Land Pride RTR10 Series Features And Benefits

Features and Benefits
Rotary Tillers, Reverse Tine Rotation
Features
American made
Reverse tilling action
Tractor HP range
Gearbox Warranty
Working widths
6 1/2" Digging depth
Plate steel upper hitch
Clevis lower hitch
Hitch offset capability
Offset Dimensions
Fits Land Pride Quick-Hitch
Adjustable parking stand
Adjustable skid shoes
Formed and reinforced rear
deflector
Front deflector
4 'C' shaped heat-treated
tines per flange
Solid rotor shaft
15" Rotor swing diameter
Double lip seal on rotor bearing
Fully shielded shear pin or
slip-clutch driveline
#80 Drive chain enclosed in oil
bath
Stamped chain cover
Designs, specifications, features and information are subject to change without notice.
16/23/10
RTR10 Series
Many tillers are imported. American made means better parts availability.
Reverse action 'sucks' tiller into ground, does not walk on top of hard ground like
forward rotation tillers can.
17-25 HP
5 Years on housing, seals, & bearings. shows our confidence in the product.
42", 50", 58" to meet specific customer needs.
For deep soil penetration.
Plate steel is stronger than flat bar type hitch.
Provides additional strength and easy one person hook-up.
Offset by moving lower hitch points and gearbox mount to cover right tire track.
42" Width 16" - 26" Std.
50" Width 25" - 25" Std.
58" Width 29" - 29" Std.
Allows for quick and easy one person hook-up.
(Offset cannot be used with Quick-Hitch.)
Allows for easy hook-up and storage.
Control depth with seven adjustments.
Keeps dirt in and leaves a level finish. Forming gives deflector additional strength.
Adjustable deflector allows for various finish results.
Front deflector is flexible to take the beating from rocks or debris.
'C' Shaped tines require less HP to move through the ground.
1 3/4" Solid steel rotor shaft for strength.
For deep tilling and turning the soil over faster.
Double lip seal helps keep the dirt out and the grease in.
Protects the gearbox and rotor shaft upon hitting obstructions. Slip-clutch saves
having to replace shear-pins.
Heavy drive chain stretches less, and oil bath keeps wear to a minimum.
Stamped forming gives the chain cover strength.
Benefits
13" - 29" Max. Right 23" - 19" Max. Left
18" - 32" Max. Right 32" - 18" Max. Left
22" - 36" Max. Right 36" - 22" Max. Left
311-431F continued on next page
