- Page 1 FUN CYCLE OWNER'S GUIDE #18127 4/98 $1.00...
- Page 2 ITEM PART DESCRIPTION QTY. ITEM PART DESCRIPTION 19171 SCREW ^10-32 x3/8 RHMS 12272 RETAINER RING 11745 FENDER. 20" REAR 11340 NUT 1/2 x 13 NYLON JAM 11760 BRACE, REAR FENDER 12301 WASHER 3/8 SAE 12170 NUT ^10 10-32 HEX KEPS 19153 NUT AXLE CB SHIMANO 12223...
- Page 3 (23). Tighten nuts so that the frame sections are securely held together, but not so much to cause binding when pivoted. Tighten backrest clamps and refer to schematics for correct placement. Front Frame Fig. 2 TRAILMATE owner's guide...
-
Page 4: Front Wheel Assembly
4 through 6. 7. Pedals Install pedals (31) by threading the pedal marked "R" into the right side of the crank (clockwise) and the pedal marked "L" into the left side of the crank (counterclockwise). TRAILMATE owner's guide... - Page 5 (see figure 7). Sit in seat and readjust tension until comfortable. 12. Handlegrips and Flag Complete by installing handlegrips (18) and placing safety flag (42) All-Weather Canvas Seat in hold Fig. 7 TRAILMATE owner's guide...
-
Page 6: Maintenance And Inspection
6. Seat: Adjust seat for rider comfort and safety. 7. Tires: Keep tires inflated to the recommended tire pressure, as indicated on the tire's sidewatl. 8. Chainguard: Replace damaged or missing chainguard immediately 9. Frame: Replace damaged frame immediately. TRAILMATE owner's guide... - Page 7 Trailmate, Inc., further authorizes a lifetime frame guarantee and will replace any frame, at no cost to the buyer, providing that item has not been used for rental use and that: 1) The item has not been altered, repaired, or modified in any way.
