9.0 Technical Data

Display: ..................................4
V DC Display: ..........................5
Hz Display: ..............................6 digit LCD
Total display:............................50.000 digits
V DC total display: ..................500.000 digits
Hz total display: ......................999.999 digits
Analogue display: ....................bargraph display with 42 segments
Display rate numerical display: 5 measurements/s (4
Measurement rate bargraph display: 60 measurements / s
Polarity indication: ..................automatic
Overload display: .....................0L is displayed
Battery condition display: ......battery symbol is displayed (< ap-
Automatic power off: ..............after approx. 17 minutes (can be
Overvoltage classes:
UNITEST Hexagon 710
V / R: ......................................CAT III / 1000 V AC/DC
A: ............................................CAT III / 500 V AC, 300 V DC
mA / µA: ..................................CAT III / 500 V AC, 300 V DC
UNITEST Hexagon 720
V / R: ......................................CAT III / 1000 V AC/DC
A: ............................................CAT III / 1000 V AC/DC
mA / µA: ..................................CAT III / 600 V AC, 300 V DC
Degree of contamination: ........2
Transient protection:................8 kV (1.2/50 ms Surge)
Power supply:..........................9 V battery, IEC 6LR61
Current consumption:..............approx. 5 mA (typical)
Current consumption (Auto Power Off): approx. 20 mA
dimensions: ............................198x97x55 mm incl. holster
Weight: ....................................approx. 500 g (incl. holster)
Technical Data
/
3 digit LCD
4
/
3 digit LCD
4
1.25 measurements/s (5
prox. 7V)
disabled)
/
3
digits)
4
/
3
digits)
4
69
