TAIL WHEEL ASSEMBLY
(1)
Nylon Tail Wheel Bracket
(1)
Nylon Tail Wheel Tiller Arm
(1)
Prebent Tail Wheel Wire
(1)
Tail Wheel
(2)
Wheel Collars w/Set Screws
(1)
Nylon Spacer
(1)
2.5mm x 12mm Wood Screw
(3)
3mm x 12mm Wood Screws
ENGINE MOUNT ASSEMBLY
(2)
Engine Mounting Beams
(4)
4mm x 20mm Socket-Cap Screws
(4)
4mm x 30mm Socket-Cap Screws - Optional
(4)
4mm Blind Nuts
(4)
4mm x 25mm Socket-Cap Screws
(4)
4mm Lock Nuts
(12) 4mm Flat Washers
ELEVATOR CONTROL SYSTEM
(1)
31" Threaded Wire
(1)
Nylon Control Horn w/Backplate
(2)
2mm x 20mm Machine Screws
(1)
Nylon Clevis
(1)
Nylon 90º Snap Keeper
(6)
C/A Style Hinges
FUEL TANK ASSEMBLY
(1)
360cc Fuel Tank
(1)
Large Diameter Metal Plate
(1)
Small Diameter Metal Plate
(1)
Rubber Stopper
(1)
Fuel Pick-Up "Clunk"
(1)
3mm x 20mm Machine Screw
(1)
Silicon Fuel Tubing
(2)
Aluminum Tubing
SECTION 4: METRIC CONVERSION CHART
To convert inches into millimeters: Inches x 25.4 = mm To convert millimeters into inches: Millimeters / 25.4 = in
1/64"
=
.4mm
1/32"
=
.8mm
1/16"
=
1.6mm
3/32"
=
2.4mm
1/8"
=
3.2mm
5/32"
=
4.0mm
6
Visit our website at http://modeltech.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
3/16"
=
4.8mm
1/4"
=
6.4mm
3/8"
=
9.5mm
1/2"
=
12.7mm
5/8"
=
15.9mm
3/4"
=
19.0mm
RUDDER CONTROL SYSTEM
(1)
31" Threaded Wire
(1)
Nylon Control Horn w/Backplate
(2)
2mm x 20mm Machine Screws
(1)
Nylon Clevis
(1)
Nylon 90º Snap Keeper
(3)
C/A Style Hinges
LANDING GEAR ASSEMBLY
(1)
Prebent Aluminum Main Gear Strut
(2)
Blow-Molded Wheel Pants
(2)
Main Gear Wheels
(2)
Plywood Mounting Plates (D36)
(2)
4mm Threaded Axles w/Lock Nuts
(4)
4mm Wheel Collars w/Set Screws
(4)
4mm x 20mm Machine Screws
(4)
4mm Flat Washers
(2)
3mm x 12mm Machine Screws
(2)
3mm Blind Nuts
MISCELLANEOUS WING PARTS
(1)
Hardwood Wing Joiner (W3)
(2)
5mm x 40mm Machine Screws
(2)
5mm Flat Washers
(2)
5mm Blind Nuts - Optional
MISCELLANEOUS FUSELAGE PARTS
(1)
Prepainted Fiberglass Cowling
(1)
Plywood Engine Mount Spacer (F1A) - Optional
(1)
Plywood Fuselage Servo Tray (D29)
(1)
Clear Plastic Windscreen
(4)
3mm x 10mm Wood Screws
(4)
3mm Flat Washers
(2)
2mm x 6mm Wood Screws
(1)
Length of Clear Tubing
(1)
Decal Sheet
1"
=
25.4mm
2"
=
50.8mm
3"
=
76.2mm
6"
=
152.4mm
12"
=
304.8mm
18"
=
457.2mm
21"
=
533.4mm
24"
=
609.6mm
30"
=
762.0mm
36"
=
914.4mm
