Control Panel
WHITE BALANCE
Adjusts the tone of white.
'AUTO'
Adjusts the tone of white automatically. Before pushing the button,
project a white sheet of paper fully on the screen and adjust the bright-
ness. The indicator lights up during the adjustment.
• Adjust WHITE BALANCE again when the ambient illumination has
changed.
'BLUE'
Adds a slightly blue shade to white.
'RED'
Adds a slightly yellow shade to white.
(NOTE) With power to this equipment turned off, white balance will
be reset to factory setting. See page E-15 for storage of adjusted
value.
'LIGHT'
Turns on the light. At each press,
the illumination changes as fol-
lows:
"Main light lights up and base light
goes out." → "Main light goes out
and base light lights up."→ "Both
main light and base light go out."
LIGHT
POSI/NEGA
'POSI / NEGA'
Produces an output after
negative conversion.
Press this button again and the
output will return to positive.
The indicator lights up when
positive is on.
'COLOR / BW'
Produces black-and-white output. Press
again and the output will return to color.
The indicator lights up when color is on.
'TEXT / PHOTO'
Selects output for text or photo.
The indicator lights up when text is on.
(NOTE)When the negative mode is selected
using the 'POSI/NEGA' button, the 'TEXT/
PHOTO' button is not available.
NOTE:
• The main light is provided within the camera head. Turn it on when shooting printed matter. The base light is provided
within the stage, which is to be turned on when shooting see-through material. For the combination of ON and OFF of
the lights, please refer to the "lighting guidelines" in the NOTE on page E-15.
SOURCE
Selects a source input for output.
The indicator for the currently selected input
lights up.
'CAMERA'
Selects camera image.
'MEMORY'
Selects the image stored in image memory.
(NOTE) Digital zoom is cancelled.
'EXTERNAL'
Selects the image being inputted to the RGB
input terminal.
(NOTE) EXTERNAL cannot be selected when
video output is selected by dip switch 4. (See
page E-10)
WHITE BALANCE
SOURCE
AUTO
BLUE
RED
CAMERA
MEMORY
UP
MEMORY
DOWN
COLOR/BW
TEXT/PHOTO
CAPTURE
'CAPTURE'
Writes image into image
memory.
(NOTE) Turning power off
will erase memory con-
tents.
Image Memory No. Display
Displays the No. of the image
memory selected.
MEMORY
Selects image memory.
'UP'
Selects the next image memory.
'DOWN'
Selects the previous image memory.
BRIGHTNESS
Adjusts the brightness of image.
'AUTO'
Adjusts the brightness of image au-
tomatically. The indicator lights up
during the adjustment.
'DARK'
Darkens the image.
'BRIGHT'
Brightens the image.
KEYSTONE
Corrects trapezoidal dis-
tortion when shot ob-
liquely. Or cancels correc-
tion. (See page E-16)
'ON / OFF'
Turns trapezoidal correc-
tion on or off. The indica-
tor lights up with trapezoi-
dal correction on.
'+' '-'
Makes fine adjustment of
trapezoidal correction.
BRIGHTNESS
EXTERNAL
AUTO
DARK
BRIGHT
FOCUS
AUTO
NEAR
FAR
FOCUS
Adjusts the focus of camera image.
'AUTO'
Adjusts the focus of camera image automatically.
The indicator lights up during the adjustment.
'NEAR'
Moves the focus nearer to the camera.
'FAR'
Moves the focus farther from the camera.
E-9
'REAL / FREEZE'
Selects between
moving
mode and still im-
age mode. The in-
dicator for the
moving
mode selected
light up.
KEYSTONE
ON/OFF
REAL/FREEZE
ZOOM
WIDE
TELE
ZOOM
Changes the range of image to be
shot.
'WIDE'
Shoots a wider range.
'TELE'
Shoots an enlarged portion of an
area.
(NOTE) For zooming above opti-
cal 15-power zoom, use digital
zoom. In digital zoom, change
magnification by pressing button
step by step. Digital zoom may
sometimes produce inferior image
quality.
