- Page 1 73-1733-250 9/04 Lionel Jones & Laughlin Steel Slag Train Owner’s Manual...
-
Page 2: Table Of Contents
Replacing the traction tires Servicing your locomotive’s lamps Servicing the slag car lamps Notes Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ® , TrainMaster ®... -
Page 3: Transformer Operations Running Your Train Set With A Lionel Transformer
Move ‘em out! Get your train set moving. Press the DIRECTION button on your Lionel transformer. This command sequences the locomotive’s reverse unit to the next operating state in the repeating sequence: forward, neutral, reverse, and neutral. -
Page 4: Locking Your Locomotive Into A Single Operational State
Transformer operations Locking your locomotive into a single operational state he electronic reverse unit inside your Lionel locomotive acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. -
Page 5: Sounding Your Locomotive's Whistle
ON/OFF switch is in the ON position. Refer to Figure 1 on page 4 for the location of that switch. If your controller does not have a WHISTLE button, install a Lionel Sound Activation Button (available separately, part no. 610-5906-001). Connect the button as shown in Figure 2. -
Page 6: Uncoupling Your Locomotive
Transformer operations Uncoupling your locomotive our locomotive is equipped with two magnetic couplers, which are designed for use with Remote-Control Track sections (available separately, 6-65149 or 6-12746 for O-27 gauge; 6-65530 for O gauge; or 6-12020 for FasTrack layouts). To uncouple your locomotive, simply position the uncoupling trigger over the magnet on the Remote-Control Track section and press UNCOUPLE on the controller. -
Page 7: Uncoupling The Slag Cars
Transformer operations Uncoupling your slag cars he slag cars feature magnetic couplers. To operate the couplers by hand, slide the uncoupling tab on the side of the coupler arm towards the car. Do not push down on the tab. To operate the couplers with a Remote-Control Track section (available separately, 6- 65149 or 6-12746 for O-27;... -
Page 8: Maintaining And Servicing Your Train Set Adding Smoke Fluid To The Smoke Generator
Maintaining and servicing your train set Adding smoke fluid to the smoke generator our locomotive is equipped with a smoke generator that produces clean, white smoke. The smoke unit will operate only if the smoke unit switch is in the ON position. Refer to Figure 1 on page 4 for the switch location. -
Page 9: Lubricating Your Locomotive
We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do), and avoid getting grease or oil on the locomotive’s wheels or your track. -
Page 10: Replacing The Traction Tires
Because of the delicate soldering operations required, we recommend that you have the lamps serviced at an authorized Lionel Service Center. Refer to the Service Center list that is included with this unit. -
Page 11: Notes
Notes... -
Page 12: Limited Warranty/Lionel Service
Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
