Summary of Contents for Dustbane POWER CLEAN
- Page 1 OPERATION MANUAL POWER CLEAN POWER CLEAN WIDE AREA VACUUM Item Code 19384 Edition 02 03 27...
-
Page 2: Machine Data Log/Overview
DATE OF PURCHASE __________________________ SERIAL NUMBER ______________________________ SALES REPRESENTATIVE # _____________________ DEALER NAME ________________________________ OPERATIONS GUIDE NUMBER ___________________ PUBLISHED __________________________________________ YOUR DEALER Name: _____________________________________________________________________________________ _____________ Address: For the name and address of your dealer contact: Windsor Industries _____________________________________________________________________________________ __________ Dustbane Products Limited... -
Page 3: How To Use This Manual
NOTE: If a service or option kit is installed on your machine, be sure to keep the KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. Dustbane Products Limited... -
Page 4: Table Of Contents
Regular/Periodic Maintenance......4-2 Wiring Diagram..........4-3 GROUP PARTS LIST Brush and Drive Group........5-1 Brush Height and Wheel Group......5-3 Vacuum Group..........5-5 Handle Group...........5-7 Lid/Decal Group..........5-9 Electrical Panel and Cover Group……………...5-11 Suggested Spare Parts…………………….……5-12 Warranty............5-13 Dustbane Products Limited... -
Page 5: Important Safety Instructions
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not pull/run machine over cord. Keep cord away from heated surfaces. Connect to a properly grounded outlet. See Grounding Instructions. SAVE THESE INSTRUCTIONS Dustbane Products Limited... -
Page 6: Hazard Intensity Level
Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. Dustbane Products Limited... -
Page 7: Grounding Instructions
Whenever the adaptor is used, it must be held in place by a metal screw. Dustbane Products Limited... -
Page 8: Controls
12 Dust bag cove r. Raise to allow access to dust bag and vac motors. 13 Cloth dust bag. High filtration cloth bag with zipper opening to access paper bag. 14 Paper bag. Fits within cloth bag for clean and easy dust removal. Dustbane Products Limited... - Page 9 NOTE: Attach strain relief/cord retainer to the power cord. 1. Make a loop in power cord approximately 12” from receptacle end. 2. Slide cord loop through slot in retainer arm. Pull slack cord back through slot to secure. Attach retainer to handle. Dustbane Products Limited...
-
Page 10: Cleaning
When finished vacuuming, coil the cable by hand by looping into about a 3 foot diameter, Hang coiled cable over handle. Wrap the end around the cable loop to secure. 10. Return brush to storage position. Dustbane Products Limited... -
Page 11: Maintenance
NOTE: BEFORE REINSTALLING BRUSH MOTOR BRACKET ASSEMBLY IT’S RECOMMENDED THAT THE REAR SPRING BE RECONNECTED TO THE FLAPPER ASSEMBLY. NOTE: PART NO. 140212 IF YOU HAVE A MOTOR MARKED “LEESON.” PART NO. 14340 IF YOU HAVE A MOTOR MARKED “53617.” Dustbane Products Limited... -
Page 12: Daily Maintenance
Frayed or cracked hoses should be repaired or replaced to eliminate vacuum loss. The electrical cable must be well insulated, if the cable insulation is broken or frayed, repair or replace it immediately. Don’t take chances with electrical fire or shock. Dustbane Products Limited... -
Page 13: Wiring Diagram
8 8 0 2 5 3 8 8 2 3 1 8 8 3 4 9 S C R E W E X H A U S T H A N D L E S C R E E N Dustbane Products Limited... -
Page 14: Brush And Drive Group
BRUSH AND DRIVE GROUP BRUSH ASSEMBLY -DETAIL- Vacuum Door Assembly BRUSH ASSEMBLY BRUSH DRIVE MOTOR ASSEMBLY VACUUM DOOR ASSEMBLY 24AB BRUSH SET BRUSH DRIVE MOTOR ASSEMBLY Dustbane Products Limited... - Page 15 WASHER, 3/8ID X 3/4OD X 1.25 3-66281 PEDAL, WAND ACTIVATOR 3-51277 LINKAGE, WAND ACTIVATOR 3-29202 DOOR, WAV FLAPPER 3-57042 NUT, 3/8 PUSHLOCK 3-73240 SPRING, EXT. 0.5OD X 2.25L X .063W 3-35224 GASKET, FLAPPER WAV 3-70270 SCR, 1/4-20 X 3/4 HHCS Dustbane Products Limited...
-
Page 16: Brush Height And Wheel Group
BRUSH HEIGHT AND WHEEL GROUP MAIN FRAME ASSEMBLY 7 17 Dustbane Products Limited... - Page 17 3-87090 3-87088 WASHER, 3/4ID X 1.00 PLTD. WASHER, 1/4 LOCK EXT. STAR SS 3-87025 SPRING, EXT .5OD X 1.75L X .06W 3-73362 SCR, 3/8-16 X 3/4 HHCS GR5 PLTD. 3-70507 3-70505 SCR, 1/4-20 X 1.0 HHCS PLTD. Dustbane Products Limited...
-
Page 18: Vacuum Group
VACUUM GROUP 7 (BRUSH SET) Dustbane Products Limited... - Page 19 GASKET, 4.0ID X 5.5OD X .38THK PRN 3-35204 GASKET, FILTER BAG NECK 3-35200 3-87025 WASHER, 1/4 LOCK EXT STAR SS 3-70505 SCR, 1/4-20 X 1.0 HHCS PLTD. SCR, #10 X 3/4 POLYFAST 3-70114 DEBRIS CHUTE, WAV 3-29205 3-53783 VAC MOTOR, 115V 5.7 1ST Dustbane Products Limited...
-
Page 20: Handle Group
HANDLE GROUP HANDLE ASSEMBLY - DETAIL - HANDLE ASSEMBLY Dustbane Products Limited... - Page 21 SCR, 8-32 X 1/2 FHMS 3-57163 NUT, 4-40 W/ STAR WASHER 3-62839 PLATE, SWITCH BOX INSLTR 3-51299 LEVER, SPRING STEEL 3-70363 SCR, 10-32 X 3/8 PHTR PLTD. 3-70663 SCR, 1/4-20 X 3-1/4 HHCS PLTD. 3-87025 WASHER, 1/4 LOCK EXT STAR SS Dustbane Products Limited...
-
Page 22: Lid/Decal Group
LID/DECAL GROUP Dustbane Products Limited... - Page 23 LABEL, WARNING 3-50762 LABEL, BRUSH HEIGHT ADJ. 3-02083 BRUSH, 3" DUST 3-70233 SCR, #10 X 3/8 PH HI-LO PLTD 3-27744 CLIP, C 1-1/2 PLASTIC 3-02085 BRUSH, UPHOLSTERY 3-02084 TOOL, 5" UPHOLSTERY 3-02292 TOOL, 11" PLASTIC CREVICE 5-10 Dustbane Products Limited...
-
Page 24: Electrical Panel And Cover Group
ELECTRICAL PANEL AND COVER GROUP NUT SUPPLIED WITH SWITCH NUTS SUPPLIED WITH CIRCUIT BREAKER 5-11 Dustbane Products Limited... -
Page 25: Suggested Spare Parts
BELT, 220 J-6 POLY-V 3-140341 BAGS, PAPER (PKG. OF 10) 3-34012 FILTER, VAC MOTOR 3-34309 FILTER, EXHAUST 3-140164 BAG, CLOTH 3-140211 BRUSH SET, VAC MOTOR 3-140212 BRUSH SET, 90 VDC 1/4HP MOTOR 3-14340 BRUSH SET, 53616/53617 5-12 Dustbane Products Limited...
