Sony UP-D55 Instructions For Use Manual
Digital color printer
Hide thumbs
Also See for UP-D55:
- Instructions for use manual (22 pages) ,
- Specification sheet (2 pages)
Related Manuals for Sony UP-D55
Summary of Contents for Sony UP-D55
- Page 1 2-059-514-13 (1) Digital Color Printer Instructions for Use UP-D55 © 2004 Sony Corporation...
- Page 2 Operation of this equipment in a Refer to these numbers whenever you call upon your residential area is likely to cause harmful interference in Sony dealer regarding this product. which case the user will be required to correct the interference at his own expense.
- Page 3 UP-D55. Guidance and manufacturer’s declaration-electromagnetic emissions The UP-D55 is intended for use in the electromagnetic environment specified below. The customer or the user of the UP-D55 should assure that it is used in such an environment. Emission test Compliance...
- Page 4 Guidance and manufacturer’s declaration - electromagnetic immunity The UP-D55 is intended for use in the electromagnetic environment specified below. The customer or the user of the UP- D55 should assure that it is used in such as environment. IEC 60601 test...
- Page 5 Guidance and manufacturer’s declaration - electromagnetic immunity The UP-D55 is intended for use in the electromagnetic environment specified below. The customer or the user of the UP- D55 should assure that it is used in such as environment. IEC 60601 test...
- Page 6 Recommended separation distances between portable and mobile RF communications equipment and the UP-D55 The UP-D55 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the UP-D55 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (Transmitters) and the UP-D55 as recommended below, according to the maximum output power of the communications equipment.
-
Page 7: Table Of Contents
Table of Contents Getting Started System Overview ........... 8 System Configuration ......... 8 Location and Function of Parts and Controls ..8 Front Panel ............8 Rear Panel ............9 Supplied Accessories ..........9 Connections ............10 USB Port Connection ........10 Installing the Printer Driver ....... -
Page 8: Getting Started
Parts and Controls For details, refer to the pages given in parentheses. System Overview The UP-D55 digital color printer is designed to Front Panel reproduce computer images on A-5 size paper. You can print out computer image data in full color (with... -
Page 9: Rear Panel
Press this switch to turn the printer on or off. Paper Tray (1) Rear Panel Ink ribbon holder (1) USB cable 1-824-211-41 (Sony) (1) Software Licence Agreement (1) CD-ROM (including the printer drivers and PDF files of multi-lingual Instructions For... -
Page 10: Connections
• USB 2.0 supports Hi-speed USB, in addition to the existing Full (Low) speed. (USB) connector • The UP-D55 can be connected as Full-speed in a USB 1.1 environment. However, to use the UP-D55 with Hi-speed USB functions in a USB 1.1 environment, the following requirements must be met. - Page 11 2.0, or all USB 2.0 extension boards/extension cards cannot be guaranteed. Note When the UP-D55 is connected to the computer with the power turned on, do not turn your computer to standby mode (suspend status) or in pause mode. Doing so may cause a malfunction of the operation.
-
Page 12: Operation
Open the ribbon door by pulling the ribbon door Operation toward you. Before Printing This section describes the operations below that must be made before printing, but after making the necessary connections. (See “Connections” on page 10.) • Loading an ink ribbon cartridge (See below.) •... - Page 13 Detach the spent ink ribbon from the ink ribbon 2 Place the ink ribbon with the white gear as holder. illustrated. 1 Press the white gear of Pushing the ink ribbon spool that takes up the ink the ink ribbon. ribbon in the direction of the arrow, remove the Match the color of the spool from the side with the gray gear.
- Page 14 Close the ribbon door. Note If the ribbon is left slack, it may be damaged when the ink ribbon cartridge is inserted into the printer. Turn the gears in the direction of the arrows until any slack is eliminated and the magenta section of the ink ribbon appears.
-
Page 15: Inserting The Paper Tray
sure to riffle the paper along with the protection Inserting the Paper Tray sheets before placing the paper in the paper tray. To load paper in the paper tray and insert the paper tray into the printer, follow the procedure below. Be careful not to touch the printing surface of the paper. -
Page 16: Printing
Slide the paper tray back into the printer until it Printing clicks into place. Before printing • Ensure that the printer is properly connected to the computer. (See page 10.) • Ensure that the ink ribbon cartridge and paper tray are properly loaded. - Page 17 being printed when you opened the ribbon door is ejected and the printer turns to the standby mode. • You can make multiple copies of identical printouts. However, the printer may stop printing due to warping of the printed sheet and the ALARM indicator lights. In such a case, remove the printouts accumulated on the paper tray.
-
Page 18: Miscellaneous
• If the unit malfunctions or if a foreign body falls into the cabinet, disconnect the AC power cord immediately and consult your Sony service facility or Cleaning your Sony dealer. Note... -
Page 19: Ink Ribbon And Paper
Specification Revision 2.0 Input connector AC IN (for power input) Supplied accessories Paper tray (1) USB cable 1-824-211-41 (Sony) (1) Ink ribbon holder (1) Software License Agreement (1) Before Using this Printer (1) CD-ROM (including the printer drivers and PDF files of multi-lingual... -
Page 20: Troubleshooting
Should the problem persist after you have with air or with oxygen or nitrous applied the remedy, unplug the unit and contact your oxide Sony dealer or local authorized Sony service facility. Mode of operation: Continuous Symptoms Possible causes and remedies The printer does not •... -
Page 21: Indicators On The Ribbon Door
PRINT, ALARM, RIBBON and/or PAPER light PAPER and power of the printer first. ALARM Then contact your Sony or blink to indicate the problem condition. the following service facility or your table shows the relation between lighting or blinking... -
Page 22: If The Paper Jams
Load the paper into the paper tray correctly. If the Paper Jams If the ALARM indicator lights on the ribbon door, or the message “Paper jam. Printing is aborted. Please remove the jammed paper and print again.” or “Motor or sensor trouble. - Page 23 • Confirm that connecting cables and the AC power cord are securely connected. • Reset the paper tray in the printer. If you still cannot remove the paper Do not try to remove it forcibly. Contact your nearest Sony dealer. If the Paper Jams...
-
Page 24: Index
Printing pack Index available printing pack 19 Specifications 19 Accessories System configuration 8 paper tray 9 System overview 8 USB cable 9 Alarm indicating the problem using the Troubleshooting 20 indicators 21 indicators on the ribbon door 21 USB 2.0 10 USB port connection 10 Cleaning cabinet 18... - Page 25 Sony Corporation...
