Table of Contents

1.0 Overview - 1
1.1 Introduction - 1
1.2 About This Manual - 2
Meet the StudioLive RM32AI and RM16AI - 2
1.3
1.4 What's In the Box - 3
2.0 Hookup - 4
2.1 Front-Panel Connections and Controls - 4
2.2 Rear-Panel Connections and Controls - 8
2.3 Typical Band Hookup - 10
Typical Church Hookup - 12
2.4
3.0 Installing the UC Surface
Touch-Control Software - 14
3.1 Minimum System Requirements - 14
3.2 Downloading UC Surface for iPad
and QMix-AI - 14
3.3 Wired Ethernet Control Setup - 15
Wireless Control Setup - 15
3.4
3.5 Computer Recording Setup - 16
3.6 Computer Hookups - 18
3.6.1 Command and Recording -
FireWire-equipped computer - Wireless
via Ethernet - 18
3.6.2 Command and Recording -
FireWire-equipped computer - Wireless
with dongle - 18
3.6.3 Command and Recording - FireWire-
equipped computer - Wired - 19
3.6.4 Separate Command and Recording -
Wireless via Ethernet - 19
3.6.5 Separate Command and Recording -
Wireless with Dongle - 20
3.6.6 Separate Command and Recording -
Wired - 20
3.6.7
Separate Touch Screen Command and
Recording - Wireless via Ethernet - 21
3.6.8
Separate Touch Screen Command and
Recording - Wireless via Dongle - 21
3.6.9 Separate Touch Screen Command and
Recording - Wired - 22
3.6.10 UC Surface iPad and QMix-AI
iPhone Connections for Any of
These Hookups - 22
4.0 Getting Started - 23
4.1 Level-Setting Procedure - 23
5.0 A Tour of UC Surface Features - 24
5.1 UC Surface Settings - 24
5.2 Mix Scroll View - 26
5.3 Meter Bridge - 28
5.4 Flex Fader and Mix Selection Area - 28
5.5 Filter DCAs - 30
5.6 Main Mix Area - 33
5.7 Fat Channel - 35
5.7.1 Channel Settings - 37
Channel Input - 38
5.7.2
5.7.3 Fat Channel Processing - 39
5.7.4 Compressor - 40
Limiter - 41
5.7.5
5.7.6 Parametric EQ - 41
5.7.7 Preset List/Editor Button - 42
Graphic EQ - 43
5.7.8
5.7.9 Effects - 45
5.8 Working With Presets - 47
5.9 Mix Scene Quick Recall - 48
5.10 Mute Groups - 49
