Auto Meter BusPro Series Instruction Manual

Professional 120 vac
Hide thumbs Also See for BusPro Series:
Table of Contents

Advertisement

Quick Links

Download this manual
BusPro-660.
®
1
2
3
Warning Risk of Explosive Gases!
Read and understand all of the instructions.
In case of direct acid contact with eyes, skin or clothing, flush
immediately with large amounts of water. Seek medical attention.
Never smoke, create sparks or flames near batteries.
Always make sure batteries are at least two feet from BusPro-360.
Never attempt to charge a frozen battery.
®
Never attempt to start or run engine near a battery being charged.
Always wear protective goggles or full face shield.
Make sure no sparks or flames occur near the batteries during charging.
A battery explosion can kill, injure and cause property damage.
It takes very little to ignite the explosive gases given off by the lead-acid
battery.
Work in an open and well ventilated area.
Red = Charging
Rojo = Carga
Flashing = Defective Battery
Intermitente = Bateria Defectiva
BusPro-360
Green = Charged & Maintaining
Verde = Cargada y en Mantenimiento
AGM Optimized
Ready for Load Testing
Listo Para la Prueba de Carga
1
Both Red & Green Lights = Topping off the Battery
2
Rojo y Verde = Maximación de Carga
3
No Lights = No Connection, Reversed Connection
No Luces = No Conexión, Conexión Devertida o la
or Battery Less Than 2 Volts
Batería Tiene Menos de 2 Voltios
© 2008 Auto Meter Products, Inc. 2511-2560-00
BusPro Series
BusPro-660.
BusPro-660
AGM Optimized
© 2008 Auto Meter Products, Inc.
4
5
6
Professional 120 VAC
Instruction Manual
2650-1412-00 Rev. B
12/23/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BusPro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Auto Meter BusPro Series

Summary of Contents for Auto Meter BusPro Series

  • Page 1 No Lights = No Connection, Reversed Connection No Luces = No Conexión, Conexión Devertida o la or Battery Less Than 2 Volts Batería Tiene Menos de 2 Voltios © 2008 Auto Meter Products, Inc. 2511-2560-00 Professional 120 VAC BusPro Series Instruction Manual 2650-1412-00 Rev.

  • Page 2: Table Of Contents

    BUSPRO SERIES SPECIFICATIONS Charges ............12 Volt Batteries Input............120 VAC @ 5 Amps Charging & Output Mode ..5 Amps Max/10 Amps BusPro-361 Maintenance Output Mode ..... 0-2.5 Amp variation as needed 0-5 Amp with BusPro-361 Leads ..............6 Ft. 18 GA.

  • Page 3: Safety Instructions

    GENERAL SAFETY RULES FOR SAFE OPERATION Batteries are dangerous. Auto Meter provides the following Warnings for your safety: Use the BusPro-300 and BusPro-600s chargers only on 12 Volt LEAD ACID.

  • Page 4: Personal Safety Precautions

    SAFETY INSTRUCTIONS Cont. 11. NEVER attempt to charge a frozen battery. Allow the battery to return to room temperature before connection. 12. ALWAYS use the charger in an open and well-ventilated area. The area should be dry and free of trash, debris and combustibles. 13.

  • Page 5: Setting Up The Charger

    SETTING UP THE BusPro Charger The charger has two mounting keyholes. YOU MUST mount the charger to a wall that provides a secure surface. This will keep it out of the way and prevent damage due to accidents. If needed, you may leave the two screws slightly extended from the wall to allow easy removal through the keyhole slots.

  • Page 6: Inspecting The Battery

    INSPECTING THE BATTERY Remove and Inspect the battery before connecting it to a the charger. A clean battery and battery terminals insure proper operation of the charger and the vehicle charging system. • Check for dirty or loose terminals. • Check for any cracks or distortion in the battery case.

  • Page 7: Hooking Up The Clamps

    HOOKING UP THE CLAMPS Each charging station has a lead set with a red positive (+) and a black negative (-) clamp. If the charger has been installed correctly, at least two feet above the work station, the clamps should lie on a clean dry surface. •...

  • Page 8: Disconnecting The Charger

    DISCONNECTING THE BusPro Charger The charger is safely maintaining the battery at a full charge when the green light is on. Simply remove the clamps and set them on the working surface clear from the other batteries and clamps. You can now load-test the battery.

  • Page 9: Hookup Potential (3 Units Together And Optional Leads)

    BusPro Charger HOOKUP POTENTIAL BusPro-660. BusPro-660. ® BusPro-660 AGM Optimized © 2008 Auto Meter Products, Inc. Charge up to 36 12-Volt batteries with the BusPro-600s and BusPro-660 Charge up to 18 12-Volt batteries with the BusPro-300, BusPro-360 and BusPro-361 •...

  • Page 10: What To Expect From Your Charger

    What To Expect From Your BusPro Charger The Professional Charger is equipped with sophisticated circuitry that will: • Check Each Battery’s Condition The charger will indicate bad batteries that are sulfated or have bad cells. This allows the battery to be replaced without unnecessary charging.

  • Page 11: Warranty And Service Information

    (customer returning the Test Equipment). Protect the product by shipping in original carton or add plenty of over-pack cushioning such as crumpled up newspaper. For Service Please Contact: Auto Meter Products, Inc. 413 West Elm Street Sycamore, IL 60178 Phone: 866-883-8378 Fax: 815-895-6786...

  • Page 12: Contact Information & Warnings

    With all six stations in operation the case may become very hot to the touch when vertical ventilation is inhibited. For BusPro-600s, BusPro-660 & BusPro-361 Auto Meter Products Inc. 413 West Elm Street T est Equipment...
