Land Pride RTA25 Series Features And Benefits

Features and Benefits
Rotary Tillers, Standard Tine Rotation
Features
American made
Tractor HP Range
Gearbox Warranty
Working widths
8" Digging depth
Stamped upper hitch plate
Hitch bolted to
inside of support
Clevis Style Lower Hitch
Hitch Offset capability
Fits Land Pride
Quick-Hitch
Adjustable Parking stand
Adjustable skid shoes
Wear shield or left skid shoe
Formed rear deflector with
springs
Rear gate down pressure
springs (optional)
Four or six tines per flange
"C" Tines
Rotor swing diameter
Double lip seal on rotor
bearings
Cat. 3 driveline with
slip-clutch protection
#100 Drive chain
enclosed in oil bath
Stamped chain cover
Designs, specifications, features and information are subject to change without notice.
5/12/09
RTA25 & RTA35 Series
Many tillers are imported. American made means better parts availability.
(RTA25 = 25 - 55 HP) And (RTA35 = 35 - 75 HP)
3 Years on housing, gears, shafts, seals, bearings. Shows our confidence in the product.
(RTA25 = 62" & 70") And (RTA35 = 76") To meet specific customer needs
For extra deep soil penetration and cultivation.
Stamped plate adds additional strength to hitch.
Force is applied downward on top hitch, by bolting hitch to inside of support. Keeps hitch
from 'spreading' outward.
Allows easier hook-up of lower 3-point arms.
Offset 5" by moving lower hitch points to cover right tire track.
Allows for quick and easy one person hook-up. Offset can not be used with Quick-Hitch.
Allows for easy hook-up and storage.
Control depth with various settings.
Shield protects lower portion of chain cover from wearing due to dragging in the soil.
Forming gives deflector additional strength. Springs allow deflector to ''bounce'' when
obstructions are hit.
Forces the rear gate down to level even better. Easy-to-adjust chain tightener Cast iron
chain tightener is a simple bolt adjustment to keep constant tension on the chain.
Six tines go through the ground better than four.
C Tines take less horsepower to move through the ground.
(RTA25 = 17") And (RTA35 = 19") For deep tilling action and turning the soil over faster.
Double lip seal helps keep the dirt out and the grease in.
Heavy driveline for rough conditions. Slip-clutch protects other drive train components and
saves having to replace shear bolts.
Heavy-duty drive chain reduces stretching, oil keeps constant lubrication and holds wear
to a minimum.
Stamped forming adds additional strength.
Benefits
