It is of vital importance, before attempting to
operate your engine,
'SAFETY INSTRUCTIONS AND WARNINGS'
section on pages 2-4 of this booklet and to
strictly adhere to the advice contained therein.
Also, please study the entire contents of this
instruction manual, so as to familiarize
yourself with the controls and other features of
the engine.
Keep these instructions in a safe place so that
you may readily refer to them whenever
necessary.
It is suggested that any instructions supplied
with the aircraft, radio control equipment, etc.,
are accessible for checking at the same time.
to read the general
2-4
5
6
7
8
9-11
ENGINE EXPLODED VIEW
12
ENGINE PARTS LIST
13-14
CARBURETOR EXPLODED VIEW
15
ENGINE THREE VIEW DRAWINGS
1
CONTENTS
16
17-18
19
20-21
22-23
24-25
26
27
28
29
30
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for O.S. engine FS-200S-P
Summary of Contents for O.S. engine FS-200S-P
-
Page 1: Table Of Contents
It is suggested that any instructions supplied with the aircraft, radio control equipment, etc., are accessible for checking at the same time. CONTENTS SAFETY INSTRUCTIONS AND GLOWPLUG WARNINGS ABOUT YOUR O.S. ENGINE NOTES WHEN APPLYING AN 17-18 MIXTURE CONTROLS ELECTRIC STARTER STARTING ABOUT THE ENGINE RUNNING-IN ("Breaking-in") -
Page 2: Safety Instructions And Warnings About Your O.s. Engine
(see 'NOTES' all times. section relating to propeller safety). If at some future date, your O.S. engine is acquired by another person, we would respectfully request that these Model engine fuel is poisonous. Do not allow it to instructions are also passed on to its new owner. -
Page 3: Notes When Applying An Electric Starter
Take care that the glow plug clip or battery leads do not come into contact with the propeller. Also check the linkage to the throttle arm. A disconnected linkage could also foul the propeller. After starting the engine, carry out any needle-valve readjustments from a safe position behind the rotating propeller. -
Page 4: About The Engine
ABOUT THE ENGINE This is an overhead valve four stroke cycle STANDARD ACCESSORIES engine for model aircraft use. This engine has a largest displacement of 32.4cc in the FS Glowplug TypeF series and is suitable for big scale and sport models. -
Page 5: Fuel Tank & Lines
Approx. 15mm INSTALLATION Because the FS-200S-P is a powerful, large-displacement, single-cylinder four-stroke-cycle engine, it is essential to use very substantial engine mounting. Conventional wooden mounting beams should be of rigid hardwood and of at least 15mm or 5/8- in square section. - Page 6 How to fasten the mounting screws. Tighten second nut firmly 5mm steel down onto first nut. 5mm steel nuts Allen screw Tighten this nut first. Spring washer Spring washer or lock washer 15mm min. Hardwood such as cherry or maple. Steel washer 15mm min.
-
Page 7: Exhaust Header Pipe & Silencer
EXHAUST HEADER PIPE & SILENCER IInstall these in the following sequence. Screw the exhaust header pipe into the exhaust port until it “bottoms”, then unscrew it approximately 90 degrees,and Apply silicone sealant. secure with locknut. Screw the silencer onto the header pipe more than 10mm and maximum 30mm to achieve the desired exhaust angle and tighten the other locknut. -
Page 8: Fuel
The locknut should be tightened firmly after retightening the propeller nut. Propeller washer Since the FS-200S-P is intended to be started with an electric starter, the addition of a spinner assembly for centering the starter sleeve is desirable. Special propeller locknut sets are available for use with spinners. -
Page 9: Glowplug
GLOWPLUG Since the compatibility of the glowplug and Glowplug life fuel may have a marked effect on performance and reliability, it is suggested Particularly in the case of very high performance engines, to use the O.S. Type F plug when it is glowplugs must be regarded as expendable items. -
Page 10: Starting
Use only alcohol (methanol) or glow fuel for cleansing these items. STARTING The FS-200S-P is not equipped with manual choke Check these conditions and, instead of pressing the starter controls, as it is intended for use with an electric starter button after applying the starter, have the starter spinning only. -
Page 11: Running-In ("Breaking-In")
RUNNING-IN ("Breaking-in") For long life and peak performance, every engine needs The recommended procedure is as follows: special treatment when new, know as “running-in” or Use the same fuel and prop as you intend for flying your “breaking-in”. This is a procedure during which the model. -
Page 12: Idle Mixture Adjustment
VALVE ADJUSTING Valve clearances are correctly set before any O.S. engine leaves the factory and, in normal use, will seldom require adjustment. However, if, after a considerable amount of... -
Page 13: Maintenance
MAINTENANCE Please pay attention to the matters described below to The use of modern high-performance alcohol based model ensure that your engine serves you well in regard to engine fuels, while promoting cooler running, improved anti- performance, reliability and long life. detonation combustion and increased power, have the disadvantage of causing corrosion due to the acid by- As previously mentioned, it is vitally important to avoid... -
Page 15: Parts List
EXPLODED VIEW & PARTS LIST S.3x3 Description Code No. 23881900 Needle-valve Assembly 22681980 Needle Assembly 24981837 "O" Ring (2pcs.) 26381501 Set Screw 27381940 Needle-valve Holder Assembly 26711305 Ratchet Spring 22681953 Fuel Inlet (Nipple No.1) 44582100 Carburetor Body 45581820 Roter Guide Screw 44581600 Mixture Control Valve Assembly 46066319... -
Page 16: Three View Drawing
THREE VIEW DRAWING Specifications Displacement 32.4 cc / 1.98 cu.in. Bore 38.0 mm / 1.50 in. Stroke 28.6 mm / 1.13 in. PracticalR.P.M. 1,800 - 10,000 r.p.m. 4- 5.1 Output 3.0 ps / 9,000 r.p.m. Weight 876 g / 30.9 oz. (Silencer including 116g (4.1 oz.) exhaust header pipe)
