Manual
BlueSolar Pro Remote Panel
For BlueSolar PWM-Pro charge controllers 12/24V 5, 10, 20, 30A
Article number SCC900300000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BlueSolar Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Victron energy BlueSolar Pro

  • Page 1 Manual BlueSolar Pro Remote Panel For BlueSolar PWM-Pro charge controllers 12/24V 5, 10, 20, 30A Article number SCC900300000...
  • Page 3: Table Of Contents

    Contents 1.Important safety instructions ……….... 2 2. Installation ............. 2 3.Product features..........3 3.1 General ............ 3 3.2 Display ............ 5 3.3 Buttons ............ 6 4. Monitoring ............6 5. Full setup details ........... 8 5.1 Main menu ..........8 5.2 Device Information .........
  • Page 4: Important Safety Instructions

    1. Important safety instructions Read all instructions before starting the installation. Keep the controller away from rain, exposure, severe dust, vibration, corrosive gas and intense electromagnetic interference. 2. Installation Please see section 8 for mounting dimensions Connection to the BlueSolar PWM-Pro charge controller: The panel must be connected to the controller with a standard RJ45 UTP cable.
  • Page 5: Product Features

    3. Product features 3.1. General Warning LED Communication LED Audible Alarm Display LCD screen Buttons...
  • Page 6 RS485 communication and power interface Warning LED The warning indicator LED flashes in case of failure of the connected charge controller. Audible alarm The audible failure alarm can be activated or deactivated. Communication LED Indicates communication status when the display is connected with the charge controller.
  • Page 7: Display

    3.2. Display After connecting the remote panel, the default monitoring display will be shown: Charge current icon Battery status icons Load status icon Day/night. Battery icon Load current icon PV- V & A. Battery-V&A Load-V&A Day and night icons - Night ,...
  • Page 8: Buttons

    Battery status icons - Normal voltage. - Under voltage - Over discharge , Load status icon - Load output “on” - load output “off” 3.3. Buttons Operation is visualized in the schematic diagram below: 4. Monitoring The default monitoring display and monitoring subpages can be accessed with the UP/DOWN and LEFT/RIGHT buttons.
  • Page 10: Full Setup Details

    5. Full setup details 5.1. Main menu When in monitoring mode, the main menu is accessed by pressing the ESC button. The UP and DOWN buttons are used to browse through the main menu: 1 Monitoring 2 Device information 3 Test operation 4 Control parameters 5 Load set 6 Device parameters...
  • Page 11: Control Parameters

    The manual control function is disabled when other load output settings are chosen (see section 5.5). However, when other load output settings have been chosen, the load output can be tested (i.e. switched ON and OFF) after switching back to Manual Control. 5.4 Control Parameters The table below shows the list of battery related parameters that can be modified.
  • Page 12: Load Settings

    5.5 Load output setting The load output setting options are shown below: Manual Control M anual Control ◎ Default : L ight On/Off ◎ L ight On+Timer ◎ ◎ T ime Control M anual Control ◎ Light On/Off On: 0.5V DeT: 10M L ight On/Off ◎...
  • Page 13 Option 2: Light On/Off This is a simple load output On/Off option, based on the solar input voltage of the Controller (= output voltage of the solar panel). When, at dusk, the input voltage of the Controller becomes • lower than the light On voltage (default 0.50V), the load output is switched on.
  • Page 14: Device Parameters

    Option 4: Time control This option uses the internal clock (see section 5.6) to set one (Time1 only) or two on-time periods. 5.6 Device Parameters The first screen displays the software version Device Parameter Ver: VX.XX and communication ID number of the Charge ID : XXX Controller.
  • Page 15: Failure Information

    5.10 Failure Information Displays failures such as Over Voltage, Over Load or Short Circuit. (automatic reset when the fault is corrected). 5.11 Parameters The first screen displays the type, software version and serial number of the remote meter. The second screen allows modification of Switch-Pages (refresh time interval of the monitoring pages, •...
  • Page 16: Dimensions

    8 Dimensions:...
  • Page 18 Serial number: Serial number: Version : 02 Date : 01 September 2014 Victron Energy B.V. De Paal 35 | 1351 JG Almere PO Box 50016 | 1305 AA Almere | The Netherlands General phone : +31 (0)36 535 97 00...
