Sony HCD-HPX7 Service Manual

Compact disc deck receiver.
Hide thumbs

Advertisement

SERVICE MANUAL

Ver 1.0 2004.06
HCD-HPX7 is the amplifier, CD player,
tape deck and tuner section in CMT-HPX7.
Main unit
Amplifier section
European model:
DIN power output (rated): 50 + 50 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
60 + 60 W
(6 ohms at 1 kHz, 10%
THD)
Music power output (reference): 100 + 100 W
Other models:
The following measured at AC 240 V, AC 220 V or AC
120 V
DIN power output (rated): 45 + 45 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
50 + 50 W
(6 ohms at 1 kHz, 10%
THD)
Inputs
MD/VIDEO:
Sensitivity 450/250 mV,
impedance 47 kilohms
Outputs
PHONES:
Accepts headphones with
an impedance of 8 ohms or
more.
SPEAKER:
Accepts impedance of 6 t
16 ohms.
Sony Corporation
9-877-911-01
Home Audio Company
2004F1678-1
Published by Sony Engineering Corporation
© 2004.06
HCD-HPX7
Model Name Using Similar Mechanism
CD
CD Mechanism Type
Section
Base Unit Name
Optical Pick-up Block Name
Tape deck
Model Name Using Similar Mechanism
Section
Tape Transport Mechanism Type
SPECIFICATIONS
CD player section
Laser
Semiconductor laser
(λ=780 nm)
Emission duration:
continuous
Frequency response
20 Hz – 20 kHz
Tape deck section
Recording system
4-track 2-channel, stereo
Frequency response
50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassettes
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
87.5 – 108.0 MHz
Antenna
FM lead antenna
Antenna terminals
75 ohms unbalanced
I ntermediate frequency 10.7 MHz
AM tuner section
Tuning range
Pan-American model:
530 – 1,710 kHz
(with the tuning interval
set at 10 kHz)
531 – 1,710 kHz
(with the tuning interval
set at 9 kHz)
o
European model:
531 – 1,602 kHz
(with the tuning interval
set at 9 kHz)
COMPACT DISC DECK RECEIVER
Canadian Model
AEP Model
UK Model
E Model
Australian Model
HCD-HPX9
CDM82A-F1BD81
BU-F1BD81A
KSM-215DCP
HCD-HPX9
CMAL5Z225A
Other models:
530 – 1,710 kHz
(with the tuning interval
set at 10 kHz)
531 – 1,602 kHz
(with the tuning interval
set at 9 kHz)
Antenna
AM loop antenna, external
antenna terminal
Intermediate frequency 450 kHz
General
Power requirements
North American model: 120 V AC, 60 Hz
Australian model:
230 – 240 V AC, 50/60 Hz
European model:
230 V AC, 50/60 Hz
Taiwan model:
120 V AC, 50/6
Korean model:
220 V AC, 60 Hz
Mexican model:
120 V AC, 60 Hz
Other models:
120 V, 220 V or 230 – 240
V AC, 50/60 Hz
Adjustable with voltage
selector
Power consumption
European model:
115 W
Other models:
90 W
Design and specifications are subject to change
without notice.
0 0 Hz

Advertisement

Table of Contents

   Related Manuals for Sony HCD-HPX7

   Summary of Contents for Sony HCD-HPX7
