- Page 1 4 ports Remote I/O Controller CIE-H14 User Manual Version 1.1 Sollae Systems Co., Ltd. http://www.ezTCP.com...
- Page 2 CIE-H14 User Manual Ver. 1.1 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
-
Page 3: Table Of Contents
CIE-H14 User Manual Ver. 1.1 Contents Contents ............................- 2 - Introduction ..........................- 6 - 1.1 Introduction ................................- 6 - 1.2 Features .................................. - 6 - 1.3 Application Examples ............................- 7 - 1.4 Components ................................. - 9 - 1.5 Specification .............................. - Page 4 CIE-H14 User Manual Ver. 1.1 4.5 Serial Configuration mode ......................... - 28 - 4.5.1 Configuring Parameters ........................- 28 - 4.5.2 Revoking Serurity Options......................... - 28 - 4.6 ISP mode................................- 28 - 4.6.1 Upgrading Firmware..........................- 28 - 4.6.2 Upgrading HTML ........................... - 28 - 4.6.3 Revoking Serurity Options.........................
- Page 5 CIE-H14 User Manual Ver. 1.1 System Management ......................- 47 - 7.1 Upgrading Firmware ............................- 47 - 7.1.1 Firmware ..............................- 47 - 7.1.2 Processes ..............................- 47 - 7.2 Changing Webpage ............................- 49 - 7.2.1 Webpage ..............................- 49 - 7.2.2 Processes ..............................
- Page 6 CIE-H14 User Manual Ver. 1.1 Technical Support and Warranty ..................- 68 - 11.1 Technical Support ............................- 68 - 11.2 Warranty ................................- 68 - 11.2.1 Refund ................................. - 68 - 11.2.2 Free Repair Services ..........................- 68 - 11.2.3 Charged Repair Services........................
-
Page 7: Introduction
HTTP, Modbus/TCP, serialized Modbus/TCP and Macro mode can be used for these functions. CIE-H14 is additionally equipped with a RS232 serial interface to allow your serial devices to establish an Ethernet networking connection so that it can be flexibly used in diverse applications. -
Page 8: Application Examples
CIE-H14 User Manual Ver. 1.1 Application Examples Remote I/O device server Figure 1-1 remote I/O device server Serialized Modbus/TCP Figure 1-2 serialized Modbus/TCP Internet Switch Figure 1-3 internet switch - 7 - http://www.ezTCP.com... - Page 9 CIE-H14 User Manual Ver. 1.1 Serial Switch Figure 1-4 serial switch Macro mode Figure 1-5 macro mode Serial Device Server Figure 1-6 serial device server - 8 - http://www.ezTCP.com...
-
Page 10: Components
CIE-H14 User Manual Ver. 1.1 Components CIE-H14 RS232C Cable for PC (option) Dry contact adaptor (option) - 9 - http://www.ezTCP.com... -
Page 11: Specification
CIE-H14 User Manual Ver. 1.1 Specification 1.5.1 H/W specification Input Power DC 8.5~38V (Auto Polarity) Power Power Consumption Size 174mm x 123mm x 28mm Weight About 255g Digital Input 4 ports with photo couplers Digital Output 4 ports with relays... -
Page 12: Interface
CIE-H14 User Manual Ver. 1.1 Interface 1.6.1 Power The Power is interfaced with a 5mm terminal block and DC 8.5~38V(polarity auto detection) is allowed. Figure 1-7 Power - 11 - http://www.ezTCP.com... -
Page 13: Input Ports
1.6.2 Input Ports Because each of CIE-H14’s input ports are isolated by photo-couplers, users don’t need to be worried about the polarity. The circuit of the input port is shown in the figure below. Figure 1-8 a circuit of the input port The voltage specification of the input port is as follows: Over 1.8V... -
Page 14: Output Ports
CIE-H14 User Manual Ver. 1.1 1.6.3 Output Ports The output ports of CIE-H14 are interfaced to relays (Normal Open) as shown below. Figure 1-9 a circuit of the output port The output port operates are as follows : value relay contact... -
Page 15: Rs232 Port (Db9M)
CIE-H14 User Manual Ver. 1.1 1.6.4 RS232 Port (DB9M) CIE-H14 has an RS232 port supporting from 300 bps to 230,400 bps. This port is for connecting users’ serial devices to Ethernet (TCP/IP) including the “Serialized Modbus/TCP”. Figure 1-10 D-sub Male Connector ... -
Page 16: Ethernet Interface
1.6.5 Ethernet Interface An RJ45 connector is for the network interface of CIE-H14. You can use a UTP cable. It automatically senses 10Mbits or 100Mbits Ethernet. It also provides auto MDI/MDIX function that can automatically sense a 1:1 cable or cross over cable. -
Page 17: System Led
CIE-H14 User Manual Ver. 1.1 1.6.6 System LED CIE-H14 has 17 LEDs to indicate the current system status. Each LED represents the following status: mode name LED status description supplying the power connected with network LINK Blinks connected with network... -
Page 18: Isp Switch
1.6.7 ISP Switch There is an ISP switch located on the back of the product. It is a switch allowing CIE-H14 to operate in the serial configuration mode or ISP mode. If you press it between 20ms and 1s, CIE-H14 will go into the serial configuration mode that you can configure the environment parameters through the RS232 port. -
Page 19: Installation And Test
Figure 2-1 the connection between CIE-H14 and a PC 2.1.1 Setting Network Aera This step is for setting both CIE-H14 and your PC to be located on the same network to establish a TCP connection. Setting of the PC Add or change the IP address of the network adapter on your PC. - Page 20 MS Windows and this is comfortable to use because it does not need installation process. First, search your CIE-H14 via network. All the values of parameters are set to the default values in the factory. To apply it to your system, proper values should be set via ezManager.
-
Page 21: Test Operation
Test operation 2.2.1 Modbus/TCP Test This is for checking the operation of Input and output ports of CIE-H14 via Modbus/TCP. In this instruction, offered Modbus/TCP test program was used. Run ezManager. Then, you can see the window as shown below. - Page 22 Modbus/TCP test Figure 2-4 Modbus/TCP test ① Input the IP address of CIE-H14 ② Input the local port for Modbus/TCP of CIE-H14 In a local area network, ① and ② steps can be omitted. ③ Try to connect by pressing [Connect] button ④...
-
Page 23: Http Test With A Web Browser
2.2.2 HTTP Test with a WEB browser This is for testing the operation of Input and output ports of CIE-H14 via HTTP. The test was implemented on a WEB browser. You can use WEB browsers such as MS Internet Explorer, Google Chrome and Mozilla Firefox. -
Page 24: Configuration
Configuration via LAN Checklists Make sure of the connection between your PC and CIE-H14 via Ethernet. If they are in the same network, [MAC Address search] button can be used. Otherwise, only [IP Address search] is allowed to use. -
Page 25: Configuration Via Serial
Configuration via Serial Checklists Make sure of the connection between your PC and CIE-H14 using a RS232 cross cable. CIE-H14 has to be operating in the [Serial Configuration] mode. You make CIE- H14 operate in the serial configuration mode by pressing the ISP- button less than 1 second. -
Page 26: At Command
Make sure of the connection between your PC and CIE-H14 using a RS232 cross cable. All the parameters of the serial port between CIE-H14 and the Terminal of your PC should be the same. In the AT command mode, you can change some parameters through the serial port. -
Page 27: Operation Modes
CIE-H14 User Manual Ver. 1.1 Operation Modes What is the Operation Mode? Each of three operation modes are designed for specific purposes, and those are as follows: Normal mode This mode is for normal data communication and has 8 different communication modes. -
Page 28: Comparison Of The Each Mode
WEB(HTTP) Users can monitor and control CIE-H14 via HTTP Table 4-2 digital I/O control types Serial to Ethernet converter CIE-H14 can be used as a Serial to Ethernet converter. There are four communication modes in this operation. modifying serial... -
Page 29: Serial Configuration Mode
4.5.2 Revoking Serurity Options CIE-H14 offers strong functions for security like filtering with password or MAC and IP addresses. In the Serial Configuration mode, you can revoke all of these options. When you forget the password, enter this mode to change or delete it. -
Page 30: Methods For I/O Control
CIE-H14 User Manual Ver. 1.1 Methods for I/O control Modbus/TCP CIE-H14 supports Modbus/TCP. By using this protocol, it remotely monitors and controls I/O devices. To use this method, users’ application should support this protocol. 5.1.1 Related Parameters parameter description Modbus/TCP Using Modbus/TCP for controlling I/O ports of CIE-H14. -
Page 31: Modbus/Tcp Slave Mode
According to the standard Modbus/TCP, users can use a Modbus/TCP manager to control and monitor their I/O devices. You can set CIE-H14 to the [Slave] item to [Slave] mode. The [Passive] connection is recommended in this mode and the [Peer Port] should be 502. -
Page 32: Tcp Connection Modes
Table 5-3 the passive / active connection 5.1.5 Initial Output Value The initial value of CIE-H14’s output port can be configured. The output ports are set to ON or OFF according to the value of [Initial State] at the boot time. 5.1.6 Write Pulse By using the function code 105, you can give the signal of pulse type to the output ports. -
Page 33: Macro Mode
CIE-H14 User Manual Ver. 1.1 Macro Mode This mode lets users set the values of the output ports with simple macros. Since CIE- H14 reflects the values according to the macro expressions which are configured by users in advance, it is useful to make a specific device operate automatically using signals from various sensors. -
Page 34: 5.3.3 An Example Of Equations
CIE-H14 User Manual Ver. 1.1 5.3.3 An Example of Equations Here are some examples. In the expressions, spaces between the two operands will be ignored. Input Port Equations Description i0 + i1 Perform OR for i0 and i1. The part of the expression within the parentheses, (i1... -
Page 35: Web (Http)
ISP (Internet Service Provider) blocks the port, you can change that port number. Figure 5-2 changing port number for HTTP ① Input a port number to the [Web(HTTP) Port] box. ② Input the IP address of CIE-H14 along with the changed port number and “http://” - 34 - http://www.ezTCP.com... -
Page 36: Uploading Users' Web Page
5.4.2 Uploading Users’ Web Page CIE-H14 supports uploading custom web page. This function is available to anyone who can make HTML files. If you get some simple syntax, it is possible to monitor and control the I/O ports with your homepage interface. For more details about this, please refer to the clause 7.2... -
Page 37: Serial Communication Modes
TCP Server In this mode, CIE-H14 functions as a TCP server. CIE-H14 waits for a TCP connection from remote hosts. Once one of hosts tries to connect to CIE-H14, it responses to that request. After the connection is established, CIE-H14 converts the raw data from the serial port to TCP/IP packets and sends the packets to the network and vice versa. - Page 38 An Example An example as a TCP server Figure 6-1 TCP server Point State CIE-H14 is waiting for request segments of a TCP connection ① Remote host has sent a request (SYN) segment Processes of the connection ② The connection has been established...
- Page 39 CIE-H14 User Manual Ver. 1.1 TCP Client In this mode, CIE-H14 acts as a TCP client. CIE-H14 sends request segments to a remote host with information of [Peer Address] and [Peer Port]. Under situation that the TCP server works fine with the specific port, the connection will be established. After then, CIE-H14 converts the raw data from the serial port to TCP/IP data and sends them to the network and vice versa.
-
Page 40: An Example
CIE-H14 User Manual Ver. 1.1 DNS IP Address [DNS IP Address] is required when users use a host name instead of the IP address on the [Peer Port] parameter. 6.2.2 An Example A situation that [Event Byte] is set to 0... - Page 41 In the TCP client mode, the [TCP Server] check option is activated. If you check this option, CIE-H14 operates in the TCP server/client mode. In this mode, CIE-H14 can establish a TCP connection both actively and passively without changing any settings.
-
Page 42: At Command
CIE-H14 User Manual Ver. 1.1 AT Command AT command is a mode which users control CIE-H14 with AT command like controlling modem. In this mode, active and passive TCP connections are available. And users are allowed to configure some environmental parameters with extended commands. -
Page 43: Examples
③ TCP connection has been established CIE-H14 sends “CONNECT” message to the serial port Table 6-8 descriptions of each state Most of the response messages from the serial port of CIE-H14 are omitted on above figure. - 42 -... - Page 44 TCP Client – setting parameters and an active connection Figure 6-5 an active TCP connection Point State Set parameters in the AT command mode CIE-H14 sends a request segment of a TCP connection with ① the ATD command. Processes of the TCP connection ②...
-
Page 45: Udp
CIE-H14 User Manual Ver. 1.1 UDP has no processes of a connection. In this mode, data is sent in block units. Therefore, data that comes through CIE-H14’s serial port must be classified in block units to be sent elsewhere. 6.4.1 Key parameters ... -
Page 46: Examples
Point State CIE-H14 is receiving data from the serial port ① CIE-H14 Sends 5 bytes as one block based on the [Block Size] Serial device sends data “678” to CIE-H14 ② Data “678” has arrived CIE-H14 sends data from the remote host to the serial device ③... - Page 47 UDP data arrives from Remote Host 2. Send UDP data to Remote Host 2. Table 6-12 descriptions of each state “ABC”, “DE”, and “FGH” in the above figure are the data that CIE-H14 receives from a serial port and send to the network.
-
Page 48: System Management
Upgrading Firmware 7.1.1 Firmware Firmware is a type of software for operation of CIE-H14. If it is needed to add function or fix bugs, the firmware will be modified and released. We recommend that users keep using the latest released firmware. - Page 49 CIE-H14 User Manual Ver. 1.1 Checking firmware file and Sending Figure 7-2 sending firmware file ① Check if the name and path of the firmware file are correct ② Click the [Send] button ③ Confirm the completed message - 48 -...
-
Page 50: Changing Webpage
CIE-H14 User Manual Ver. 1.1 Changing Webpage 7.2.1 Webpage CIE-H14 comes preloaded with a webpage to facilitate control and monitoring through HTTP. 7.2.2 Processes Making Users‘ webpage or Downloading sample files Make your own webpage file or use sample webpage files freely available to download at our web site. - Page 51 ② Click the [Change F/W / HTML] button to run TFTP client ③ Select the [Change HTML] radio button ④ Input the IP address of CIE-H14 to the [Local IP Address] text box ⑤ Press the [Open Files] button and choose the HTML file - 50 - http://www.ezTCP.com...
- Page 52 CIE-H14 User Manual Ver. 1.1 Checking files and Sending Figure 7-5 sending firmware file ① Check if the name and path of the files are correct ② Click the [Send] button ③ Confirm the completed message - 51 -...
-
Page 53: Status Monitoring
Status Monitoring 7.3.1 Using TELNET Once the [TELNET] option is activated, users can remotely log in to CIE-H14. If a password is set, users should input the password. After that, messages from CIE-H14 appear as shown in the figure below. - Page 54 “st sio” command displays the number of bytes for the serial port. Figure 7-8 “st sio” command st uptime “st uptime” command shows amount of time since CIE-H14 has booted up. Figure 7-9 “st uptime” command sc “sc” command is used when users close a session. [OP1] means the name of session, and [OP2] should be “CLOSE”.
-
Page 55: Using Ezmanager
CIE-H14 User Manual Ver. 1.1 7.3.2 Using ezManager Status of CIE-H14 can be monitored by [Status] button on ezManager. By using the [Refresh Every 1 Second] option in the status window, the status is automatically updated in every second. Figure 7-12 status window of ezManager ... - Page 56 Password This text box is activated when CIE-H14 has a password. If users want to close the TCP connection, this password has to be correctly filled. Refresh Every 1 Second.
-
Page 57: Additional Functions
The maximum length is 8 bytes of Alphabet or number. When you want to revoke all of these restrictions, change the mode of CIE-H14 to the ISP mode. All restrictions are removable and communication with ezManager is revoked in the ISP mode. -
Page 58: Option Tab Functions
8.2.1 Notify IP Change CIE-H14 can be a TCP server even though it is assigned the IP address automatically. Using [Notify IP Change] function, it sends its IP address with the host name to the specific server. There are 3 types of functions provided: DDNS, TCP and UDP. -
Page 59: Sending Mac Address
CIE-H14 User Manual Ver. 1.1 8.2.2 Sending MAC Address [Sending MAC Address] is a function that CIE-H14 sends its MAC address to the remote host right after the connection is established. By using this function, a server can identify multiple devices with the information. - Page 60 Figure 8-4 debugging message window ① Pull down menu for selecting a network adapter ② Place for showing received debugging messages from CIE-H14 over the network ③ Auto update to display the latest captured file on the screen of ②...
-
Page 61: Serial Port Tab Functions
RTS/CTS when the states are changed. Disable TCP Transmission Delay - ② 8.3.2 If you use this option, CIE-H14 sends the data from the serial port to Ethernet as quickly as possible. Data Frame Interval - ③... -
Page 62: Tx Interval - ④
CIE-H14 User Manual Ver. 1.1 TX interval - ④ 8.3.4 This option is for preventing data loss in the case that the serial device has very small buffer size or does not have a buffer. The range of the value could be from 0 to 25 and the unit is duration of sending 1 byte. -
Page 63: I/O Tab Functions
Notify Input or Output Port Change When input or output port is changed, you can receive an email for notification from CIE-H14 using SMTP protocol. When ports you selected are changed, status of CIE-H14 is sent to the Email address you entered. -
Page 64: Valid Time
8.4.2 Valid Time CIE-H14 only recognizes signals of the input ports as the valid signals when the signal lasts for the [Valid Time]. If the signals are not maintained for the [Valid Time], the input signals will be ignored. The unit used for the [Valid Time] is 1ms. However, because the accuracy is only guaranteed in 10ms, the designated values are rounded down in units of 10ms. -
Page 65: Self-Test In Trouble
CIE-H14 User Manual Ver. 1.1 Self-Test in Trouble When users are in trouble with using CIE-H14, make sure of the following steps first. Searching problem with ezManager Confirming types of configuration utility CIE-H14 can be configured by ezManager. Cancelling the Firewall operation In case of being blocked by firewalls of a personal computer or network block, you must cancel all the firewalls before searching CIE-H14. -
Page 66: Connection Problem Over Modbus/Tcp
Port, Subnet Mask, Gateway IP Address, DNS IP Address, DDNS option and etc. Table 9-1 major parameters related with Modbus/TCP PING Test Confirm the connection over the network by PING test. If CIE-H14 does not send any reply from the request, check the network environment. Firewall In case the networks which need strong security, the access may be denied by their firewall. -
Page 67: Communication Problem Over Modbus/Tcp
Port Base Address], [Poll Interval] and [Notify Input change]. Checking which mode is using In case of MACRO or serialized Modbus/TCP, you can control the outputs of CIE-H14. Turn the mode off if those modes are using. Contact us if you have any questions about above steps or our products. -
Page 68: 10 Related Material
CIE-H14 User Manual Ver. 1.1 10 Related material 10.1 Technical Documents You can find the following technical documents at our website. Datasheet Modbus/TCP protocol Internet switch Serial switch Combinations of I/O Controllers Digital Pulse Output ... -
Page 69: 11 Technical Support And Warranty
11 Technical Support and Warranty 11.1 Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: E-mail: support@eztcp.com... -
Page 70: 12 Precaution And Exemption From Liability
CIE-H14 User Manual Ver. 1.1 12 Precaution and Exemption from Liability 12.1 Precaution Sollae Systems is not responsible for product failures occurring due to user ’s alternation of the product. Specifications of the product are subject to change without prior notice for performance improvement. -
Page 71: 12.2 Exemption From Liability
Sollae Systems Co., Ltd. and its distributors entire liability and your exclusive remedy shall be Sollae Systems Co., Ltd. and its distributors option for the return of the price paid for, or repair, or replacement of the CIE-H14. - Page 72 à caractère commercial ou de toute autre perte financière) provenant de l'utilisation ou de l'incapacité à pouvoir utiliser le boîtier CIE-H14, même si Sollae Systems Co., Ltd. ou un de ses distributeurs a été informé de la possibilité de tels dommages.
- Page 73 CIE-H14 sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier CIE-H14 puisse être échangé au titre de la garantie.
-
Page 74: 13 History
CIE-H14 User Manual Ver. 1.1 13 History Date Version Comment Author 2013.08.21 ○ Initial Release Amy Kim 2014.01.15 ○ Add comment of Users’ Web Page document. Amy Kim - 73 - http://www.ezTCP.com...
