Handlink Technologies WG-602 User Manual

Easy hotspot kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

WG-602/WG-602P
Easy Hotspot Kit
User's Manual
Handlink Technologies Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WG-602 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Handlink Technologies WG-602

Summary of Contents for Handlink Technologies WG-602

  • Page 1 WG-602/WG-602P Easy Hotspot Kit User’s Manual Handlink Technologies Inc.
  • Page 2 Copyright Notice Copyright © 2005-2015 Handlink Technologies Inc. All rights reserved. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission. Protected by TW patent 223184, JPN patent 3099924 and China patent ZL 03 2 04640.5.

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction............................4 1-1 Package Contents ......................... 4 1-2 Features ............................5 1-3 Precautions............................ 5 1-4 Outlook ............................5 1-4-1 Top Panel .......................... 6 1-4-2 Rear Panel ........................7 1-5 Technical Specifications......................... 8 1-5-1 Hardware Specifications....................8 1-5-2 Software Specifications ....................
  • Page 4 3-2-17 DDNS ..........................129 3-2-18 LAN Devices ......................... 131 3-2-19 Syslog ........................... 133 3-2-20 Session Trace ....................... 140 3-2-21 Bandwidth........................141 3-2-22 Secure Remote ......................142 3-2-23 SNMP ..........................143 3-2-24 Wireless ........................145 3-2-25 MISCELLANEA ......................149 3-3 System Status..........................150 3-3-1 System ..........................

  • Page 5: Introduction

    (HTTP Proxy) or load any special software to access hotspot service. It’s completely Plug’ Play with any browser. 1-1 Package Contents Please inspect your package. The following items should be included: ◎ WG-602 One Wireless Subscriber Gateway Two antennas One AC Power Adapter for Wireless Subscriber Gateway One CD containing User’s Manual and MIB file...

  • Page 6: Features

    1-2 Features Wireless data rates up to 54Mbps Supports 100 Simultaneous Users IP Plug and Play (iPnP) Comprehensive security 64/128-bit WEP encryption WPA encryption IP/URL filtering Intelligent Management Built-in AAA (Authentication/Accounting/Authorization) and Billing mechanism Note: The "PnP" Function only can be used with TCP/IP-based Network. 1-3 Precautions Never remove or open the cover.

  • Page 7: Top Panel

    1-4-1 Top Panel The top panel of the Wireless Subscriber Gateway is shown below. Figure 1-2 Wireless Subscriber Gateway Top Panel Figure 1-3 LEDs Easy Hotspot Kit...

  • Page 8: Rear Panel

    LEDs Indication State Description The Wireless Subscriber Gateway is not receiving electrical power. Green The Wireless Subscriber Gateway is receiving electrical power. The Wireless Subscriber Gateway status is defective. Green The Wireless Subscriber Gateway status is complete. Green (Blinking) During firmware upgrades, this system LED will blink. Port has not established any network connection.

  • Page 9: Technical Specifications

    1. RS-232: Reserve for manufacture use. 2. LAN (1-4): The rear panel supports four auto-sensing RJ-45 ports and all ports can be auto-switched to MDI-II connections. The LAN ports used for linking hosts or other network devices. The individual port can be either connected to 100BaseTX networks or 10BaseT networks.
  • Page 10 LED Indicators One POWER LED One WAN 10/100M Link/Activity LED Four LAN 10M/100M Link/Activity LEDs One Wireless Link/Activity LED One System LED Power Requirement External Power Adapter Input: 100-240 VAC, 50/60 Hz Output: 5V, 2A Environment Conditions Operating Temperature: 0 to 50°C Storage Temperature: -10 to 60°C Operating Humidity: 10~80% non-condensing Storage Humidity: 10% to 90% non-condensing...

  • Page 11: Software Specifications

    1-5-2 Software Specifications Networking • IEEE802.3 10BaseT Ethernet • IEEE802.3u 100BaseTX Fast Ethernet • IEEE802.3af Power over Ethernet • IEEE802.11b Wireless LAN • IEEE802.11g Wireless LAN • Supports 100 Simultaneous Users • IP Plug and Play (iPnP) • HTTP Proxy Support •...
  • Page 12 Security and Firewall • Layer 2 Isolation Security • SSL User Login page/ Configuration Page • SSL Administration • VPN Pass through (IPSec/PPTP) • Customize SSL Certificate • Pass Through IP/MAC/URL Address • Restricted Destination Filtering IP/URL • VPN (IPSec/PPTP) Pass through •...

  • Page 13: Installation

    2. Installation The followings are instructions for setting up the Wireless Subscriber Gateway. Refer to the illustration and follow the simple steps below to quickly install your Wireless Subscriber Gateway. Wall-Mounting The Wireless Subscriber Gateway can be wall-mounted on a wall by applying the two mounting brackets on screws.

  • Page 14: Connecting The Antennas

    2-2 Connecting the Antennas The Wireless Subscriber Gateway provides two antenna connectors on the rear of the unit. Figure 2-3 Antenna Connectors 2-3 Installation Requirements Before installing the Wireless Subscriber Gateway, make sure your network meets the following requirements. System Requirements The Wireless Subscriber Gateway requires one of the following types of software: Windows 98 Second Edition/NT/2000/XP Red Hat Linux 7.3 or later version...
  • Page 15 ISP Requirements Verify whether your ISP use fixed or dynamic IP. If it is a fixed IP, be sure to get the IP from your ISP. For dynamic IP, which is mostly used, the PC will get the IP automatically whenever it hooks up on the modem.

  • Page 16: Getting Start

    Getting Start 1. Place the Wireless Subscriber Gateway and AG-200E Printer on a flat work surface. 2. Connect the Ethernet cable to the Wireless Subscriber Gateway’s LAN port. 3. Connect the other end of the Ethernet cable to the AG-200EAccount Generator Printer’s RJ45 port. 4.

  • Page 17: Poe Application

    POE (Power over Ethernet) Application Figure 2-6 POE Connection Note: To use the WG-601’s POE feature, follow the instructions for your specific POE device. Easy Hotspot Kit...

  • Page 18: Configuring The Wireless Subscriber Gateway

    3. Configuring the Wireless Subscriber Gateway Setting Wizard Step 1: Start your browser, and then enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 3-1 Web Browser Location Field (Factory Default) Step 2: The Wireless Subscriber Gateway configuration tools menu will appear. In the Username and Password field, type the factory default user name admin and password admin and click Login.
  • Page 19 Figure 3-4 System Quick View Click on reset button to clear the username and password data. Note: This Web agent is best viewed with IE 5.0 or Netscape 6.0 and above browsers. If you would like to change the password please see Step 10. Username and Password can consist of up to 20 alphanumeric characters and are case sensitive.
  • Page 20 Step 3: Internet Connection Setting Select the appropriate Internet connection type to connect to your ISP. +igure 3-5 Internet Connection Setting Screen DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP.
  • Page 21 Static IP Setting If Static IP Setting is selected, then this screen will appear. Enter the IP address information provided by your ISP. Figure 3-7 Internet Connection Setting Screen—Static IP Setting Item Default Description IP Address 0.0.0.0 Enter the IP address provided by your ISP. Subnet Mask 0.0.0.0 Enter the subnet mask for the IP address.
  • Page 22 PPPoE (Point-to-Point Protocol over Ethernet) If “PPPoE” is selected, then this screen will appear. Enter the username, password and other major fields. Figure 3-8 Internet Connection Setting Screen—PPPoE Setting Item Default Description Enter the user name provided by your ISP. The user name can consist Username Empty of up to 80 alphanumeric characters and is case sensitive.
  • Page 23 Item Default Description Connect on Demand and Max Idle Time Connect on You can configure your Wireless Subscriber Gateway to cut your Enable Demand connection with your ISP after a specified period of time (Max Idle Time). If you have been disconnected due to inactivity, Connect on Demand enables your Wireless Subscriber Gateway to automatically re-establish your connection as soon as you attempt to access the Internet again.
  • Page 24 PPTP Client (Point-to-Point Tunneling Protocol) If “PPTP” is selected, then this screen will appear. Fill out all the information provided by your ISP. Figure 3-9 Internet Connection Setting Screen—PPTP Client Setting Item Default Description My IP Address Empty Enter the PPTP local IP address provided by your ISP. Enter the PPTP local Subnet Mask IP address for the IP My Subnet Mask Empty...
  • Page 25 Item Default Description Enter the PPTP server Gateway IP address provided by your Gateway IP Address Empty ISP. PPTP Server IP Address Empty Enter the PPTP server IP address provided by your ISP. Enter the user name provided by your ISP. The user name Username Empty can consist of up to 80 alphanumeric characters and is case...
  • Page 26 Step 4: Wireless Setting This page allows you to define ESSID, Channel ID and WEP/WPA encryption for wireless connection. Figure 3-10 Wireless Setting Screen Item Default Description ESSID Wireless The ESSID is the unique name that is shared among all points in a wireless network.
  • Page 27 Step 5: E-mail Server Setting Wireless Subscriber Gateway allows an extra Email server parameter to forward the subscriber’s E-mail. Figure 3-11 E-mail Service Setting Screen Item Default Description Email Server Redirect Disables or enables email server redirect function. To prevent some subscriber’s original Email server may protect by firewall or NAT network.
  • Page 28 Step 6: Authentication Service Setting Figure 3-12 Authentication Service Setting Screen Item Default Description Yes― Built-in Authentication/ No Authentication No Authentication) Wireless Subscriber Gateway provides Built-in Authentication for service provider to build up an Internet service without any extra authentication software.
  • Page 29 Step 7: Billing Profile Setting The function is used to setup a billing profile. A billing profile is a description of how you want to charge your customer. Figure 3-13 Billing Profile Setting Screen Item Default Description Time to Finish Options: Time to Finish or Accumulation. Service Time to Finish―...
  • Page 30 Item Default Description Currency Enter the appropriate currency unit or currency symbol. Number of Enter the billing decimal value. The field maximum value is 3. decimals places 01~03 The index number of billing profile. In Wizard setup, we provide only 3 billing profile.
  • Page 31 Button B Button A Button C Figure 3-15 Account Generator Printer Step 9: Accounting Setting Three-buttons Printer Setting Figure 3-16 Accounting Setting Screen (Three Buttons Printer) Easy Hotspot Kit...
  • Page 32 Name Charge Usage Time Figure 3-17 Billing Profile Setting Screen Item Default Description Define each button’s billing profile. Select one billing profile Button A~ C by clicking in the list box. Printout The system allows you to print all your bills. This value is Number of copies to print number of copies.
  • Page 33 Web-based Account Generator Setting Figure 3-18 Web-based Account Generator Setting Screen Item Default Description Billing Profile (Button Define each button’s billing profile. Select one billing profile by clicking A~C) in the list box. Printout Number of copies to The system allows you to print all your bills. Select one print number of copies by clicking in the list box.
  • Page 34 Item Default Description Password account Enter the password for web-based account generator. The password can consist of up to 80 alphanumeric characters and is case sensitive. Confirm Empty Enter the password for confirmation. Click on button to preview and operate account generator panel. Button A Button B Button C...
  • Page 35 Figure 3-20 Example-Account Printout Easy Hotspot Kit...
  • Page 36 Click “View Account List” to display current account information. Figure 3-21 Account List Click on refresh button to update the account list page. The field name button in this list show that this list can be sorted in ascending/descending order according to the corresponding field name.
  • Page 37 Customize Printout Text This function allows you to produce custom bill based on your requirements. Figure 3-22 Customize Printout Text Setting Screen Click the button to displays the account on the screen as it would appear when printed. Easy Hotspot Kit...
  • Page 38 Figure 3-23 Example- PC-connected printer Printout (Time to Finish) Figure 3-24 Example- PC-connected printer Printout (Accumulation) Easy Hotspot Kit...
  • Page 39 Figure 3-25 Example- Account Generator Printer Printout (Time to Finish) Figure 3-26 Example- Account Generator Printer Printout (Accumulation) Easy Hotspot Kit...
  • Page 40 Figure 3-27 Example-Post-paid Printout Easy Hotspot Kit...
  • Page 41 Step 10: System Setting Figure 3-28 System Setting Screen Item Default Description Username admin Enter the user name. The user name can consist of up to 80 alphanumeric characters and is case sensitive. Password admin Enter the user password. The password can consist of up to 80 alphanumeric characters and is case sensitive.

  • Page 42: Advanced Setup

    Advanced Setup The Advanced Setting enables you to configure advanced settings related to accessing the Internet, including, System WAN/LAN Server Authentication RADIUS Billing Accounting Credit Card Keypad 10. Customization 11. Pass Through 12. Filtering 13. Share 14. Portal Page 15. Advertisement 16.

  • Page 43: System

    3-2-1 System Define the Wireless Subscriber Gateway System configuration. Figure 3-30 System Setting Screen Easy Hotspot Kit...
  • Page 44 Figure 3-31 System Setting Screen Item Default Description The system name can consist of up to 40 System/Host Name Empty alphanumeric characters. The Domain name can consist of up to 80 Domain Name Empty alphanumeric characters. Location Information Empty Enter your location information. Date/Time System The system date of the Wireless Subscriber Gateway.
  • Page 45 Item Default Description Enables or disables NTP (Network Time Protocol) Time Server. Network Time Protocol can be utilized to NTP Setting Disable synchronize the time on devices across a network. A NTP Time Server is utilized to obtain the correct time from a time source and adjust the local time.

  • Page 46: Wan/Lan

    Item Default Description Option: default or customize certificate, These are two ways to create a certificate, one is purchase a SSL Certificate Default certificate from a certificate authority (Ex. Verisign or Thawte), and another is creating a self-certificate (For example: Uses OpenSSL tool). Click Apply button to save the new settings.
  • Page 47 Figure 3-34 Restart Dialog Box Device IP (LAN IP) Setting Figure 3-35 Device IP (LAN IP) Setting Item Default Description IP Address 10.59.1.1 The internal LAN IP address of your Wireless Subscriber Server Gateway. Subnet Mask 255.0.0.0 Enter the subnet mask for the IP address. WAN MAC Address Figure 3-36 WAN MAC Address Setting Item...
  • Page 48 DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP. If your xDSL/Cable comes with this feature, please enable Use DHCP Client. Figure 3-38 DHCP Client Setting Screen Static IP Figure 3-39 Static IP Setting Screen Item...
  • Page 49 PPPoE Figure 3-40 PPPoE Setting Screen Item Default Description User Name Empty Enter your PPPoE account name. The user name can consist of up to 80 alphanumeric characters and is case sensitive. Password Empty Enter your PPPoE password. The password can consist of up to 80 alphanumeric characters and is case sensitive.
  • Page 50 Item Default Description Service Name Empty Enter the service name provided by your ISP. The service name can consist of up to 64 alphanumeric characters and is case sensitive. Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your Wireless Subscriber Gateway to cut your connection with your ISP after a specified period of time Max Idle Time...
  • Page 51 PPTP Figure 3-41 PPTP Setting Screen Item Default Description My IP Address Empty A PPTP local IP address for the xDSL/Cable connection (provided by your ISP). My Subnet Mask Empty Enter the PPTP local IP address for the xDSL/Cable connection. Gateway IP Address Empty A PPTP local default gateway for the xDSL/Cable...
  • Page 52 Item Default Description Password Empty Enter your PPTP password. The password can consist of up to 80 alphanumeric characters and is case sensitive. PPP MTU Setting 1460 MTU (Maximum Transfer Unit) specifies maximum transmission unit size. TCP MSS Setting 1400 MSS (Maximum Segment Size) specifies maximum segment size.

  • Page 53: Server

    3-2-3 Server Figure 3-42 Server Setting Screen Item Default Description Web Server Enter the HTTP port number. The HTTP port allowed range is 80 or 8010 to 8060. For access the Wireless HTTP Port Subscriber Gateway system under NAT, please tab the “http://HTTP Port IP Address: Port Number”.
  • Page 54 Item Default Description There are three types of DHCP Services. DHCP Disable—Disable the DHCP server function. DHCP Server Enable DHCP Relay—Enable DHCP Relay function. DHCP Server—Enable DHCP server function. To route DHCP through an external server, the administrator needs to DHCP Relay enable the DHCP relay and assign a valid DHCP server IP address.

  • Page 55: Authentication

    3-2-4 Authentication Figure 3-43 Authentication Setting Screen Item Default Description Authentication Type Option: No Authentication, Built-in Authentication or User Authentication Agreement. No Authentication― Subscriber can direct access the Internet without enter username and password. Easy Hotspot Kit...
  • Page 56 Item Default Description Built-in Authentication― Authentication Type Authentication Wireless Subscriber Gateway provides “Built-in Authentication” for service provider to build up an Internet service without any extra authentication software. If “Built-in Authentication” is selected, service provider can generate subscriber account inside Wireless Subscriber Gateway, and the system will authenticate the subscriber login according to the generated account.
  • Page 57 Copy and paste the following HTML Code into your home page to produce user agreement login page. Figure 3-44 Preview Redirect Login Page Code Item Default Description SSL Login Page Disable Enables or disables SSL security of login page. User Idle Time Out 5 Minutes The user idle time out valid range is 1-1440.

  • Page 58: Radius Authentication

    3-2-5 RADIUS Authentication Figure 3-45 Authentication Setting Screen Easy Hotspot Kit...
  • Page 59 Item Default Description RADIUS Authentication Disable Option: No Authentication or RADIUS Server. Disable (No Authentication) ― Subscriber can direct access the Internet without enter username and password. Enable (RADIUS Authentication) ― Wireless Subscriber Gateway provides “RADIUS Authentication” for service provider to build up an Internet service with RADIUS server.
  • Page 60 Item Default Description Retry Frequency ~ The field default value is 3 seconds. Seconds Accounting Service Enable Enables or disables the accounting service. Interim Update Time 5 Minutes Specify the interim update time. Authentication Method CHAP Enter the authentication method of RADIUS server. WISPr Smart Client Enable Disable...

  • Page 61: Billing

    3-2-6 Billing The function is used to setup a billing profile. A billing profile is a description of how you want to charge your customer. Figure 3-46 Billing Setting Screen Item Default Description Pre-Paid Enable The subscribers can access Internet with pre-defined usage time. Easy Hotspot Kit...
  • Page 62 If you change billing mode (Pre-paid Post-paid or Post-paid Pre-paid), the system will erase all account and disconnect all on-line users. Figure 3-47 Message Box Item Default Description Enable Credit Card Service Disable Enables or disables the credit card service. Before you enable credit card service, make sure that your credit service is configured to work and the currency is American dollars.
  • Page 63 Figure 3-48 Credit Service Setting Screen Figure 3-49 Error Dialog Box (Credit Card Service=Enable) Item Default Description Time to Finish Enable The subscriber can access Internet only one time with one account. Once subscriber login, the pre-defined usage time will start until run out even the subscriber stop to access the Internet before run out.
  • Page 64 Item Default Description Accumulation Accumulation Disable The subscriber can access Internet many times with one account. The system can keep and accumulate every single usage time until the pre-defined usage time run out. Idle Time Out 5 Min(s) The idle time out valid range is 1-1440. If the idle time out is set as 5 minutes, it means if the account doesn’t send packet in 5 minutes, the account will logout automatically.
  • Page 65 Item Default Description +1~+10 The index number of billing profile. In Advanced setup, we provide 10 billing profile. Active Click on check box, active or inactive the billing profile. Name It is the name of billing profile. The maximum allowed characters length is 12.
  • Page 66 Figure 3-52 Post-paid Procedure Diagram Click Apply button to save the new settings. Click Apply button, the success dialog box appears. Click on Back to return to Billing setting screen. Figure 3-53 Success Dialog Box Easy Hotspot Kit...

  • Page 67: Accounting

    3-2-7 Accounting This function allow service provider to generate the subscriber accounts. Figure 3-54 Accounting Setting Screen Easy Hotspot Kit...
  • Page 68 Figure 3-55 Item Default Description Expiration Un-used account will be 12 hours Enter the number of hours/minutes/days. The field maximum deleted after ~hours value is 30 hours/minutes/days. automatically Accumulation account 3 months Enter the number and select time unit from list box. The field will be deleted after maximum value is 30 month/ days/ hours.
  • Page 69 Figure 3-56 Account Process Diagram Can be replenished by subscriber=Enable Three-Button Printer/ Web-based Account Generator Panel Figure 3-57 Three-Button Printer/ Web-based Account Generator Panel Setting Screen Item Default Description Button A~C Define each button’s billing profile. Select one billing profile by clicking in the list box. Print to…...
  • Page 70 Item Default Description Use ~ for Discount Button A, Select one button (A~C) by clicking in the list box to Price Plan based on Disable assign the base charge and select enable to active the “Button Presses” discount price plan. Click on button to preview and operate account generator panel.
  • Page 71 Figure 3-60 PC-connected Printer Printout (Time to Finish) Easy Hotspot Kit...
  • Page 72 Figure 3-61 Web-based Account Generator Printout (Accumulation) Easy Hotspot Kit...
  • Page 73 Figure 3-62 PC-connected Printer Printout (Accumulation) Note: Before configuring the accounting, you have to setting the billing profile of Web-based account generator panel. Easy Hotspot Kit...
  • Page 74 Example: If press 7 times Discount Price Plan based on “Button Presses” is disabled. Figure 3-63 Example 1 Amount: 7 x $2.00= $14.00 Figure 3-64 Account Printout Easy Hotspot Kit...
  • Page 75 Discount Price Plan based on “Button Presses” is enabled. The Charge by level is disabled. Figure 3-65 Example 2 Amount: 7 x $ 1 = $ 7.00 Easy Hotspot Kit...
  • Page 76 Below is an example of the account printout. Figure 3-66 Account Printout Easy Hotspot Kit...
  • Page 77 Discount Price Plan based on “Button Presses” is enabled. Charge by level is enabled. Figure 3-67 Example 3 Amount: 2 x $2.00 + 4 x$ 1.50+1x$1= $11.00 Easy Hotspot Kit...
  • Page 78 Below is an example of the account printout. Figure 3-68 Account Printout Easy Hotspot Kit...
  • Page 79 Discount Price Plan based on “Button Presses” Figure 3-69 Discount Price Plan Setting Screen Item Default Description Charge by levels Enable Enables or disables the charge by levels function. Level 1~10 This field displays the level number of charge rate. Conditions When>= The discount condition.

  • Page 80: Credit Card

    3-2-8 Credit Card Wireless Subscriber Gateway provides three credit card services (Authorize.net, iValidate.net and Secure Pay) that allow service provider to authorize, process, and manage credit transactions directly from Internet. Figure 3-71 Credit Card Setting Screen Item Default Description Authorize.net Version This field displays the merchant version.
  • Page 81 Item Default Description Need Disable If your Merchant Provider need password to authorize, click the check box to enable this function. Password Empty Enter your Merchant password. Merchant Transaction Empty The Merchant Transaction Key can be obtained directly from “Authorize.net”. The Merchant Transaction Key is similar to a password and is used by the Payment Gateway to authenticate transactions.
  • Page 82 Item Default Description Secure Server Address https://www. Enter the secure server address. vious.net/m erchant/proc esscc.asp Secure Pay Merchant ID Empty Enter your Merchant ID. This is a Merchant Identification Number that you’re received from your Merchant Provider. The maximum character of the Merchant ID is 7. SecurePay Address https://www.
  • Page 83 Please follow steps below to pay using credit card. Step 1: Choose Credit Card service on the login page. Select Credit Card Service Click Click Figure 3-73 Login Page Easy Hotspot Kit...
  • Page 84 Step 2: Select Service and enter payment information. Currency: American Dollars Figure 3-74 Service & Payment Information Setting Screen (Authorize.net) Item Default Description Payment Information Credit card number Empty Enter your credit card number. Credit card expiration date Empty Enter the credit card expiration date. The allowed format is MMYY.
  • Page 85 Figure 3-75 Service & Payment Information Setting Screen (iValidate.net) Item Default Description Payment Information Credit card number Empty Enter your credit card number. Credit card expiration date Empty Enter the credit card expiration date. The allowed format is MMYY. Enter Email Address Empty Enter your email address.
  • Page 86 Step 3: After valid payment information has been provided, the subscriber will obtain one valid account to login or the Figure 3-78 screen will appear. Figure 3-76 User Account Information Figure 3-77 Easy Hotspot Kit...

  • Page 87: Keypad

    3-2-9 Keypad Figure 3-78 Keypad Setting Screen Easy Hotspot Kit...
  • Page 88 Item Default Description Use for Pre-Paid Billing The system provides ten user definable hot keys through the use of the + Key plus the 1 through 0 keys across the top of the keypad. Keypad Hot Key +1~+0 It is the combination hot key for keypad application. Billing Profile Select the billing profile you want to assign to the combination hot key.
  • Page 89 Step 2: Click the Keypad in Advanced Setup Menu, define the Billing plan of pre-paid, and click Apply. Figure 3-80 Keypad’s Hot Key Setting Screen Step 3: You can use keypad to create subscriber accounts now. Press keypad hot key and then press Enter.
  • Page 90 Step 4: Subscriber can use this account to access Internet now. Use for Post-Paid Billing Step 1: Click the Billing in the Advanced Setup menu, select enable Post-paid, click Apply. Figure 3-82 Billing Setting Screen Step 2: Click the Keypad in Advanced Setup Menu, Define the billing plan of post-paid, click Apply. Figure 3-83 Keypad’s Hot Key Setting Screen Easy Hotspot Kit...
  • Page 91 Step 3: You can use keypad to create subscriber accounts now. Press Enter, a new subscriber account is generated, and the account information should be printed. This account information is including serial number, username, password and account create time. Figure 3-84 Step 4: When subscriber wants to terminate the Internet service, press *, serial number and then press Enter, a bill should be printed.
  • Page 92 Account Generator Printer Enter the date (MonthDate) PS/2 Keypad Figure 3-86 Keypad’s Hot Key List Daily Account Report Printout Press ABCAA Billing Profile Purchase Unit Figure 3-87 Daily Account Easy Hotspot Kit...
  • Page 93 Monthly Account Report Printout Press ABCBB Billing Profile Purchase Unit Figure 3-88 Monthly Account System Status Report Printout Press ABCCC Figure 3-89 System Status Report Printout Easy Hotspot Kit...
  • Page 94 Network Report Printout Press ABCAB Figure 3-90 Network Report Printout Easy Hotspot Kit...

  • Page 95: Customization

    3-2-10 Customization Login Page The Wireless Subscriber Gateway provides three different login page formats, including standard, redirect, advanced and frame format. Standard For some service providers, they may hope to have a customize subscriber’s login page to the users. This function helps them to realize the ideal. The page elements are including login page title, background color, subtitle etc.
  • Page 96 Item Default Description Copyright Enable The copyright is allowed the administrator to input a paragraph in the subscriber login page for copyright information. The maximum character of the copyright is 80. Background Color FFFFFF The background text color can be specified color. For the specified text color format please views the color grid.
  • Page 97 Redirect This allow service provider to redirect the subscriber’s browser to a specified home page. Figure 3-94 Redirect Login Page Setting Screen Copy and paste the following HTML Code into your home page to produce redirect subscriber login page. Figure 3-95 Redirect Login Page Code Screen Easy Hotspot Kit...
  • Page 98 Advanced This function allow user to design login page of Wireless Subscriber Gateway. Figure 3-96 Advanced Login Page Setting Screen Item Default Description Welcome Slogan Welcome The maximum allowed characters length is 80. Page Background None The page background can be none or specified color. For the background color format please views the color grid.
  • Page 99 Figure 3-97 Color Gird Frame If “Frame” is selected the subscriber login page will be separate into Top Frame and Bottom Frame. Bottom Frame is a default format for username and password input, Top Frame is allowed to be specified a URL to link. www.caesarpark.com Figure 3-98 Frame Login Page Setting Screen Item...
  • Page 100 Figure 3-99 Example-Login Page Screen Logo This function allows service provider to upload the customer’s logo image file which can be shown on the standard login page and account printout of PC-connected printer. Figure 3-100 Logo Setting Screen Item Default Description File Path Empty...
  • Page 101 Figure 3-101 Logo Setting Screen Figure 3-102 Login Page Easy Hotspot Kit...
  • Page 102 Information Window This function allow service provider can decide whether they want an “Information Window” pop-up on subscriber PC when authenticate successful or not and specified text of information window. Subscriber can type “http://1.1.1.1/info” to open the information window again or enter “http://1.1.1.1/logout”...
  • Page 103 Figure 3-104 Example-Login Page Screen Figure 3-105 Information Window Billing Type=Time to Finish Can be replenished by subscriber=Disable Figure 3-106 Information Window Billing Type=Time to Finish Can be replenished by subscriber=Enable Easy Hotspot Kit...
  • Page 104 Figure 3-107 Information Window Billing Type=Accumulation Can be replenished by subscriber=Disable Figure 3-108 Information Window Billing Type=Accumulation Can be replenished by subscriber=Enable Easy Hotspot Kit...
  • Page 105 Figure 3-109 Information Window Super Subscriber Account (Default username=”super” & password=”super”) Figure 3-110 Logout Successfully Dialog Box Billing Type=Accumulation Figure 3-111 Alarm Dialog Box1 Easy Hotspot Kit...
  • Page 106 Account Printout This function allow service provider to specified text of account printout. Figure 3-112 Account Printout Customization Setting Screen Easy Hotspot Kit...
  • Page 107 Click Apply button to save the new settings. Click Apply button, the success dialog box appears. Click on Back to return to Account Printout Customization setting screen. Figure 3-113 Success Dialog Box Figure 3-114 PC-connected Printer Printout Easy Hotspot Kit...
  • Page 108 Figure 3-115 Account Generator Printer Printout Figure 3-116 Account Generator Printer Printout Easy Hotspot Kit...
  • Page 109 Credit Card Standard Login Page This function allow service provider to customize the additional credit card message for the standard login page. Figure 3-117 Credit Customization Setting Screen Figure 3-118 Standard Login Page (Enable Credit Card Service=enable) Easy Hotspot Kit...
  • Page 110 Figure 3-119 Billing Setting Screen Easy Hotspot Kit...

  • Page 111: Customer Information

    Service Selection Page This function allow service provider to customize the additional credit card message for the standard login page. Customer Information Figure 3-120 Service Selection Page Setting Screen (Authorize.net) Easy Hotspot Kit...
  • Page 112 Figure 3-121 Service Selection Page Setting Screen (iValidate.net) Easy Hotspot Kit...
  • Page 113 Figure 3-122 Service Selection Page Setting Screen (Secure Pay) Easy Hotspot Kit...
  • Page 114 Figure 3-123 Service Selection Page (Authorize.net) Easy Hotspot Kit...
  • Page 115 Figure 3-124 Service Selection Page (iValidate.net) Easy Hotspot Kit...
  • Page 116 Figure 3-125 Service Selection Page (SecurePay) Easy Hotspot Kit...
  • Page 117 Successful Page Figure 3-126 Successful Page Setting Screen Easy Hotspot Kit...
  • Page 118 Figure 3-127 Example-Successful Page Fail Page This function allow service provider to customize the message for the fail page. Figure 3-128 Fail Page Setting Screen Click Apply button to save the new settings. Easy Hotspot Kit...
  • Page 119 Figure 3-129 Fail Page Click Apply button, the success dialog box appears. Click on Back to return to Credit Card Customization setting screen. Figure 3-130 Success Dialog Box Easy Hotspot Kit...
  • Page 120 User Agreement Page This function allow user to design user agreement page of Internet Subscriber Server. Figure 3-131 User Agreement Page Setting Screen Figure 3-132 User Agreement Page Easy Hotspot Kit...

  • Page 121: Pass Through

    3-2-11 Pass Through This function allow administrator to set some special devices pass through the Wireless Subscriber Gateway system. Because some network devices might be constructed under the Wireless Subscriber Gateway. However these devices needn’t be checked and authorized. The Wireless Subscriber Gateway provides a pass through list and the administrator can control which devices can be pass through with authentication.
  • Page 122 Item Default Description Pass Through Disable Enables or disables the pass through function. Destination URL/IP Address Pass Through URL or Website Empty Enter the URL Page; please use this format such like “http://www.yahoo.com”. The maximum character of the URL Page is 50.

  • Page 123: Filtering

    3-2-12 Filtering Filtering allows the system administrator to have a list of restricted destinations, which is useful to block specified Internet websites or Intranet areas. Figure 3-134 Filtering Setting Screen Item Default Description Filtering Disable Enables or disables filtering function. HTTP Message The Web Site Enter the http message.
  • Page 124 Item Default Description Restrict Destination URL or Website Empty Enter the URL Page of you wants to filter; please use this format such like “http://www.yahoo.com”. The maximum character of the URL Page is 50. Start IP Address Empty Enter the start IP address of you wants to filter. End IP Address Empty Enter the end IP address of you wants to filter.

  • Page 125: Share

    3-2-13 Share This feature allows sharing the network devices after subscriber successful login. Figure 3-136 Share Device Setting Screen Item Default Description Share LAN resource Disable Enables or disables share LAN resource function. Resource Name Empty Enter the device name. The maximum character of the resource name is 30.

  • Page 126: Portal Page

    Note: 1. You must use the “Search IP” method to search for a device on the network. Please follow steps below to search your device. Click Start, and then click Search. Click Computers or People. Click “A computer on the network”. In Computer, type the IP address of the device you want to find.

  • Page 127: Advertisement

    3-2-15 Advertisement The system allow service provider to input 10 URL links for advertisement link purpose. Figure 3-139 Advertisement URL Link Setting Screen Item Default Description Frequency One Time One Time Only—One Time Only means to send the advertisement link Only once after the subscriber Login.

  • Page 128: Walled Garden

    Click Apply button, the success dialog box appears. Click on Back to return to Advertisement URL Link setting screen. Figure 3-140 Success Dialog Box 3-2-16 Walled Garden We prepare ten URL links that allows subscriber to access the specific Web pages even they didn’t have a username or password.
  • Page 129 Name Figure 3-142 Login Page Item Description Link 1~10 Name The name is allowed user to set the prompt string in user customize login page. The maximum allowed characters length is 80. URL 1~10 The input format can be “http://www.yahoo.com”. The maximum character of the Link# is 200.

  • Page 130: Ddns

    3-2-17 DDNS The DDNS service (Dynamic Domain Name Service), an IP Registry provides a public central database where information such as email addresses, host names, IP addresses etc. can be stored and retrieved. This solves the problems if your DNS server uses an IP associated with dynamic IP addresses. When the ISP assigns the Wireless Subscriber Gateway a new IP, the Wireless Subscriber Gateway must inform the DDNS server the change of this IP so that the server can update its IP-to-DNS entry.
  • Page 131 Item Default Description Force to update every 1 day Enter a number in the field to set the force update interval ~day(s) when WAN IP (in days). address keeps no change 01~03 The index number of a DDNS account. Active Disable Click on check box, active or inactive the DDNS record.

  • Page 132: Lan Devices

    Click Apply button, the success dialog box appears. Click on Back to return to DDNS setting screen. Figure 3-145 Success Dialog Box 3-2-18 LAN Devices Administrator can direct remote control to LAN Devices via the Wireless Subscriber Gateway implemented the feature. Figure 3-146 LAN Devices Setting Screen Item Default...
  • Page 133 Item Default Description Device Name Empty The LAN device name. The maximum character of the device name is 20. Virtual Port The virtual port number valid range is 60001 to 60050 or 5900 to 5910. Device IP Address Empty Enter the IP address of LAN device in the format “xxx.xxx.xxx.xxx” Device Server Port Enter the server port of LAN device.

  • Page 134: Syslog

    3-2-19 Syslog The function allows the device to transmit event messages to your syslog server or your email address for monitoring and troubleshooting. Syslog Setting Figure 3-147 Syslog Setting Screen Item Default Description Syslog Disable Enables or disables the syslog server function. Syslog on LAN Server IP Address Empty...
  • Page 135 Item Default Description Syslog on WAN Server 1 IP Address Empty Enter IP address of first syslog server. Server 2 IP Address Empty Enter IP address of second syslog server. Send to Email Disable Enables or disables the send to e-mail function. E-mail Server IP Address or Domain Empty...
  • Page 136 Log Categories Figure 3-149 Log Settings Screen Item Interval Time Description Syslog Disable Click on check box, send log information to your syslog server. Email Disable Click on check box, send log information to your e-mail address. Easy Hotspot Kit...
  • Page 137 Item Interval Time Description System Syslog Information 60 minutes The log included system information would be sent according to specified interval time. Format: (Id, Mac Address) (System Uptime, 0 days 00h:04m:00s) (Location Name, Location Name) (WAN, FrameTxOK, FrameRxOK, FrameTxError, FrameRxError) (LAN, FrameTxOK, FrameRxOK, FrameTxError, FrameRxError) (Wireless,...
  • Page 138 Item Interval Time Description Logged-in Users 60 minutes A log included logged-in users information would be sent according to specified interval time. Format: (Id, Mac Address) (Logged-in Users, Type, Number of logged-in users, Start Number, End number) (Username, User IP, User MAC, Interface, Login time, RxData count, TxData count)(…)(…) Type: Dynamic | Super | User agreement | No Authentication If the type of Logged-in user is Super Subscriber, Username...
  • Page 139 Subscriber Trace Relationship Type Event Time Left TimeToFinish Finished 00:00:00 TimeToFinish Replenished 00:12:00 to S/Nxxxxxx TimeToFinish Deleted 00:12:00 Accumulation Finished 00:00:00 Accumulation Replenished 00:12:00 to S/Nxxxxxx Accumulation Logout 00:48:00 Accumulation Idle-Timeout 00:48:00 Accumulation Deleted 00:48:00 Accumulation Account Expired 00:48:00 PostPaid Logout ****** PostPaid...
  • Page 140 Item Interval Time Description LAN Devices Management Category LAN Devices Information 60 minutes A log including current LAN Devices Status will be sent according to specified interval time. Format: (Id, MAC Address) (LAN Devices Information, Number of devices, Start Number, End number) (Device name, Status)(…)(…) LAN Devices Alarm When device...

  • Page 141: Session Trace

    3-2-20 Session Trace Session Trace is an intelligent function to help service provider to trace every user’s access behavior. When “session trace” is enable , the system will collect information such like destination IP, destination port, source IP, source MAC, source port by every user and send the collected information in text format file to specified TFTP server.

  • Page 142: Bandwidth

    3-2-21 Bandwidth The function enables administrator to limit bandwidth usage on a per user basis (MAC address). That prevents users from consuming a disproportionately large amount of bandwidth so every user gets a fair share of the available bandwidth. Figure 3-152 Bandwidth Setting Screen Item Default Description...

  • Page 143: Secure Remote

    3-2-22 Secure Remote This feature allows you to create a secure connection to a remote site or back end system with VPN PPTP Client. If “Secure Remote” is enabled, the RADIUS packet/ syslog will be transferred to this secure connection. Figure 3-153 Secure Remote Setting Screen Item Default...

  • Page 144: Snmp

    3-2-23 SNMP The SNMP Agent Configuration screen enables you to access to your device via Simple Network Management Protocol. If you are not familiar with SNMP, please consult your Network Administrator or consult SNMP reference material. You must first enable SNMP on the SNMP Agent Configuration screen.
  • Page 145 Item Default Description Privileges Read/Write Choose “Read”, “Write”, “Trap Recipients” and “All” for different privileges. The default setting of the entry 2 is “write” and others are “read”. Status Valid/Invalid Chosen “Valid” or “Invalid”. The default setting of entry 1, 2 are valid and others are invalid.

  • Page 146: Wireless

    3-2-24 Wireless Figure 3-155 Wireless Setting Screen Easy Hotspot Kit...
  • Page 147 Item Default Description General Settings The ESSID is the unique name that is shared among all ESSID Wireless points in a wireless network. It is case sensitive and must not exceed 32 characters. Channel Select the channel ID for wireless connection. Select disable to allow wireless station to communicate with Security Disable...
  • Page 148 Item Default Description This selects which of the Keys the Wireless Subscriber Gateway uses when it transmits. You can change the selected encryption key every now and then to increase the security of your network. Note: You have to configure all WEP keys (1~4), and select one of the four WEP key.
  • Page 149 Item Default Description This setting determines the size at which packets are Fragmentation fragmented. Enter a setting ranging from 256 to 2432 bytes. 2432 Use a low setting in areas where communication is poor or Threshold where there is a great deal of radio interference. The preamble type is a section of data at the head of a packet that contains information the Wireless Subscriber Gateway Preamble Type...

  • Page 150: Miscellanea

    Click Apply button, the restart dialog box appears. Click on Apply to restart the system. Figure 3-156 Restart Dialog Box This operation will load the default manufacturer configuration to the system. All this page (Wireless) configuration setup will be replaced by default settings. 3-2-25 Account Generator Figure 3-157 Account Generator Printer Setting Screen Easy Hotspot Kit...

  • Page 151: System Status

    Figure 3-158 Application System Status Display Wireless Subscriber Gateway system basic status, including, System Account List Account Log Current User DHCP Clients Session List LAN Devices Figure 3-159 System Status Item Screen Easy Hotspot Kit...

  • Page 152: System

    3-3-1 System The System Information Menu displays current system basic information including the service connection message, host name, LAN, WAN, DHCP Configuration, DNS, E-mail Redirection, SSL Certificate, network traffic Information and the system firmware version number. Figure 3-160 System Status Screen Easy Hotspot Kit...
  • Page 153 Figure 3-161 System Status Screen Easy Hotspot Kit...

  • Page 154: Account List

    3-3-2 Account List You can display a list of all the account information on this device. This table includes the username, password, usage time, time created, login time, expiration time and status. Figure 3-162 Account List Click on refresh button to update the account list page. Click the column button to sort the column in ascending/descending order.

  • Page 155: Account Log

    3-3-3 Account Log The account log shows the accounts’ log information. Figure 3-163 Account Log This allow you to export the account logs to a text file format. (export.log) Click on Clear Log to remove all account log entries. Click on refresh button to update the account log page. Click the column button to sort the column in ascending/descending order.

  • Page 156: Current User

    3-3-4 Current User Display the current logged-in subscribers’ status. It allow service provider to disconnect any subscribers. Figure 3-164 Current User List Figure 3-165 Current User List (super account) Figure 3-166 Current User List (No Authentication) Click on refresh button to update the current user list page. Click the column button to sort the column in ascending/descending order.

  • Page 157: Dhcp Client

    3-3-5 DHCP Clients The DHCP client table shows the current DHCP users on the LAN. Figure 3-167 Current User Screen 3-3-6 Session List The remote site administrator could monitor the real time usage status of Wireless Subscriber Gateway via this page. Figure 3-168 Session List Screen Easy Hotspot Kit...

  • Page 158: Lan Devices

    3-3-7 LAN Devices You can manage all devices by clicking on device name to access device’s Web-based interface. Click Figure 3-169 LAN Devices Status Screen Figure 3-170 Example- Ethernet Switch Management Screen 3-4 System Tools This allows service provider or administrator to process Firmware upgrade, change password and backup or restore configuration.

  • Page 159: Configuration

    3-4-1 Configuration Use the Configuration item to save, restore or reset configuration parameters of the Wireless Subscriber Gateway. Figure 3-172 Configuration Setting Screen Item Default Description Backup Click it to save the system configuration to your computer. (export.cfg) Remote TFTP Server IP Empty Enter the IP address of TFTP Server.

  • Page 160: Firmware Upgrade

    3-4-2 Firmware Upgrade The Firmware Upgrade menu loads updated firmware to be permanent in flash ROM. The download file should be a binary file from factory; otherwise the agent will not accept it. After downloading the new firmware, the agent will automatically restart it. Manual Firmware Upgrade Figure 3-173 Manual Firmware Upgrade Setting Screen Item...
  • Page 161 Scheduled Firmware Upgrade Scheduled Firmware Upgrade is a program that enables an automatic upgrade to the latest firmware version through the TFTP server. Figure 3-174 Scheduled Firmware Upgrade Setting Screen Item Default Description Disable/Enable Disables or enables the scheduled firmware upgrade function. TFTP Server IP Empty Enter the IP address of TFTP Server.

  • Page 162: Boot Code

    3-4-3 Boot Code Figure 3-176 Boot Code Upgrade Setting Screen 3-4-4 System Account Use the System Account screen to change the system accounts. Figure 3-177 System Account Setting Screen Easy Hotspot Kit...
  • Page 163 Item Description Username The username can consist of up to 20 alphanumeric characters and is sensitive. Password The password can consist of up to 20 alphanumeric characters and is sensitive. Confirm The password for confirmation. Super Subscriber Disables or enables the super account function. Idle Time Out The user idle time out valid is 1 to 1440 minutes.
  • Page 164 Figure 3-180 System Quick View Web-Based Accounting Manager Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 3-181 Web Browser Location Field (Factory Default) Easy Hotspot Kit...
  • Page 165 Step 2: The Wireless Subscriber Gateway configuration main menu will appear. Enter account as the Username and account as the password and click Login Username: account Password: account Figure 3-182 Web-Based Accounting Manager Login Screen Step 3: After a valid user name and password have been provided, the account Generator Panel homepage will appear.
  • Page 166 Supervisor Account Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 3-184 Web Browser Location Field (Factory Default) Step 2: The Wireless Subscriber Gateway configuration main menu will appear. Enter supervisor as the Username and supervisor as the password and click Login.

  • Page 167: Ssl Certificate

    Super Subscriber Account Start your Web Browser; a subscriber login page will appear. Enter super as the Username and super as the password and click Enter, you can use Internet now. Username: super Password: super Figure 3-187 Subscriber Login Page 3-4-5 SSL Certificate The function allows you to download the registered CA certificate into the Wireless Subscriber Gateway.

  • Page 168: Ping Command

    3-4-6 Pin Command The Ping function can check the Wireless Subscriber Gateway networking connective or not. Figure 3-189 Ping Command Screen Item Description IP or URL Enter the IP address or the URL link. 3-4-7 Restart If your Wireless Subscriber Gateway is not operating correctly, you can choose this option to display the restart Wireless Subscriber Gateway screen.

  • Page 169: Appendix A. Rj-45 Connector Description

    Appendix A Signal Connection Arrangements RJ-45 Ethernet Port The Wireless Subscriber Gateway RJ-45 Ethernet port can connect to any networking devices that use a standard LAN interface, such as a Hub/Switch Hub or Router. Use unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable to connect the networking device to the RJ-45 Ethernet port. Depending on the type of connection, 10Mbps or 100Mbps, use the following Ethernet cable, as prescribed.

  • Page 170: Appendix B Regulations/Emi Compliance

    Appendix B Regulations/EMI Compliance FCC Regulatory Statement Part 15-Class B compliant device This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including that which may cause undesired operation.

  • Page 171: Limited Warranty

    LIMITED WARRANTY Easy Hotspot Kit What the warranty covers: We warrant its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, we will at its sole option repair or replace the product with a like product with a like product.
