm water (approx. 60-70ºC). • Slide an empty basket filter (1) into the filter holder and place an empty jug under •...
  • Page 20: Installation

    7.5.2008 Rev. 2.2 Installation 5. Installation 5.1 General 5.1.1 Unpacking The machine has been carefully packed to prevent damage being caused to your new cof- fee maker. Remove the packing carefully without using sharp objects. Check if the appli- ance is complete. The appliance is delivered with the following accessories: M 100 M 102 MT 100...
  • Page 21: Electrical Connections

    7.5.2008 Rev. 2.2 Installation 5.2.2 Electrical connections Supply voltages and frequencies can differ between countries. Check if the appliance is suitable for connection to the local power mains. Check if the details on the type plate cor- respond. Connect the appliance to an earthed wall socket. 5.2.3 Water drainage The water reservoir has a maximum content of 2.7 litres.
  • Page 22: Setting The Descale Indicator

    7.5.2008 Rev. 2.2 Installation 5.2.5 Setting the descale indicator Scale deposits are left in the heating system when the appliance is used. The amount of scaling depends on the hardness of the water being used. The appliance is fitted with a descale light (5.1), which lights up when the heating system has processed a certain quan- tity of water and has to be descaled.
  • Page 23: Troubleshooting

    7.5.2008 Rev. 2.2 Troubleshooting 6. Troubleshooting Have all repairs to the electrical system performed by a qualified service technician. If your appliance is not functioning correctly, use the troubleshooting guide below to see whether you can resolve the problem yourself. If not, please contact your dealer. Symptom Possible cause Action...
  • Page 24 7.5.2008 Rev. 2.2 Troubleshooting...
  • Page 25: Spare Parts

    7.5.2008 Rev. 2.2 Spare parts 7. Spare parts General parts M100 ......23 General parts M102 ......25 General parts MT100......27 General parts MT100V ......29...
  • Page 26 7.5.2008 Rev. 2.2 Spare parts...
  • Page 27: Voltage Codes

    7.5.2008 Rev. 2.2 Spare parts 7.1 Voltage codes Voltage code Voltage 3/N/PE∼400/230V 50Hz ∼250V 16A 50Hz 3/N/PE∼380/220V 50Hz 3/PE∼200V 50-60Hz 2/PE 220−240V 50Hz 3/N/PE∼415/240V 50Hz 3/PE∼230V 50Hz 3/PE∼220V 60Hz 3/PE∼380 50Hz 3/PE∼400V 50Hz 3/PE∼415V 50Hz 3/PE∼440V 60Hz 3/PE∼460V 60Hz 3/PE∼480V 60Hz 1/N/PE~220-240V 50Hz 2/PE~220-230V 60Hz 3/N/PE∼400/230V 50Hz...
  • Page 28 7.5.2008 Rev. 2.2 Spare parts...
  • Page 29 7.5.2008 Rev. 2.2 Spare parts Code Type Description MODULE:General parts M100 02180 M100 Switch 1P, orange 02571 M100 Cable strain relief 02886 M100 Pc board M100 02888 M100 Pc board M100 keyboard 02929 M100 Dry-boil protection 02930 M100 Level sensor M 02938 M100 O-ring 92.75x2.62 EPDM...
  • Page 30 7.5.2008 Rev. 2.2 Spare parts...
  • Page 31 7.5.2008 Rev. 2.2 Spare parts Code Type Description MODULE:General parts M102 02180 M102 Switch 1P, orange 02571 M102 Cable strain relief 02886 M102 Pc board M100 02888 M102 Pc board M100 keyboard 02929 M102 Dry-boil protection 02930 M102 Level sensor M 02938 M102 O-ring 92.75x2.62 EPDM...
  • Page 32 7.5.2008 Rev. 2.2 Spare parts...
  • Page 33 7.5.2008 Rev. 2.2 Spare parts Code Type Description MODULE:General parts MT100 02180 MT100 Switch 1P, orange 02571 MT100 Cable strain relief 02886 MT100 Pc board M100 02888 MT100 Pc board M100 keyboard 02929 MT100 Dry-boil protection 02930 MT100 Level sensor M 02938 MT100 O-ring 92.75x2.62 EPDM...
  • Page 34 7.5.2008 Rev. 2.2 Spare parts...
  • Page 35 7.5.2008 Rev. 2.2 Spare parts Code Type Description MODULE:General parts MT100V 1050 02180 MT100V Switch 1P, orange 1060 02571 MT100V Cable strain relief 1070 02886 MT100V Pc board M100 1080 02888 MT100V Pc board M100 keyboard 1090 02929 MT100V Dry-boil protection 1100 02930 MT100V...
  • Page 36 7.5.2008 Rev. 2.2 Spare parts...
  • Page 37: Technical Specifications

    7.5.2008 Rev. 2.2 Technical specifications 8. Technical specifications Electrical diagram M100 Electrical diagram M102 Electrical diagram MT100 Electrical diagram MT100v Installation drawing M100, M102 Installation drawing MT100, MT100v...
  • Page 38 Electrical diagram M100...
  • Page 39 Electrical diagram M102...
  • Page 40 Electrical diagram MT100...
  • Page 41 Electrical diagram MT100v...
  • Page 42 M100 M102 Installation drawing M100, M102...
  • Page 43 MT100 MT100v Installation drawing MT100, MT100v...
  • Page 44 7.5.2008 Rev. 2.2 Technical specifications Item Type Specification Buffer stock coffee M100 3.6 l. / 28 cups Buffer stock coffee M102 7.2 l. / 56 cups Hourly coffee capacity M100,MT100,MT100V 18 l. / 144 cups Hourly coffee capacity M102 28 l. / 224 cups Jug filling time M100 approx.
