Control-channel 3 - Color-wheel
Linear color change following the movement of the slider.
In this way you can stop the color-wheel in any position.
Decimal Hexad. Percentage
0 14 00 0E 0% 5%
15 29 0F 1D 6% 11%
30 44 1E 2C 12% 17%
45 59 2D 3B 18% 23%
60 74 3C 4A 24% 29%
75 89 4B 59 29% 35%
90 104 5A 68 35% 41%
105 119 69 77 41% 47%
120 127 78 7F 47% 50%
128 255 80 FF 50% 100%
Control-channel 4 - Static gobo-wheel, gobo shake
Decimal Hexad. Percentage
0 7 00 07 0% 3%
8 14 08 0E 3% 5%
15 21 0F 15 6% 8%
22 28 16 1C 9% 11%
29 35 1D 23 11% 14%
36 42 24 2A 14% 16%
43 49 2B 31 17% 19%
50 56 32 38 20% 22%
57 63 39 3F 22% 25%
64 70 40 46 25% 27%
71 77 47 4D 28% 30%
78 84 4E 54 31% 33%
85 91 55 5B 33% 36%
92 98 5C 62 36% 38%
99 105 63 69 39% 41%
106 112 6A 70 42% 44%
113 119 71 77 44% 47%
120 127 78 7F 47% 50%
128 255 80 FF 50% 100%
Control-channel 5 - Shutter, strobe
Decimal Hexad. Percentage
0 7 00 07 0% 3%
8 15 08 0F 3% 6%
16 131 10 83 6% 51%
132 139 84 8B 52% 55%
140 180 8C B4 55% 71%
181 189 B5 BD 71% 74%
190 231 BE E7 75% 91%
232 239 E8 EF 91% 94%
240 247 F0 F7 94% 97%
248 255 F8 FF 97% 100%
S/F
S Open / white
S Orange
S Blue
S Green
S Yellow
S Pink
S Light blue
S Light green
S Light yellow
F Rainbow effect with increasing speed
S/F
S Open
S Gobo 1
S Gobo 2
S Gobo 3
S Gobo 4
S Gobo 5
S Gobo 6
S Gobo 7
S Gobo 8
F Open shake
F Gobo 1 shake
F Gobo 2 shake
F Gobo 3 shake
F Gobo 4 shake
F Gobo 5 shake
F Gobo 6 shake
F Gobo 7 shake
F Gobo 8 shake
F Cont. gobo-wheel rotation with increasing speed
S/F
S Blackout
S Shutter open
F Strobe-effect with increasing speed
S Shutter open
F Pulse closing with increasing speed
S Shutter open
F Pulse closing with decreasing speed
S Reset after 3-5 seconds
F Random strobe-effect
S Shutter open
