- Page 1 HF-Series Operation Instructions Rev 1 (7/9/13) Page 1 Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 2 HF-Series Operation Instructions Introduction Various models that range from 17.4 - 87 lbf.in High performance Swiss Maxon brushless motor design provides durability and reduces the standard maintenance costs for electric screwdrivers. Designed for high production environments. Minimal heat build-up even when tool is operated continuously.
- Page 3 HF-Series Operation Instructions General Operation for HF-Series models 1. Attach power tool cable to the HF screwdriver and the transformer. Make sure notch in plug lines up with the notch on the socket. Tighten knurled ground ring. 2. Plug in power cord to the back of the transformer and power outlet. Flip power switch to “ON”...
- Page 4 Item # 145774 The Program Lock Key protects from incidental or operator tampering of the programmable settings on the side of select HF-Series models. To adjust the settings the Program Lock Key must be is plugged into the HTC35 Transformer.
- Page 5 HF-Series Operation Instructions How to Adjust Soft Start Setting There are 3 different time settings for the Soft Start mode which are (0.2, 0.4 & 0.6 seconds). The default setting is OFF. For those fastening applications that require a slow start and then ramp up the speed of the electric screwdriver. The soft start function can prevent damage to screw heads.
- Page 6 HF-Series Operation Instructions Connections Page 6 Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 7 The torque arm can be installed in space-restricted areas Right Angle Adapter. Easily mounts onto nose of driver. Torque Cover protects the HF-Series from incidental or operator tampering of torque setting. Allows for color- coding of specific torque values in production areas.
- Page 8 HF-Series Operation Instructions Torque Charts These charts are meant to be used as guidelines for setting the torque on the HF-Series electric screwdrivers. The drivers have a torque scale on the torque adjustment nut showing reference numbers. These numbers determine the approximate torque setting.
- Page 9 1. The NF-Series screwdrivers are a precision torque control instrument and should be handled with care at all times. 2. Only use the transformers listed in the Mountz catalog or website for appropriate NF-Series driver model (If you have any questions regarding the appropriate transformer set-up, contact Mountz Customer Service Department).
