Assembling the pedestal

Fix securely with assembly screws
Tighten screws firmly.
Pole
R
■
Set-up
Tighten assembly screws
then tighten them firmly to fix securely.
Arrow
mark
Pole
Work on a flat surface
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way when using the wall hanging bracket or repacking the TV.
Remove the assembly screws
Lift the TV from the pedestal.
Remove the assembly screws
Warning
Do not disassemble or modify the pedestal.
Otherwise, the TV may fall over and become damaged, and personal injury may result.
Caution
Do not use any pedestal other than that provided with this TV.
Otherwise, the TV may fall over and become damaged, and personal injury may result.
Do not use the pedestal if it becomes warped or physically damaged.
If you use the pedestal when it is physically damaged, personal injury may result. Contact your
nearest Panasonic Dealer immediately.
During set-up, make sure that all screws are securely tightened.
If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal
will not be strong enough to support the TV, and it might fall over and become damaged, and personal
injury may result.
When removing the pedestal, do not remove the pedestal by any methods other than the specified
procedure. (above)
Otherwise, the TV and/or pedestal may fall over and become damaged, and personal injury may result.
Attaching the pedestal to TV
A (Total 4 screws).
A
Pole
L
Base
Front
B (total 4 screws) loosely at first,
Bottom view
Rear side
B
Hole for pedestal
installation
Pole
Base
Fix securely with assembly
screws (Total 4 screws).
B
from the TV.
B
from the pole.
A
Accessories
Assembly screws
(4 of each)
A
size (M5 × 18)
B
size (M5 × 30)
Poles (2)
L
R
L or R is printed at the
bottom of the poles.
Base (1)
