Sunsky V-520 User Manual

Mini gps tracker (gps+sms+gprs)
Hide thumbs

Advertisement

Quick Links

Download this manual
Shenzhen SUNSKY Technology Limited
V-520 Mini GPS Tracker
(GPS+SMS+GPRS)
User's Manual
V1.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the V-520 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunsky V-520

Summary of Contents for Sunsky V-520

  • Page 1 Shenzhen SUNSKY Technology Limited V-520 Mini GPS Tracker (GPS+SMS+GPRS) User’s Manual V1.1...

  • Page 2: On/Off Button

    Shenzhen SUNSKY Technology Limited 1. Introduction 1.1 Welcome Our main products are Bluetooth GPS, Bluetooth Module, GPS Module and personal tracker. We have base-room of develop in Shenzhen. OEM and ODM are welcomed. 1.2 What’s in the box? V 520...
  • Page 3 Shenzhen SUNSKY Technology Limited V 520 mini Tracker is a remote positioning device with built-in GPS and GSM/GPRS technology in the smallest size. It can transmit the longitude and latitude coordinates to your cell phone by the SMS. By this, you can find its location on the Google maps© or other map software.
  • Page 4 Shenzhen SUNSKY Technology Limited services for companies, organizations and individuals, users can search the positioning or movement tracking information provided by this product in mobile phone or personal computer, etc. Specification Hardware program, 900/1800/850/1900 dual-band or quad-band , Globally unique IMEI...

  • Page 5: Getting Started

    Shenzhen SUNSKY Technology Limited Dimension 50mm*44mm*16mm Voltage >500 mAh Rechargeable battery(3.7V) Charging connector DC 5V 2. Getting started 2.1 Hardware description Blue LED--- indicate the GSM signal state State Means constant Lighting no SIM card or not GSM net Slow flash every 8 seconds...
  • Page 6 Shenzhen SUNSKY Technology Limited button Means Power key Turn on/off the product by press it 3-5s; End the calls by press one time If time of pressing SOS button bigger than 3 seconds, it will send location information to one of the three...
  • Page 7 Shenzhen SUNSKY Technology Limited you turn on the device. Switch off: When the device is on, press the button to off side and wait for 3 seconds. When the LED goes out, it indicates that the device is turning off for sure.
  • Page 8 Shenzhen SUNSKY Technology Limited 3.1.1 Set up the user password instruction Format: 777+new password (4 figures) +old password (4 figures) eg: 77712340000 Explanation: Confirm the user password correctly; changes the new user password to the old password. After set successfully, it will send the confirmation messages (SET USER PASSWORD OK) to the sender.
  • Page 9 Shenzhen SUNSKY Technology Limited three models. GPS is in normal open state in factory set or reset. 1. Open the GPS instruction Format: 222 + user's password 4 For example: 2220000 Description: When V520 received the order and confirmed the user password is correct, it will open the GPS power, after the success it will send confirmation message "GPS ON OK”.
  • Page 10 Shenzhen SUNSKY Technology Limited 3, parameters set by 199 for restart will not be lost, reset will not change until the reset. 4, only in the power-saving mode, the V520 can be set timer switch GPS in accordance with 199, the other two modes will not.
  • Page 11 Shenzhen SUNSKY Technology Limited 3.1.5 Single localization request instruction Format: 666+ user password (4 figures) eg: 6660000 Explanation: When v 520 tracker receives the instruction and confirms the user password correctly, reads the GPS information. No matter whether effective, the information with the replying base station which is the set of the original software will be sent to the sender.
  • Page 12 Shenzhen SUNSKY Technology Limited Invalid data format: Lat: +22.50500 Long: +114.01000 Speed: 0.00KM/H Direction: 315.00 Date: 2008-04-25 Time: 16:39:45 BS: 25ee0dff Fix: V ID: 353686009002030 STATE: SMS If in the cold start and GPS no position, it will return to the void of information: “ERROR GPS GPRMC FRAME DATA BS: 27971054”.
  • Page 13 Shenzhen SUNSKY Technology Limited set or reset, timing upload is stop. 3.1.7 Telephone localization function Explanation: One of 3 telephone numbers stored in advance calls in, and hangs up after ringing 2-5 times, then the v 520 will send the location information in form of 3.1.5 to this number, the information state item automatically updates STATE: CALL.
  • Page 14 Shenzhen SUNSKY Technology Limited 1. Set the scope of the fence According to the input formats different of coordinates, user can choose the format as follows instructions to operate. Format1：003+ user password E/Wdddmm.mmmmN/Sdd.mmmmRzzz.z eg: 003xxxxE11406.0024N2233.4230R1 Explanation: E-- east longitude; W-- west longitude; N-- north latitude; S-- south latitude. In this example, uses E and N, please according to the actual geographical position choose corresponding coordinate form to set.
  • Page 15 Shenzhen SUNSKY Technology Limited (Accuracy for 5 after the decimal point, the following zero cannot bypass) Rzzz.z is radius for the domain (999.9 - 0.1), unit for KM. When the tracker receives this instruction, judges to be authorized users and confirms the user password correctly, it will send the confirmation messages “SET GEO-FENCE OK”...
  • Page 16 Shenzhen SUNSKY Technology Limited domain 【0,999】, the unit is seconds. When the V520 receives the instruction to confirm the user password is correct, set the historical record of the sampling frequency of X. If X = 0, then close the historical data records, if X≠ 0, then began to store GPS data as the X seconds time interval, after the success of return to the sender to confirm the information "SET SAMPLING...
  • Page 17 Shenzhen SUNSKY Technology Limited When the v 520’s working voltage is lower than the set, to read the GPS information, whether or not effective, immediately send the format as 3.1.5 location information to the three stored numbers, the information state item automatically updates STATE: LP. Send a total of three times, each time one minute interval.
  • Page 18 Shenzhen SUNSKY Technology Limited on search button, the Google earth will display the location map for you. eg： You receive the information from the tracker. As follows: Lat: +22.50500 Long: +114.01000 Speed: 0.00KM/H Direction: 315.00 Date: 2008-04-25 Time: 16:39:45 BS: 25ee0dff...
  • Page 19 Shenzhen SUNSKY Technology Limited Or you can use local map software on PDA or car navigation device, input the position date. (Note: pay attention to change the position date format) 3.2 The operation based on the GPRS application 3.2.1 Change the user password instruction...
  • Page 20 Shenzhen SUNSKY Technology Limited OK) to the sender. Note: the quantity of setting number is not more than 3, it is empty under reset or factory set, this instruction will be valid when open it next time until re-change or reset.
  • Page 21 Shenzhen SUNSKY Technology Limited then enter the second phase, H03 indicated the total turn-GPS time, which means the second phase is 2 minutes (ie Hzz - Lyy). H can be set (3 ~ 99). When S is set as 0, then it out of power-saving mode automatically and switches to the GPS always open model, that is command 188 will not work.
  • Page 22 Shenzhen SUNSKY Technology Limited BS: Base Station information Fix: Location state (A/V) ID: IMEI STATE: Message state Effective data format: Lat: +22.50500 Long: +114.01000 Speed: 0.00KM/H Direction: 315.00 Date: 2008-04-25 Time: 16:39:45 BS: 25ee0dff Fix: A ID: 353686009002030 STATE: SMS Invalid data format: Lat: +22.50500...
  • Page 23 Shenzhen SUNSKY Technology Limited 3.2.6 Change the user name Format: #801#user password#new user name## eg：#801#0000# username## Explanation: When v 520 tracker receives the instruction and confirms the user password correctly, changes the user name to the new user name. After the success, it will send the confirmation messages to the sender.
  • Page 24 Shenzhen SUNSKY Technology Limited 3.2.9 Set up the TCP/IP server and IP’s address and port number Format：#804#user password#fixed IP address # port ## eg：#804#0000#222.125.12.32#80## Explanation: When v 520 tracker receives the instruction and confirms the user password correctly, updates the IP address and port number preserved in the module，After the success, it will send the confirmation messages to the sender.
  • Page 25 Shenzhen SUNSKY Technology Limited 3.2.11 uploads information timing automatically Format: # 805 # user's password # T # sampling interval of data each time you upload a number of N # # Example: # 805 # 0000 # 12 # 5 # # Function Description: The sampling time T in seconds, defines the domain of 【10 , 59999】,...
  • Page 26 Shenzhen SUNSKY Technology Limited The product has active and passive monitoring function, a passive monitoring function is, when pre-existing user dial SIM card numbers and rings 6 sounds, it will change into monitoring state, calling client can monitor the surrounding background sound. Product proactive monitoring...
  • Page 27 Shenzhen SUNSKY Technology Limited E – East Longitude; W – West longitude; N - north latitude; S - South latitude. In Description: this case, using E, N, please select the appropriate location according to the actual coordinates of the format settings. The meaning of the various parts of the example is as follows: Exxxxx.xxxx is degress longitude information (decimal point behind the four, followed by zero...
  • Page 28 Shenzhen SUNSKY Technology Limited When the module receives the instruction and confirm the user password is correct, it will send short message to confirm: SET GEO-FENCE OK. Note: 1. the fence can not exceed the radius of its domain. 2. If the caller status is off, it will not dial again and send text messages to pre-existing customers only.
  • Page 29 Shenzhen SUNSKY Technology Limited Note: X is a historical record of the sampling frequency, an integer number, the definition of domain 【0,999】, the unit is seconds. When the V520 receives the instruction to confirm the user password is correct, set the historical record of the sampling frequency of X. If X = 0, then close the historical data records, if X≠...

  • Page 30: Auxiliary Functions

    Shenzhen SUNSKY Technology Limited 3.2.17 Low voltage upload Explanation: When the v 520’s working voltage lower than the set, it will upload data in such format as shown in 3.2.10. 4.1 Auxiliary functions 1, command reset * RESET # 0000 # #.
  • Page 31 Shenzhen SUNSKY Technology Limited IMEI: Identity marking yards MOD: Point to Point (SMS P2P 2) / SMS platform (SMS SC) / GPRS GPS: normally open (ON) / normally closed (OFF) / power (AUTO) HFR: hands-free Switch MTPRF: listen (SILENT) / Normal (NORMAL)
  • Page 32 Shenzhen SUNSKY Technology Limited Data Format: U1: Number one, the password U2: Number 2, password U3: No. 3, password SC: Service Center number, service password 4.2 State marked 1, point to point model 666 single request 4XX timer sending TIMER...

  • Page 33: Instruction Set

    Shenzhen SUNSKY Technology Limited 4.3 Reset the state list configuration state configuration state configuration state Working Point to point Stored calls Empty password 0000 mode Timing send Stop Number stations power e-fence CMNET User name V500 GPRS 0000 IP address 0.0.0.0 0000...
  • Page 34 Shenzhen SUNSKY Technology Limited 777+new password + old password Change user password in two modes #801#user password # new user name## Change the user name in GPRS mode #802#user password service Change service password in GPRS mode password # old service password ##...
