PARTS GUIDE MANUAL
APRIL 2008
pagepro 4650EN
A0DX011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4650EN and is the answer not in the manual?

Questions and answers

Related Manuals for Konica Minolta 4650EN

Summary of Contents for Konica Minolta 4650EN

  • Page 1 PARTS GUIDE MANUAL APRIL 2008 pagepro 4650EN A0DX011...
  • Page 2 To find correct Parts No., refer to the “HOW TO MAKE THE BEST USE OF THIS MANUAL” in the following page. HOW TO MAKE THE BEST USE OF THIS MANUAL 1 When you order, please check the proper figures beforehand that are on Our Parts Guide Manual, and order with the appropriate figures. 2 For screws, Nuts, Washers, retaining rings and Pins which are used in this model, one letter is shown on the Standard parts column of Parts list and exploded diagrams.

  • Page 3: System Outline

    SYSTEM OUTLINE OPTION SF-603 OPTION AD-508 OPTION PF-505 Parts Guide Manual "pagepro 4650EN" includes PF-505, AD-508 and SF-603. pagepro 4650EN...

  • Page 4: General Contents

    Description PRINTER B/W PRINTER B/W OTHER OPTION OTHER OPTION GENERAL CONTENTS pagepro 4650EN pagepro 5650EN HD-512 MK-717 Model pagepro 4650EN...
  • Page 5 DIAGRAM OF MAIN PARTS SECTION pagepro 4650EN...
  • Page 6 DESCRIPTION EXTERNAL PARTS 150 PAPER CASSETTE 550 PAPER CASSETTE PAPER FEED SECTION P/H FUSING SECTION PAPER EXIT SECTION DRIVE SECTION ELECTRICAL COMPONENTS PF-505 AD-508 SF-603 CONTENTS P4 P5 P7 P8 P11 P12 P13 PAGE No. pagepro 4650EN...
  • Page 7 15-5 A0DX PP2X 01 14-5 A0DX PP2Y 00 15-1 A0DX PP31 00 A0DX PP33 00 10-8 A0DX PP38 01 10-1 A0FM 011 10-7 A0FM 0Y1 10-7 12-1 13-2 13-1 15-3 11-6 14-4 14-1 14-2 14-8 11-4 12-3 15-9 pagepro 4650EN...

  • Page 8: External Parts

    EXTERNAL PARTS Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 9 COVER RIGHT A0DX PP2P 00 COVER FRONT A0DX PP23 00 COVER LEFT A0DX PP2Q 00 COVER STOPPER A0DX PP21 00 COVER OPEN A00F 9420 00 Label Logo Mark A0DX 9401 00 Label pagepro4650 Description Destinations Class Standard parts pagepro 4650EN...

  • Page 10: 150 Paper Cassette

    150 PAPER CASSETTE Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 11 A0DX PP20 00 COVER CST A0DX PP1R 00 ROLL ASSY RETARD A0DX PP2C 00 SPRING RETARD A0DX PP0A 00 GUIDE END 150 A0DX PP01 00 HOLDER ASSY RETARD A0DX PP0K 00 150 PAPER CASSETTE Description Destinations Class Standard parts pagepro 4650EN...

  • Page 12: 550 Paper Cassette

    550 PAPER CASSETTE Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 13 Part No. A0DX PP20 00 COVER CST A0DX PP1R 00 ROLL ASSY RETARD A0DX PP09 00 GUIDE END 550 A0DX PP0M 00 550 PAPER CASSETTE Description Destinations Class Standard parts pagepro 4650EN...

  • Page 14: Paper Feed Section

    PAPER FEED SECTION Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 15 A0DX PP10 00 ACTUATOR NO PAPER A0DX PP2H 00 SENSOR OCT A0DX PP1R 00 ROLL ASSY RETARD A0DX PP1G 00 SENSOR TONER ASSEMBLY A0DX PP2U 00 KIT CHUTE REGI A0DX PP1Q 00 150 FEEDER ASSY Description Destinations Class Standard parts pagepro 4650EN...
  • Page 16 PAPER FEED SECTION Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 17 A0DX PP2H 00 SENSOR OCT A0DX PP11 00 CLUTCH ASSY PH A0DX PP1R 00 ROLL ASSY RETARD A0DX PP10 00 ACTUATOR NO PAPER A0DX PP07 00 GUIDE TRAY LEFT A0DX PP03 00 550 FEEDER ASSY Description Destinations Class Standard parts pagepro 4650EN...

  • Page 18: P/H Fusing Section

    P/H FUSING SECTION Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 19 HARNESS ASSY ROS 34PPM A0DX PP0H 00 ROS ASSY 34PPM A0DX PP2A 00 BTR ASSY A0DX PP1S 00 FUSER ASSY 34PPM 110V A0DX PP1T 00 FUSER ASSY 34PPM 220V A0DX PP1C 00 FAN SUB Description C,D,D1,D3,J,K Destinations Class Standard parts pagepro 4650EN...

  • Page 20: Paper Exit Section

    PAPER EXIT SECTION Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 21 Part No. A0DX PP2Y 00 COVER EXIT 500 A0DX PP2H 00 SENSOR OCT A0DX PP31 00 500 EXIT ASSY Description Destinations Class Standard parts pagepro 4650EN...
  • Page 22 PAPER EXIT SECTION FACE UP TRAY Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 23 PAPER EXIT SECTION Page. 8 Part No. Description Destinations Class Standard parts A0DX PP0J 00 COVER REAR 500 34PPM pagepro 4650EN...

  • Page 24: Drive Section

    DRIVE SECTION Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 25 Part No. A0DX PP19 00 MAIN MOTOR 34PPM A0DX PP1P 00 GEAR ASSY HOUSING 34PPM Description Destinations Class Standard parts pagepro 4650EN...

  • Page 26: Electrical Components

    ELECTRICAL COMPONENTS P 10 PRCB MFPB DCPU Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 27 A0DX PP0U 00 INTERLOCK S/W REAR A0DX PP15 00 FAN MAIN A0DX M710 05 Controller PWB assembly A0FM 011 Maintenance Kit 110V A0FM 0Y1 Maintenance Kit 220V A0DX PP33 00 KIT SCREW Description C,D,D1,D3,J,K C,D,D1,D3,J,K C,D,D1,D3,J,K Destinations Class Standard parts pagepro 4650EN...
  • Page 28 PF-505 P 11 PCCB Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 29 A0DX PP2M 00 HARNESS ASSY FDR2 A0DX PP0V 00 OPT ASSY SIZE A0DX PP2G 00 FRAME CVR L550 A0DX PP00 00 FOOT A0DX PP25 00 FRAME CVR R550 A0DX PP1H 00 PWBA FEEDER 550 Description Destinations Class Standard parts pagepro 4650EN...
  • Page 30 PF-505 P 12 Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 31 Part No. A0DX PP1R 00 ROLL ASSY RETARD A0DX PP11 00 CLUTCH ASSY PH A0DX PP2H 00 SENSOR OCT A0DX PP02 00 550 FEEDER OPTION Description Destinations Class Standard parts pagepro 4650EN...
  • Page 32 PF-505 P 13 Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 33 Part No. A0DX PP20 00 COVER CST A0DX PP1R 00 ROLL ASSY RETARD A0DX PP09 00 GUIDE END 550 Description Destinations Class Standard parts pagepro 4650EN...
  • Page 34 AD-508 P 14 ADCB Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 35 COVER LEFT A0DX PP13 00 MOTOR DUPLEX A0DX PP26 01 COVER HSG DUP A0DX PP1K 00 PWBA DUPLEX A0DX PP14 00 FAN DUPLEX A0DX PP1F 00 SENSOR DUP A0DX PP29 01 COVER RIGHT Description Destinations Class Standard parts pagepro 4650EN...
  • Page 36 SF-603 P 15 OCTCB Please refer Page.10-Key.8 for parts described as "S" or "E". pagepro 4650EN...
  • Page 37 A0DX PP0S 00 S/W REAR COVER A0DX PP12 00 SOLENOID ASSY GATE A0DX PP2H 00 SENSOR OCT A0DX PP0E 00 ROLL OCT UPPER A0DX PP1B 00 MOTOR ASSY OCT A0DX PP0B 01 TRAY ASST OCT Description Destinations Class Standard parts pagepro 4650EN...

  • Page 38: Maintenance List

    *3: The Maintenance kit includes Rollers(for feed roller, pick-up roller and separation roller),Transfer roller and Fuser unit. Maintenance Cycle (K=1,000) Parts No. Destinations Replace 200K *1 A0FM011 for 4650EN, 110 V 200K *1 A0FM0Y1 for 4650EN, 220 V Page/Key Note P10-7...
  • Page 39 THAILAND, SRI LANKA, SINGAPORE, MALAYSIA, HONG KONG, PAKISTAN, INDIA, BANGLADESH, INDONESIA AUSTRALIA, NEW ZEALAND Model No. 50/60 50/60 A0DX-011 220-240 50/60 A0DX-021 220-240 50/60 A0DX-041 220-240 50/60 A0DX-041 220-240 50/60 220-240 50/60 220-240 50/60 A0DX-011 220-240 50/60 220-240 50/60 A0DX-041 220-240 50/60 A0DX-041 pagepro 4650EN...
