2. On the PGROUPS Configuration page, enter values for the parameters indicated in
Web Page Item
Bypass DTMF
#
Address
Port
Name
TTL
Lineout
Security Code
Note
CyberData Corporation
Table 2-11. PGROUPS Configuration Parameters
Description
When selected, bypassing the DTMF will result in all calls being relayed to
PGROUP 0.
Shows the paging group number.
Enter the IP address of the PGROUP.
Note: To disable a relay on a group, use an IP address of 0.0.0.0.
Enter the port number of the PGROUP.
Note: The port range can be from 2000 to 65534 and must be even. When
configuring a Paging Group for Polycom Group Paging using an odd-numbered
port, configure the next lower even port number. For example, when using the
default Polycom paging port 5001 on Polycom phones, configure the next lower
even port 5000 for the desired V3 Paging Server's Paging Group port.
Enter a name for the PGROUP.
The TTL field allows you to adjust the TTL. TTL is "time to live" and it describes
how many networks (routers) a packet will go through before it is discarded.
The Lineout field determines whether or not the device will play audio out of the
RCA output port and the 600 Ohm output port in addition to forwarding it to the
PGROUP.
This field allows the user to add a security code to prevent unauthorized paging
to the PGROUP. Code must be between two to five numeric digits (0 through 9).
Leave the field empty for no security code. Any security code entered for
PGROUP 0 will be ignored if DTMF is bypassed.
Click on 1, 2, 3, or 4 to navigate through the pages of PGROUPS.
You must click on the Save button and then the Reboot button for the changes to take
effect.
