Summary of Contents for TRAILMATE Desoto Classic
- Page 1 Desoto Classic & EZ Roll Regal Owner’s Guide DESOTO CLASSIC EZ ROLL REGAL...
- Page 3 24" DESOTO/REGAL PARTS LIST ITEM PART DESCRIPTION ITEM PART DESCRIPTION 11871 REFLECTOR KIT TRIKE 11679 CONNECTING LINK 12199 SCREW 14 x 3/4 11747 FENDER 24" FRONT W/BRACKET 12069 BASKET HOLD DOWN 11764 FENDER BRACE 24" 11639 BASKET COATED TRIKE 12176 NUT 5/16 - 24 HEX 12102 FLAG SAFETY W/POLE...
- Page 4 DESOTO CLASSIC & EZ ROLL REGAL ASSEMBLY INSTRUCTIONS 1. Preparation 4. Front Fender & Wheel Remove parts from carton. Check air Install front wheel in slots of fork with pressure & inflate tires to 35 psi. Make wheel retainer (66) tabs seated in sure tires are properly seated on rims.
- Page 5 DESOTO CLASSIC & EZ ROLL REGAL ASSEMBLY INSTRUCTIONS 7. Chainguard 9. Handlebar Place chainguard (25) over chain & Slide handlebar (47) through clamp on slide rear under top of transmission stem (49) with portion of long bolt to box rear. Attach using screw & u-nut rear.
- Page 6 DESOTO CLASSIC & EZ ROLL REGAL ASSEMBLY INSTRUCTIONS 11. Basket Place basket (4) on rear frame immediately behind sissy bar & centered between the rear wheels. Secure basket using tabs (3) & screws (2) into the holes in rear frame &...
- Page 7 MAINTENANCE & INSPECTION REGULAR MAINTENANCE: BI-MONTHLY 1. Keep all painted parts clean & waxed for long-lasting luster. 2. Spray chrome parts with recommended coating & let sit overnight for penetration. 3. Lubricate following: Seat pivot points, axle shafts, pedal bearings, chain (turn/spray).
- Page 8 Trailmate, Inc., further authorizes a lifetime frame guarantee and will replace any frame, at no cost to the buyer, providing that the item has not been used for rental and that:...
