KS-AX4500
Location of main parts
HEAT SINK
CONTROL PANEL
SWITCH KNOB
VOLUME KNOB
HEAT SINK
REAR PANEL
FUSE
INPUT for POWER
OUTPUT TERMINAL for REAR(L/R)
OUTPUT TERMINAL for FRONT(L/R)
LOW INPUT jack for REAR(R)
LOW INPUT jack for FRONT(R)
HEAT SINK
FRONT PANEL
HIGH INPUT connector for FRONT
HIGH INPUT connector for REAR
LOW INPUT jack for FRONT(L)
LOW INPUT jack for REAR(L)
1-3
