Unitest Hexagon 710 Instruction Manual page 74

Technical Data
DC Current
Measurement Range
500,00 mA
5000,0 mA
50,000 mA
500,00 mA
5,0000 A
10,000 A*
* 10 A continuous, 20 A for max. 30 s including 5 min cooling down
AC, AC/DC Current
Range
50...60 Hz
500,00 mA
5000,0 mA
50,000 mA
500,00 mA
5,0000 A
10,000 A*
40Hz..1kHz
500,00 mA
5000,0 mA
50,000 mA
500,00 mA
5,0000 A
10,000 A
1kHz..10kHz
500,00 mA
5000,0 mA
50,000 mA
500,00 mA
5,0000 A
10,000 A
* 10 A continuous, 20 A for max. 30 s including 5 min cooling down
74
Accuracy
± (0,15% rdg. + 20 D) 0,15 mV/mA
± (0,1% rdg. + 20 D)
± (0,15% rdg. + 10 D) 3,3 mV/mA
± (0,1% rdg. + 20 D)
± (0,5% rdg. + 10 D)
± (0,5% rdg. + 20 D)
Hexagon 710
± (1,0% rdg. + 40 D) ± (0,5% rdg.
± (1,0% rdg. + 40 D) ± (0,7% rdg.
not specified
Apparent Voltage
0,15 mV/mA
3,3 mV/mA
0,03 V/A
0,03 V/A
Hexagon 720 Apparent Voltage Overload Protection
0,15 mV/mA
0,15 mV/mA
3,3 mV/mA
+ 50 D) 3,3 mV/mA
0,03 V/A
0,03 V/A
0,15 mV/mA
0,15 mV/mA
3,3 mV/mA
+ 50 D) 3,3 mV/mA
0,03 V/A
0,03 V/A
0,15 mV/mA
± (2,0% rdg. 0,15 mV/mA
+ 50 D) 3,3 mV/mA
3,3 mV/mA
not specified 0,03 V/A
not specified 0,03 V/A
Overload Protection
0,63 A / 500 V (710)
1 A / 600 V (720)
12,5 A / 500 V (710)
15 A / 1 kV (720)
0,63 A / 500 V
(Hexagon 710)
1 A / 600 V
(Hexagon 720)
12,5 A / 500 V (710)
15 A / 1 kV (720)
0,63 A / 500 V
(Hexagon 710)
1 A / 600 V
(Hexagon 720)
12,5 A / 500 V (710)
15 A / 1 kV (720)
0,63 A / 500 V
(Hexagon 710)
1 A / 600 V
(Hexagon 720)
12,5 A / 500 V (710)
15 A / 1 kV (720)
