Battery Replacement; Battery Specifications; Usage And Maintenance - Fenix PD32 Operation Instruction

Notice: The video for PD32 operation can be watched and downloaded from Fenix official
website, please log onto the service channel ->light operation video.

Battery Specifications

Type
Non-rechargeable Battery
(Lithium)
Rechargeable Battery
(Li-ion)
Rechargeable Battery
(Li-ion)
Rechargeable Lithium
iron phosphate battery
Rechargeable Lithium
iron phosphate battery
Caution: please do not mix batteries of different size or type, or it will ruin the
batteries or flashlight.

Battery Replacement

Unscrew the tail cap to insert the batteries with the anode side (+) toward the light's head, screw
the tail cap to test.

Usage and Maintenance

18650 Li-ion batteries are industrial batteries and not for domestic use. Using inferior batteries
or misusing batteries (short circuit or high temperature, etc) may cause combustion and explosion
which will damage people and their property. Therefore, when using such batteries, users will
agree to take the relevant responsibility voluntarily. Quality Li-ion batteries with protective circuit
can lower the risks to some degree.
Please don't disassemble the sealed head, doing so can cause damage to the flashlight and will
void the warranty.
Please use battery of high quality, and take out the battery if the flashlight will not be used for a
long time, or it may cause damage from electrolyte leakage or battery explosion.
The o-ring may be worn out after using for a long time. If it happens, please replace the o-ring
with a new one to keep the flashlight properly sealed against water.
Please clean the contacts of your light from time to time, especially if the light flickers or
doesn't light up. There may be several reasons for a flickering or not working light:
Reason A: The battery needs replacing.
Nominal
Dimensions
voltage
CR123A 3V
16340 3.7V
18650 3.7V
16340 3.2V
18650 3.2V
Usability
Recommended
Banned
Cautious
Usable
Banned
