Summary of Contents for Wacker Neuson G 2.5A
- Page 1 0152792en 0902 Generator G 2.5A OPERATOR'S MANUAL...
- Page 2 DANGER CARBON MONOXIDE Using a generator indoors CAN KILL YOU IN MINUTES. Generator exhaust contains carbon monoxide (CO). This is a poison you cannot see or smell. If you can smell the generator exhaust, you are breathing CO. But even if you cannot smell the exhaust, you could be breathing CO.
- Page 3 Foreword Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.
- Page 4 G2.5A Nameplate / Plaque signalétique A nameplate listing the Model Number, Item Number, Revision, and Serial Number is attached to each unit. Please record the information found on this plate so it will be available should the nameplate become lost or damaged. When ordering parts or requesting service information, you will always be asked to specify the model, item number, revision number, and serial number of the unit.
-
Page 5: Table Of Contents
G2.5A Operating Information Table of Contents Safety Information ................1A-2 Operating Safety ................1A-3 Operator Safety while using Internal Combustion Engines ....1A-4 Service Safety ..................1A-4 Technical Data ................... 1A-5 Safety and Operating Labels .............. 1A-6 Label Locations .................. 1A-7 Application and Power Requirements .......... -
Page 6: Safety Information
OPERATION G2.5A Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. -
Page 7: Operating Safety
G2.5A OPERATION Operating Safety Familiarity and proper training are required for the safe operation of electrical equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions and familiarize yourself with the location and proper use of all instruments and controls. Inexperienced operators should receive instruction from someone familiar with the equipment before being allowed to operate the generator. -
Page 8: Operator Safety While Using Internal Combustion Engines
OPERATION G2.5A Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling! Read and follow warning instructions in engine owner's manual and safety guidelines below. Failure to follow the safety guidelines described below could result in severe injury or death. DANGER DO NOT run engine indoors or in an enclosed area DO NOT touch or lean against hot exhaust pipes. -
Page 9: Technical Data
G2.5A OPERATION Technical Data Generator Maximum Output 2500 Continuous Output 2250 Type Single voltage, single phase, brushless system AC Voltages available 120 1ø volts phase Frequency Power Factor AC Receptacles 120V GFI duplex 120V duplex Main Circuit Breaker L x W x H 27 x 17.5 x 17 (685 x 445 x 435) in. -
Page 10: Safety And Operating Labels
OPERATION G2.5A Safety and Operating Labels This WACKER machine uses international pictorial labels where needed. These labels are described below: DANGER IMPROPER CONNECTION OF GENERATOR TO A BUILDING'S ELECTRICAL SYSTEM CAN ALLOW ELECTRICAL CURRENT FROM THE GENERATOR TO BACKFEED INTO UTILITY LINES. THIS MAY RESULT IN ELECTROCUTION OF UTILITY WORKERS, FIRE OR EXPLOSION. -
Page 11: Label Locations
G2.5A OPERATION Danger! Electric shock will cause serious injury or death. 119593 Neutral bonded to frame. 155503 Label Locations DANGER IMPROPER CONNECTION OF GENERATOR TO A BUILDING'S ELECTRICAL SYSTEM CAN ALLOW ELECTRICAL CURRENT FROM THE GENERATOR TO BACKFEED INTO UTILITY LINES. THIS MAY RESULT IN ELECTROCUTION OF UTILITY WORKERS, FIRE OR EXPLOSION. -
Page 12: Application And Power Requirements
OPERATION G2.5A Application and Power Requirements This generator is designed to operate single-phase, Chart 1 : Approximate Starting Power Requirements 60 Hz appliances running at 120 VAC. Incandescent lights and appliances such as Some appliances and tools require a surge of current irons and hot plates, which use a resistive-type when starting. -
Page 13: Indoor Operation
G2.5A OPERATION 1.11 Indoor Operation If the generator must be operated indoors, adequate ventilation or exhaust hoses must be provided. When venting exhaust fumes, make sure the exhaust piping is large enough to prevent excessive back pressure to the engine. Back pressure reduces engine efficiency and may cause the engine to overheat. -
Page 14: Ground Fault Circuit Interrupt (Gfi)
OPERATION G2.5A 1.13 Ground Fault Circuit Interrupt (GFI) The 120V, 20 Amp duplex receptacle is equipped with a ground fault circuit interrupt (GFI). The GFI shuts off the power to the receptacle when a ground fault occurs in the generator or to a piece of equipment attached to the generator. -
Page 15: To Start
G2.5A OPERATION CHOKE 1015SD03 1015SD04 1005SD47 1005SD49 1.16 To Start 1.17 To Stop Before starting, be sure you read and understand all the 1. Turn off and disconnect all tools and appliances safety and operating instructions in this manual. attached to the generator. 1. -
Page 16: Engine Maintenance
OPERATION G2.5A 1.19 Engine Maintenance The Periodic Maintenance Schedule below lists basic maintenance intervals for the engine and generator. Please read the detailed maintenance procedures for the engine described in engine Owner’s Manual. This manual was supplied with the generator. Replacement copies of these manuals can be ordered from WACKER Corporation or directly from the engine manufacturer. -
Page 17: Servicing Air Cleaner
G2.5A OPERATION 1.23 Servicing Air Cleaner The engine is equipped with a dual element air cleaner— service frequently to prevent carburetor malfunction. CAUTION: NEVER run engine without air cleaner. Severe engine damage will occur. WARNING NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner. -
Page 18: Carburetor Adjustment
OPERATION G2.5A 1.25 Carburetor Adjustment The pilot screw (a) is fitted with a limiter cap to prevent excessive enrichment of the air-fuel mixture in order to comply with emission regulations. The mixture is set at the factory and no adjustment should be necessary. Do not attempt to remove the limiter cap. -
Page 19: Storage
G2.5A OPERATION 1.28 Storage 1.29 Troubleshooting Before storing generator for a long period of time: If engine doesn't start, check that: 1. Engine switch is on "Start". 1. Close the fuel valve and remove and empty sediment 2. Fuel valves under fuel tank and on engine are open. cup under carburetor. -
Page 20: Wiring Schematic
OPERATION G2.5A 1.30 Wiring Schematic wc_gr000262 1A-16... - Page 21 UNITED KINGDOM LONDON LEA ROAD Tel. (44)(01992) 707200 WALTHAM CROSS, HERTS EN9 1AW Washington Washington/Tyne N37 1LH Tel. (0191) 4 16 63 92 Warrington Winwick Quay, Warrington WA2 8RE Tel. (01925) 57 39 55 Worksop Worksop S81 7BE Tel. (01909) 48 45 06 Redditch Washford, Redditch B98 0DQ Tel.
- Page 22 www.wackergroup.com UNITED STATES CORPORATE OFFICE MENOMONEE FALLS, WI 53052 N92 W15000 ANTHONY AVE. Tel. (262) 255-0500 CANADA MISSISSAUGA, ONT. L5T 2N6 160 ADMIRAL BLVD. Tel. (905) 795-1661 Calgary, Alta. T2H 2H9 #11, 6115-4 St. S.E. Tel. (403) 255-3336 St. Laurent, Quebec H4R 2C1 3526 Rue Ashby Tel.
