NØRRESKOVEN
Mk 2
M U L T I F U E L
S T O V E
Installation and Operating Instructions
An accredited competent person must carry out the installation of this appliance;
alternatively, your local Building Control Officer can approve the completed
installation, should a non-accredited engineer undertake the installation. It is an
offence, under UK law, not to comply with this advice. Please hand these
instructions to the stove user when the installation is complete. Leave the system
ready for operation and instruct the user in the correct use of the appliance and
operation of controls.
v01.11b
Advertisement
Table of Contents
Related Manuals for Cleanburn NØRRESKOVEN
Summary of Contents for Cleanburn NØRRESKOVEN
- Page 1 NØRRESKOVEN Mk 2 M U L T I F U E L S T O V E Installation and Operating Instructions An accredited competent person must carry out the installation of this appliance; alternatively, your local Building Control Officer can approve the completed installation, should a non-accredited engineer undertake the installation.
-
Page 2: Technical Specification
Nørreskoven Technical Specification Stove Mass 100 kg BS/EN 13240 Total Efficiency 73.5 % Nominal Heat Output 4.4 kW Mean CO Emission (at 13% O 0.17 % Mean Flue Gas Temperature 311 °C Flue Gas Mass Flow 4.6 g/s This appliance is not suitable for use in a shared flue This appliance is suitable for intermittent burning... -
Page 3: Important! - Read This First
Important! – Read This First This stove has been designed and assembled so that it may be used to burn wood logs in a Smoke Control Area. Find out if you are in a Smoke Control Area by contacting your Local Authority or at the following web address: http://smokecontrol.defra.gov.uk/locations.php If the stove is being installed in a location which is not in a Smoke Control Area, the screw shown in... -
Page 4: Assembly Instructions
Assembly Instructions PLEASE READ THESE INSTRUCTIONS CAREFULLY It is important that your stove is correctly installed, as Cleanburn Stoves cannot accept responsibility for any fault arising through incorrect use or installation. Flue Collar Wind the eight M6 studs supplied into the fixing holes in the flue collar and blanking plate until finger tight. - Page 5 Removing Internal Parts This set of instructions explains the removal sequence that you will need to employ when servicing your Cleanburn stove. 1. Open the stove door(s) and remove the ash pan. 2. Remove the baffle by pulling it forwards and sliding it to the left until the right side of it clears the baffle support and then lowering it into the firebox and removing it (a).
- Page 6 2. Remove the side castings by lifting them upwards and out (g). 3. Remove the front plate by lifting it out. On double-door stoves it will be necessary to push the front plate towards the back of the stove to free it from the location pins (h) before lifting it out (k).
-
Page 7: Installation Instructions
Installation Instructions These instructions cover the basic principles to ensure satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current Building Regulations, Local Authority Byelaws and other specifications or regulations as they affect the installation of the stove. -
Page 8: Installation
Installation Chimney The chimney height and the position of the chimney terminal should conform to Building Regulations. Check that the chimney is in good condition, dry, free from cracks and obstructions. The diameter of the flue should not be less than 127mm and not more than 230mm. If any of these requirements are not met, the chimney should be lined by a suitable method. -
Page 9: Free-Standing
Material Clearances Your stove must be installed on a floor with adequate load-bearing capacity. If the existing construction does not meet this pre-requisite, suitable measures (e.g. load distributing plate) should be taken to achieve it. Care should be taken to level the stove using the adjusting screws in the feet. FREE-STANDING FIREPLACE RECESS Plan view:... - Page 10 Fuel Storage log storage recess Fuel may be placed in the log storage recess underneath the European variant. The logs should be stacked in such a way that they do not touch the heat shield at the top of the recess. Important! - Fuel must not be stored underneath the Traditional or Pedestal variants.
-
Page 11: Operating Instructions
Operating Instructions This appliance is not suitable for use in a shared flue This appliance should not be operated with the doors open Aerosol Sprays Do not use an aerosol spray on or near the stove when it is alight. Air Controls This stove has been designed to burn cleaner and more efficiently than a conventional wood burning stove. - Page 12 Warning!- The stove will remain hot for a considerable time after the fire has been extinguished. Recommended Fuels Cleanburn Stoves recommend wood logs be burnt in this appliance. Burn only dry, well-seasoned wood, which should have been cut, split and stacked for at least 12 months, with free air movement around the sides of the stack to enable it to dry out.
-
Page 13: Safety Notes For Your Guidance
Safety notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children, the elderly or the infirm. The fireguard should be manufactured in accordance with BS 6539 – Fireguards for use with solid fuel appliances. DO NOT OVERFIRE –... -
Page 14: General Maintenance
Check the rope around the door and glass. If rope is becoming detached, use proprietary rope glue to re-attach it. If the rope is in a poor condition, a replacement rope kit may be ordered from the Cleanburn Stoves spares range. Annually... - Page 15 If the stove is fitted in place of an open fire, then the chimney should be swept one month after installation to clear any soot falls which may have occurred due to the difference in combustion between the stove and the open fire. Periods of Prolonged Non-Use - If the stove is to be left unused for a prolonged period of time then it should be given a thorough clean to remove ash and unburned fuel residues.
-
Page 16: Stove Spares
STOVE SPARES SINGLE DOOR Door Handle Assembly Single Door Door Handle, Black HMS04/002 HCE05/053 Handle Spacer, Black HCE05/054 Handle Nut, Black HCE05/055 Door Glass Shaft, Door Handle HMS04/053 HCE05/038 Glass Gasket Circlip HMS04/055 FLRX07 M8 Full Nut FSHM08 Glass Clip & Screw Door Catch HHR08/046 HMS04/037... - Page 17 PRIMARY AIR VALVE Shaft Spacer Primary Air Valve x3 HCE06/048 HCE06/049 Slider Knob Primary Air Valve Plate HCE06/059 HCE06/047 Washer x3 Wave Spring x3 FWFM08017 6890 - Lesjofors Support HCE06/046 Washer x3 Nut x3 FWFM06016 FNFM06Z BODY ASSEMBLY - PART SECTION - MULTIFUEL Flue Gaskets Top Air Parts Flue Collar...
- Page 18 QUARTER TURN DOOR HANDLE - DOUBLE DOOR - MULTIFUEL – PARTS Catch End HCE09/089 Catch Shaft HCE05/082 M12 Half Nut FNLM12Z Catch Collar Catch Boss HCE09/092S HCE09/090S Snap Ring FLRWM0160 3mm x 10mm Roll Pins 4mm x 14mm Roll Pin FPGM03010 FPGM04014 Catch Spacer...
