0213321en
002
05.2008
Inverter
FUE 6
Operator's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUE 6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wacker Neuson FUE 6

Summary of Contents for Wacker Neuson FUE 6

  • Page 1 0213321en 05.2008 Inverter FUE 6 Operator's manual...

  • Page 3: Table Of Contents

    Inhalt Contents Foreword ........................5 Introduction ....................... 6 2.1 Means of representation for this operator's manual ........... 6 2.2 WACKER representative ..................7 2.3 Described machine parts..................7 Safety information ....................8 3.1 Principle......................8 3.2 Qualification of the operating personnel ............10 3.3 Protective gear ....................
  • Page 4 Contents Technical data ......................28 12.1 FUE 6 ....................... 28 12.2 Notes regarding class rating and protection class..........29 12.3 Extension cable ....................30 EC Declaration of Conformity ................31 DIN EN ISO 9001 Certificate ................... 33...

  • Page 5: Foreword

    Foreword Foreword This operator's manual contains information and procedures for the safe opera- tion and maintenance of your WACKER machine. In the interest of your own safety and to prevent accidents, you should carefully read through the safety in- formation, familiarize yourself with it and observe it at all times. This operator's manual is not a manual for extensive maintenance and repair work.

  • Page 6: Introduction

    Introduction Introduction Means of representation for this operator's manual Warning symbols This operator's manual contains safety imformation of the categories: DANGER, WARNING, CAUTION, NOTICE. They should be followed to prevent danger to life and limb or damage to equip- ment or improper service. DANGER This warning notice indicates hazards that result in serious injury or even death.

  • Page 7: Wacker Representative

    Introduction WACKER representative Depending on your country, your WACKER representative is your WACKER Service, your WACKER affiliate or your WACKER dealer. You can find the addresses in the Internet at www.wackergroup.com. The addresses of the WACKER main locations are located at the end of this op- erator's manual.

  • Page 8: Safety Information

    Safety information FUE 6 Safety information Principle State of the art This machine has been constructed with state-of-the-art technology according to the recognized rules of safety. Nevertheless, when used improperly, dangers to the life and limb of the operator or to third persons or damage to the machine or other materials cannot be excluded.
  • Page 9 FUE 6 Safety information Maintenance Regular maintenance is required in order for the machine to operate properly and reliably over time. Neglected maintenance work can make the machine danger- ous to use. Strictly observe the prescribed maintenance intervals. Do not use the machine if it requires maintenance or repairs.

  • Page 10: Qualification Of The Operating Personnel

    Safety information FUE 6 Operator's controls Always keep the operator's controls of the machine dry, clean and free of oil or grease. The function of the operator's controls must not be manipulated or rendered in- effective. Cleaning Always keep the machine clean and be sure to clean it each time you have fin- ished using it.

  • Page 11: Protective Gear

    FUE 6 Safety information Work recommendations Please observe the recommendations below: Work only if you are in a good physical condition. Work attentively, particularly as you finish. Do not operate the machine when you are tired. Carry out all work calmly, circumspectly and carefully.

  • Page 12: Operating Safety

    Safety information FUE 6 Operating safety Work environment Familiarize yourself with your work environment before you start work. This in- cludes e.g. the following items: Obstacles in the work and traffic area. Load-carrying capacity of the ground. The measures needed to cordon off the construction site from public traffic.

  • Page 13: Safety During The Operation Of Electric Appliances

    FUE 6 Safety information Safety during the operation of electric appliances Specific regulations for electrical appliances Observe the safety information provided in the brochure General Safety Rules which is included in the scope of delivery of your machine. Also observe the country-specific regulations, standards and guidelines in refer- ence to accident prevention in connection with electrical equipment and ma- chines.

  • Page 14: Maintenance

    Safety information FUE 6 Extension cable The machine may only be operated with undamaged extension cables! Only use extension cables with grounded conductor and correct connection of the grounded conductor to the plug and coupling (only for machines of class rating I).

  • Page 15: Safety Labels

    FUE 6 Safety information Safety labels Your machine has adhesive labels containing the most important instructions and safety information. Make sure that all the labels are kept legible. Replace any missing or illegible labels. Item Label Description Warning - Read manual.

  • Page 16: Scope Of Delivery

    Scope of delivery FUE 6 Scope of delivery The scope of delivery includes: Machine. Operator's manual. Parts book. General safety instructions.

  • Page 17: Description

    FUE 6 Description Description Application The machine may only be used for the operation of internal and external vibra- tors. The machine is used to convert the current on the construction site into current that can be used by the machines to be connected.

  • Page 18: Components And Operator's Controls

    Description FUE 6 Components and operator's controls Item Designation Item Designation Ventilation slots Status LED Protective frame Plug receptacle with protective cover (3 pieces) Power cable (not shown) ON/OFF switch Lifting strap Thumbwheel for frequency ad- justment (only FUE6 ... SC) Status LED If the machine is correctly connected, the status LED lights green.

  • Page 19: Transport

    FUE 6 Transport Transport WARNING Improper handling can result in injury or serious material damage. Read and follow all safety instructions of this operator's manual, see chapter Safety information. Transporting the machine 1. Switch off the machine via the ON/OFF switch.

  • Page 20: Operation

    Operation FUE 6 Operation WARNING Improper handling can result in injury or serious material damage. Read and follow all safety instructions of this operator's manual, see chapter Safety information. Prior to starting the machine After unpacking, the machine is ready for operation.

  • Page 21: Starting Up

    FUE 6 Operation Starting up WARNING A damaged machine part or power cable can result in personal injury caused by electric current. Do not operate a damaged machine! Have a damaged machine repaired immediately. Connecting the machine to the power supply The machine may only be connected to AC single phase, connection values see chapter Technical Data.

  • Page 22: Decomissioning

    Operation FUE 6 Switching on the machine Switch on the inverter via the ON/OFF switch. If the machine is ready for operation, the status LED lights green. Decomissioning Switching off the machine 1. Switch off all connected machines via the respective equipment switch.

  • Page 23: Maintenance

    FUE 6 Maintenance Maintenance WARNING Improper handling can result in injury or serious material damage. Read and follow all safety instructions of this operator's manual, see chapter Safety information. Maintenance schedule Note: The time intervals mentioned here are reference values for normal op- eration.
  • Page 24 Maintenance FUE 6 Cleaning the machine Note: Do not clean the machine with high pressure washers or steam jet cleaners! 1. Clean the ventilation slots with a suitable tool. 2. Wipe the housing with a damp and clean cloth. 3. Clean the thumbwheel (applicable to inverters with frequency adjustment).

  • Page 25: Troubleshooting

    FUE 6 Troubleshooting Troubleshooting Please refer to the following tables if the machine does not work properly. They contain potential faults, their causes and remedies. An LED makes troubleshooting easier. Malfunction Cause Remedy Inverter in operation. - Excessive current consump- Reduce the current consump- LED lights red and green.

  • Page 26: 10 Disposal

    Disposal FUE 6 10 Disposal 10.1 Disposal of the machine Your machine contains many valuable raw materials which should be disposed and recycled in an environmentally friendly manner. During disposal of the machine observe the country-specific rules and regula- tions, e.g. the European Directive for obsolete electrical and electronic devices.

  • Page 27: Accessories

    FUE 6 Accessories 11 Accessories The machine is available with a multiple plug receptacle for the connection of 2 external vibrators. For more information on accessories, visit the following website: www.wackergroup.com.

  • Page 28: 12 Technical Data

    Technical data FUE 6 12 Technical data 12.1 FUE 6 Designation Unit FUE 6/042/200W FUE 6/042/200W Item no. 0610176 0610084 Length x Width x Height mm (in) 524 x 325 x 325 (20.7 x 12.8 x 12.8) Weight kg (lb) 32.5 (71.7)

  • Page 29: Notes Regarding Class Rating And Protection Class

    FUE 6 Technical data 12.2 Notes regarding class rating and protection class Class rating The class rating according to DIN EN 61140 specifies the safety measures for electrical equipment to avoid electrocution. There are four class ratings: Class rating Meaning No special protection apart from the basic insulation.

  • Page 30: Extension Cable

    < 292 < 459 Example You utilize a FUE 6/042/200W and want to use an extension cable with a length of 45 m (148 ft). The machine has an input voltage of 230 V. According to the table, the extension cable must feature a cross-section area of 2.5 mm...

  • Page 31: Ec Declaration Of Conformity

    EC Declaration of Conformity Wacker Construction Equipment AG, Preußenstraße 41, 80809 München certifies that the construction machines: Category Inverter Type FUE 6/042/200W FUE 6/042/200W SC Machine type number 0610176 0610084 fulfill the requirements of the following directives: 2004/108/EC EN 61000 2006/95/EC Dr.

  • Page 33: Din En Iso 9001 Certificate

    DIN EN ISO 9001 Certificate Prüf- und Zertifizierungsinstitut VERBAND DER ELEKTROTECHNIK ELEKTRONIK INFORMATIONSTECHNIK e.V. C E R T I F I C A T E Registration-Number: 6236/QM/06.97 This is to certify that the company Wacker Construction Equipment AG Wacker-Werke GmbH & Co. KG at the following locations Head Office Munich Preußenstraße 41...
  • Page 34 Wacker Construction Equipment AG, Preußenstraße 41, 80809 München – Deutschland – Tel.: +49-(0)89-354 02-0 – Fax: +49-(0)89-354 02-390 Wacker Corporation – P.O. Box 9007 – Menomonee Falls, WI 53052-9007 – USA – Tel.: +1(1)262-255-0500 – Fax: +1(1)262-255-0550 – Support: 800-770-0957 Wacker Machinery (HK) Ltd.–...
